Advantech PCM-3116 Startup Manual

PCM-3116 PC/104-Plus 2 Slot mini PCI
Module
Startup Manual

Introduction

The PCM-3116 is a mini PCI interface module that
attaches to the PC/104-Plus connector on your CPU
card or PC/104-Plus CPU module. The PCM-3116
provides 32-bit performance, and PCI bus capability.

Packing list

Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-3116 PC/104 + mini PCI
• 1 Start-up Manual
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our
support website at:
http://service.advantech.com/support
This manual is for the PCM-3116
Part No. 2006311600
1 PCM-3116 Startup Manual

Features

PCM-3116 PC/104-Plus 2 Slot mini PCI Module
• Support 2 mini PCI devices
• High performance(PC/104-Plus)
• Compliant with PCI v2.1

Specifications

• miniPCI Slot: 2 Slot
• miniCPU Card: Type III A/B
• Data Bus 32-Bit data Bus (Compliant with PCI Bus Spec-
ification 2.1)
• PC/104 Expansion: 104-pin and 120-pin 16/32-bit PC/
104-Plus module connector
• PCI interface 3.3V interface ( 5V tolerant)
• Power Requirements:+5V, +/- 5% tolerance on power
supply
• Size/Weight: 96mm x 90mm(3.8" x 3.5"), 0.094kg
(0.207lb)
• Temperature Operating: 0~60°C(32~140°F)
-40~85°C(-40~185°F)
• Operating Humidity: 0%~90% relative humidity, non-con-
densing.
1st Edition
August 2004
Storage:
P/N:2006311600
