DM-TX-4KZ-202-C and DM-TX-4KZ-302-C
DigitalMedia 8G+® 4K60 4:4:4 HDR Transmitters
The Crestron®
DM-TX-4KZ-202-C
versatile interface for ultra high-definition AV sources as part of a
complete Crestron DigitalMedia™ system. The devices function as DM
8G+® transmitters and switchers, and also provide control module
functionality.
In the Box
DM-TX-4KZ-202-C or DM-TX-4KZ-302-C , DigitalMedia 8G+®
1
4K60 4:4:4 HDR Transmitters
Additional Items
1
Connector, 2-Pin (2003574)
1
Connector, 5-Pin (2003577)
and
DM-TX-4KZ-302-C
provide a
Install the Transmitter
NOTE:
This unit is for indoor use only. It is not intended for outdoor use.
Cet appareil est réservé à une utilisation en intérieur. Il n'est pas
destiné à une utilisation en extérieur.
The DM-TX-4KZ-202-C and DM-TX-4KZ-302-C can be mounted onto a
flat surface or onto a rack rail.
Mount onto a Flat Surface
Using four mounting screws (not included), mount the device onto a flat
surface such as a wall or a ceiling.
Quick Start
1
Advertisement
Table of Contents
Related Manuals for Crestron DM-TX-4KZ-202-C
Summary of Contents for Crestron DM-TX-4KZ-202-C
- Page 1 In the Box destiné à une utilisation en extérieur. DM-TX-4KZ-202-C or DM-TX-4KZ-302-C , DigitalMedia 8G+® The DM-TX-4KZ-202-C and DM-TX-4KZ-302-C can be mounted onto a 4K60 4:4:4 HDR Transmitters flat surface or onto a rack rail. Mount onto a Flat Surface...
- Page 2 DM-TX-4KZ-202-C and DM-TX-4KZ-302-C DigitalMedia 8G+® 4K60 4:4:4 HDR Transmitters Mount onto a Rack Rail The DM-TX-4KZ-202-C or DM-TX-4KZ-302-C can be mounted onto a Connect the Transmitter front or rear rack rail. To mount the device: Connect the device as required for the application.
- Page 3 Quick Start DM-TX-4KZ-202-C and DM-TX-4KZ-302-C DigitalMedia 8G+® 4K60 4:4:4 HDR Transmitters Left and Right Side Connections (DM-TX-4KZ-302-C Shown)
- Page 4 To assign the default static IP address of the transmitter, hold down the SETUP button while the unit boots up. The default static IP address, which is 192.168.1.251 for the DM-TX-4KZ-202-C and 192.168.1.252 for the DM-TX-4KZ-302-C, overwrites the current Upgrade the Firmware setting.
- Page 5 Service Providers (CSPs) under a limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement. Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_agreement. www.crestron.com/model/6508079 The product warranty can be found at www.crestron.com/warranty.
