Page 2: Table Of Contents
Table of Contents 1. General 2. Specifications 2.1 Overview SHP550 2.2 Overview SHP650 2.3 Mains Voltage and Protections 2.4 Safety Certifications 2.5 Warranty 3. Package Contents 4. Cable Configuration 4.1 Connectors 4.2 Cable Length 5. Installation 5.1 Installing the Power Supply into a PC Case 5.2 Connecting Mainboard and Graphics Card(s) -
Page 3: General
PCIe Connectors 1x 6+2-Pin PCIe Connector 120 mm Fan 20% Load: Min. 82% Efficiency 50% Load: Min. 85% 100% Load: Min. 82% 2. Specifications 2.1 Overview SHP550 Model No. SHP550 Input Voltage Current Frequency Input (AC) 200 - 240 V... -
Page 4: Mains Voltage And Protections
A two-year warranty is provided for these power supplies. 3. Package Contents Power cord Mounting screws Manual Note: If you are missing any of the items listed above, please contact our customer service immedi- ately: support@sharkoon.com (Germany and Europe) support@sharkoon.com.tw (International) ... -
Page 5: Cable Configuration
4. Cable Configuration 4.1 Connectors 1x 20+4-Pin Mainboard Connector 1x 4+4-Pin CPU Connector 4x SATA Connectors 1x 6+2-Pin PCIe Connector 1x Floppy Connector 3x 4-Pin IDE Connectors ... -
Page 6: Cable Length
4.2 Cable Length 450 mm 1x 20+4-Pin Mainboard Connector 450 mm 1x 4+4-Pin CPU Connector 450 mm 1x 6+2-Pin PCIe Connector 450 mm 150 mm 3x 4-Pin IDE Connectors 150 mm 150 mm 1x Floppy Connectors 450 mm 150 mm 4x SATA Connectors 450 mm 150 mm... -
Page 7: Installing The Power Supply Into A Pc Case
5.1 Installing a Power Supply into a PC Case 1. Insert the power supply into the PC case and place it against the power supply bracket on the rear panel. For additional information, refer to the PC case’s manual. 2. Attach the power supply from the outside of the case using the provided screws. Ensure that the fan and air vents of the built-in power supply are not covered. -
Page 8: Checking All Connections
Do not force to plug the connectors within the incorrect orientation, nor modify any of the components, as this will damage the power supply and other hardware. SHARKOON warranty does not cover damage cause by incorrect handling. 6. Troubleshooting If the power supply does not work properly, please check the following: 1. - Page 9 Legal Disclaimer: For potential loss of data, especially due to inappropriate handling, SHARKOON assumes no liability. All named products and descriptions are trademarks and/or registered trademarks of the respective manufacturers and are accepted as protected. As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to change without prior notice.
