Rev. 01 Desiccant Flex Dryer DFD Side 13 af 40
Installation of compressed air 1/4" BSPF (5-7 Bar)*
Connection for water supply 1/2" RG (max. 8 Bar)**
* Where a pneumatic slide valve (optional) is fi tted under the DH hoppers.
** HT/LT models are fitted with a cooler which needs connection to water. Water inlet (27) and
water outlet (28) (½" RG).
Maximum pressure: 6 bar
Water volume: 250 l/h
Cooling water temperature in/out: 15/40°C
R1070_R01
