DM-TX-4K-202-C and DM-TX-4K-302-C
4K DigitalMedia 8G+® Transmitters
The Crestron®
DM-TX-4K-202-C
versatile interface for computers and high-definition AV sources as part
of a complete Crestron DigitalMedia™ system. The devices function as
DM 8G+® transmitters and switchers, and also provide control module
functionality.
In the Box
DM-TX-4K-202-C or DM-TX-4K-302-C , 4K DigitalMedia 8G+®
1
Transmitters
Additional Items
1
Connector, 2-Pin (2003574)
1
Connector, 5-Pin (2003577)
and
DM-TX-4K-302-C
provide a
Install the Transmitter
NOTE:
This unit is for indoor use only. It is not intended for outdoor use.
Cet appareil est réservé à une utilisation en intérieur. Il n'est pas
destiné à une utilisation en extérieur.
The DM-TX-4K-202-C and DM-TX-4K-302-C can be mounted onto a flat
surface or onto a rack rail.
Mount onto a Flat Surface
Using four mounting screws (not included), mount the device onto a flat
surface such as a wall or a ceiling.
Quick Start
1

Advertisement

loading

Related Manuals for Crestron DM-TX-4K-202-C

Summary of Contents for Crestron DM-TX-4K-202-C

  • Page 1 Cet appareil est réservé à une utilisation en intérieur. Il n’est pas In the Box destiné à une utilisation en extérieur. DM-TX-4K-202-C or DM-TX-4K-302-C , 4K DigitalMedia 8G+® The DM-TX-4K-202-C and DM-TX-4K-302-C can be mounted onto a flat Transmitters surface or onto a rack rail. Mount onto a Flat Surface...

  • Page 2: Connect The Transmitter

    The DM OUT port of the DM-TX-4K-302-C is a PoDM+ powered device (PD) port and is also compatible with HDBaseT® PoE+. The DM OUT port of the DM-TX-4K-202-C is a standard PoDM PD port and is also compatible with HDBaseT PoE.
  • Page 3 Quick Start DM-TX-4K-202-C and DM-TX-4K-302-C 4K DigitalMedia 8G+® Transmitters Left and Right Side Connections (DM-TX-4K-302-C Shown)

  • Page 4: Upgrade The Firmware

    Do not connect ground wires to the connector shell. The connector shell is reserved for the cable shield. Upgrade the Firmware Before using the device, upgrade the firmware. The latest firmware can be downloaded from the DM-TX-4K-202-C DM-TX-4K-302-C product page on the Crestron website (www.crestron.com).

  • Page 5: Determine The Ip Address

    To assign the default static IP address of the transmitter, hold www.crestron.com/model/6507319 down the SETUP button while the unit boots up. The default static IP address, which is 192.168.1.204 for the DM-TX-4K-202-C and 192.168.1.205 for the DM-TX-4K-302-C, overwrites the current setting.
  • Page 6 Development Tools License Agreement. Crestron product operating system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement. Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_agreement. The product warranty can be found at www.crestron.com/warranty.
