Summary of Contents for Sharkoon SilentStorm Cool Zero 650
- Page 1 Manual...
-
Page 2: Table Of Contents
Content Specifications ....... . . 3 General ....... . . 3 1.2 Package Contents. -
Page 3: Specifications
1. Specifications 1.1 General Power 650, 750 or 850 Watt Warranty 3 Years PCIe Connector 4x 6+2-Pin. 135 mm Fan with Fluid Dynamic Bearing 20% Load: min. 87% Efficiency 50% Load: min. 90% 100% Load: min. 87% 80 PLUS Certification Gold 1.2 Package Contents ... -
Page 4: Model-Specific
1. Specifications 1.3 Model-Specific Model SilentStorm Cool Zero 650 Voltage Current Frequency Input (AC) 100 - 240 V 10 A 50 - 60 Hz Output Voltage (DC) +3.3 V +5 V +12 V -12 V +5 Vsb Max. Output Current... -
Page 5: Safety Standards And Protections
2. Safety Standards and Protections This power supply is designed for a mains voltage of 100 - 240 volts. It complies with CE, FCC and CB safety standards and has the following protection features: Over Power Protection (OPP) If the system demands more power than the specifications allow, the power supply will switch off to protect the electronics from damage. -
Page 6: Installation
3. Installation 3.1 Removal of Existing Power Supply from PC Case If installing into an empty PC case, continue with the section "Installing the Power Supply into a PC Case". For a PC case with an already installed power supply, first remove this from the case. Proceed as follows: 1. -
Page 7: Connection Options
4. Connection Options Because of the fully modular cable system, only the cables are used on the power supply which are actually needed when connecting hardware and peripherals. The complete wiring and the inside of the case thus remain tidy and the air flow is not unnecessarily obstructed. The SilentStorm Cool Zero has the following connection options: 2x Sockets for 24-Pin. -
Page 8: Cable Diagram
2x Adapter Cable (SATA to IDE) Please note: Make sure that only the supplied set of modular cables is used! The use of other cables (e.g., older power supply cables from Sharkoon or cables from other manufacturers) can result in damage to the device. -
Page 9: Connecting
Do not try to force a connector into a socket using the incorrect alignment, nor modify the components, otherwise the power supply and your hardware will be damaged. The SHARKOON warranty does not cover any damage that has been caused by improper handling. -
Page 10: Flexible Cooling Options
7. Flexible Cooling Options The SilentStorm Cool Zero is equipped with two functions for flexibly adjusting the cooling behavior, which are explained below. At the back of the power supply, both functions can be switched on or off via two separate switches. -
Page 11: Various Installation Positions
8. Various Installation Positions 8.1 Power Supply on the Case Bottom Cool air is drawn from underneath the case and transported to the rear out of the housing as waste heat. The air circulation of the power supply is largely separated from the air circula- tion in the rest of the case. -
Page 12: Troubleshooting
5. Pull the power plug out of the wall outlet and leave the power supply without power for approximately 10 minutes! This will cause a reset of the protective circuits. If the system still fails to function, please contact support@sharkoon.com. - Page 13 All named products and descriptions are trademarks and/or registered trademarks of the respective manufactu- rers and are accepted as protected. As a continuing policy of product improvement at SHARKOON, the design and specifications are subject to ch- ange without prior notice. National product specifications may vary.
