Advantech PCM-3117 Startup Manual

PCM-3117 PCI to ISA Bridge Module
Startup Manual

Introduction

The PCM-3117 is PCI to ISA bridge module.
For more and more PCI-104 bus application, there still
have PC104+ module customer used. For all modules can
be compatible, PCM-3117 is important solution. Except
this, PCM-3117 support two COM RS-232/422/485, user
can select the function by jumper setting.
But for OS limitation, user must install PCM-3117 first,
then just can install OS; Or computer can not distinguish
PCM-3117.

Packing list

Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-3117 module
• 1 Start-up manual
• 1 2 x COM port cable
• 1 Signal CABLE 4P to 4P
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCM-3117
Part No. 2006311701
P/N: 1701200220
P/N: 1700001898
2nd Edition
Dec. 2005

Features

PCM-3117 PCI to ISA Bridge Module
• Compatible with PC/104 and PC/104+
• PCI-104 CPU module (PCM-3380) be able to control
PC/104 peripheral (ISA bus)
• Support 2 COM RS-232/422/485
• Support Windows NT 4.0, Windows 98/2000/XP/SE

Specifications

• Controller: ITE IT8888F
• Bus: PC/104(ISA) and PC/104+(PCI)
• Plug & Play: Support Plug & Play automatic detection &
configuration
• PC/104 expansion: 104-pin and 120-pin 16/32-bit
PC104 /Plus module connector
• Operating Voltage: +5 V Only
• Power Consumption: +5 @ 70 mA (Typical)
• Size/Weight: 96 x 90 mm (3.8î x 3.5î). 90 g (0.198 lb)
• Environment: 0 ~ 60× C (operation), -40 ~ 85× (Stor-
age)
• Humidity: 0 ~ 90%
PCM-3117 Startup Manual 1
