User's Guide
Gas Leak Detector
Model CO52
Introduction
Congratulations on your purchase of the Extech C052 Gas Leak Detector. The CO52
detects the presence of gas and displays concentrations between 0 and 10000 parts per
million (ppm). Careful use of this meter will provide years of reliable service.
Description
Sensor Light Sensor
Specifications
Measurement range
Response Time
Power supply
Battery life
Operating Temperature
Storage Temperature
Operating Humidity
Dimensions
Weight
LCD
On/Off Button
0-10000 ppm
Less than 5 seconds
2 x AA 1.5V
Approx. 50 hours with alkaline battery with no backlight
Approx. 30 hours with backlight operation
o
o
32 to 122
F (0 to 50
C)
o
-22 to 140
F (-30 to 60
5 to 95% RH (non condensing)
1.5 x 10 x 1.1" (38 x 254 x 28mm)
3.5oz (100g)
Battery Compartment (Rear)
o
C)
Advertisement
Related Manuals for Extech Instruments CO52
Summary of Contents for Extech Instruments CO52
-
Page 1: Specifications
Model CO52 Introduction Congratulations on your purchase of the Extech C052 Gas Leak Detector. The CO52 detects the presence of gas and displays concentrations between 0 and 10000 parts per million (ppm). Careful use of this meter will provide years of reliable service. -
Page 2: Digital Display
Batteries 2 AA size batteries are used. The battery compartment is located at the rear of the CO52. Fit the batteries in accordance with the diagram found within the molding. Remaining battery life is indicated by the symbol in the digital display. If the batteries are fresh, 5 segments will be displayed.
