*** Please make sure you have all parts indicated below prior to assembly.
HARDWARE LIST Q'TY
NO
A
Flat Washer
B
Lock Washer
C
Bolt
D
Allen Wrench
E
Nut
F
Wrench
G
Full Threaded Bolt
H
Wood Dowel
Diagram 2
Assembly steps:
1. Attach the mounting bridge (J) to the post (K) with 2 flat washers (A), 2 lock washers (B) and
2 bolts (C). Tighten all bolts securely with allen wrench (D) (See diagram 1).
2. Insert 3 full threaded bolts (G),3 wood dowels(H) to legs, assemble legs to post by using 3 flat
washers (A), 3 lock washers (B), 3 nuts(E) and turn with wrench (F) in a clockwise direction
(see digram2).
ASSEMBLY INSTRUCTION
Item#: 500-50-828 Round Accent Table
8
8
5
1
3
1
3
3
G
H
1/2
2
Diagram 1
Diagram 3
