Industrial Electronic Devices
CHARACTERISTICS:
The HD67B81-xxx-A1/B2 is a BACnet Slave / PROFINET Master converter.
It allows the following characteristics:
Triple isolation between RS485 - Power Supply, RS485 - Ethernet, Ethernet - Power Supply;
Up to 1500 bytes in reading and 1500 bytes in writing;
Two-directional information between PROFINET and BACnet;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67B81 software on your PC in order to perform the following:
Define the parameter of the BACnet;
Define the parameter of the PROFINET;
Define the list of PROFINET slaves connected to the converter;
Define the list of BACnet objects available for reading and writing;
Export the EDE file for BACnet;
Update the device.
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual BACnet Slave / PROFINET Master
Document code: MN67B81_ENG
INFO:
www.adfweb.com
Revision 1.000
Page 8 of 32
Phone +39.0438.30.91.31
