Appendix D Communicating with a PC

(The CO 80 requires the purchase of the optional IR to RS232 adaptor (P/N:
589230) for communication with a PC to be possible.)
The CO80 communicates to a PC thru a communications program. The most
commonly used program is Hyperterminal which comes standard on any PC
equipped with a Windows operating system.
Port settings must be set as follows to allow the CO80 to send data streams
to the PC.
Bits Per Second: 9600
Data Bits: 8 Bits
Parity:
Stop Bits: 1
Flow Control: XON/OFF
Setting up a Hyperterminal Session
Access Hyperterminal through the Start button on your control bar.
1. Hyperterminal screen opens
None
2. Setup new connection
45 CO80 V3.1 04/06
