** Please make sure you have all parts indicated below prior to assembly.
Assembly Steps:
1. Place console top (D) upside down on a soft surface to prevent from scratching top.
2. Attach posts (C) to top in a clockwise direction (See diagram 1).
3. Put bottom panel (B) on posts (C); insert bun feet (A)to posts through the bottom panel in a
clockwise direction (See diagram 2).
4. Turn the console upright.
ASSEMBLY INSTRUCTION
Item#:5048-85122 THREE DRAWER THIN CONSOLE
B
D
NO.
HARDWARE LIST
E
PLASTIC ANCHOR
F
A
C
C
D
1/2
HOOK
A
B
Diagram 2
C
Diagram 1
Q'TY
2
2
Advertisement
Table of Contents
Related Manuals for Hooker Furniture 5048-85122
Summary of Contents for Hooker Furniture 5048-85122
- Page 1 ASSEMBLY INSTRUCTION Item#:5048-85122 THREE DRAWER THIN CONSOLE ** Please make sure you have all parts indicated below prior to assembly. Q'TY HARDWARE LIST HOOK PLASTIC ANCHOR Diagram 2 Diagram 1 Assembly Steps: 1. Place console top (D) upside down on a soft surface to prevent from scratching top.
- Page 2 ANTI-TIP RESTRAINTS： Diagram 3 1. Place the console in a desired location. Mark wall with pencil. 2. Drill two holes into the wall using 1/4”drill bit and insert the plastic anchors (F). 3. Screw hook (E) into plastic anchor (F). Check and make sure the plastic anchor (F) is securely held in the wall.
