PILOT'S OPERATING HANDBOOK
AND FAA APPROVED
AIRPLANE FLIGHT MANUAL
for the CIRRUS DESIGN SR22
Aircraft Serials 4435 and Subsequent with
Cirrus Perspective+ Avionics System
FAA Approved in Normal Category based on 14 CFR 23. This document
must be carried in the airplane at all times and be kept within the reach of
the pilot during all flight operations.
THIS MANUAL INCLUDES THE MATERIAL REQUIRED TO BE FURNISHED TO
THE PILOT BY 14 CFR 23 AND ADDITIONAL INFORMATION PROVIDED BY
CIRRUS AIRCRAFT AND CONSTITUTES THE FAA APPROVED AIRPLANE
FLIGHT MANUAL.
Model - Serial #:
Registration #:
P/N 13772-006
Cover Page-i
Reissue A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR22 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cirrus SR22

Summary of Contents for Cirrus SR22

  • Page 1 THIS MANUAL INCLUDES THE MATERIAL REQUIRED TO BE FURNISHED TO THE PILOT BY 14 CFR 23 AND ADDITIONAL INFORMATION PROVIDED BY CIRRUS AIRCRAFT AND CONSTITUTES THE FAA APPROVED AIRPLANE FLIGHT MANUAL. Model - Serial #:...
  • Page 2 Copyright © 2019 - All Rights Reserved Cirrus Design Corporation 4515 Taylor Circle Duluth, MN 55811 Cover Page-ii P/N 13772-006 Reissue A...
  • Page 3 IRRUS ESIGN IRPLANE LIGHT ANUAL SR22 FFECTIVE AGES List of Effective Pages Use this page to determine the current effective date for each page in the AFM. Supplements are issued individually and are controlled by the Log of Supplements Page in Section 9.
  • Page 4 IRRUS ESIGN IRPLANE LIGHT ANUAL SR22 FFECTIVE AGES List of Effective Pages (Cont.) Page Status Page Status Page Status 3A-23 Reissue A 5-22 Reissue A 7-25 Reissue A 3A-24 Reissue A 5-23 Reissue A 7-26 Reissue A 3A-25 Reissue A...
  • Page 5 IRRUS ESIGN IRPLANE LIGHT ANUAL SR22 FFECTIVE AGES List of Effective Pages (Cont.) Page Status Page Status Page Status 7-80 Reissue A 10-5 Reissue A 7-81 Reissue A 10-6 Reissue A 7-82 Reissue A 10-7 Reissue A 7-83 Reissue A...
  • Page 6 IRRUS ESIGN IRPLANE LIGHT ANUAL SR22 FFECTIVE AGES Intentionally Left Blank LOEP-4 P/N 13772-006 Reissue A...
  • Page 7 SR22 OREWORD Foreword This Pilot’s Operating Handbook (POH) has been prepared by Cirrus to familiarize operators with the aircraft. Read this POH carefully. It provides operational procedures that will ensure the operator obtains the perfor- mance published in the manual, data designed to allow the most efficient and safe use of the airplane, and basic information to assist in maintaining the airplane in airworthy condition.
  • Page 8 “Original Issue” at this location. In the event that the majority of pages in the POH are revised, Cirrus may determine that it is more effective to reissue the POH. Reissued pages will be identified by the word “Reissue”...
  • Page 9 POH. Section 9 includes a “Log of Supplements” page preceding all Cirrus Supplements produced for this airplane. The “Log of Supplements” page can be utilized as a “Table of Contents” for Section 9. If the airplane is modified at a non-Cirrus facility through an STC or other approval method, it is the owner’s responsibility to ensure that the proper supple-...
  • Page 10 RONTMATTER IRRUS ESIGN SR22 ARNINGS AUTIONS OTES Intentionally Left Blank Frontmatter-4 P/N 13772-006 Reissue A...

  • Page 11: Table Of Contents

    1: G IRRUS ESIGN ECTION ENERAL SR22 Section 1: General Table of Contents Introduction..................3 The Airplane ..................7 Engine ....................7 Propeller .................... 7 Hartzell .................... 7 McCauley ..................7 MT Propeller ..................7 Fuel ....................7 Approved Fuel Grades ..............7 Oil ......................
  • Page 12 1: G ECTION ENERAL IRRUS ESIGN SR22 Intentionally Left Blank P/N 13772-006 Reissue A...

  • Page 13: Introduction

    1: G IRRUS ESIGN ECTION ENERAL SR22 NTRODUCTION Introduction This section contains information of general interest to pilots and owners. You will find the information useful in acquainting yourself with the airplane, as well as in loading, fueling, sheltering, and handling the airplane during ground operations.
  • Page 14 1: G ECTION ENERAL IRRUS ESIGN SR22 NTRODUCTION Figure 1-1: Airplane Three View 26.0 ft 7.92 m 8.9 ft 2.71 m NOTE: • Wing span includes position and strobe lights. 38.3 ft 11.67 m 78 inches 3-BLADE 198 cm 9.1 ft SR22_FM01_5313 2.8 m...
  • Page 15 1: G IRRUS ESIGN ECTION ENERAL SR22 NTRODUCTION Figure 1-2: Airplane Interior Dimensions 49.3" 39.8" Fuselage Station 49.7" 38.5" 27.0" 16.0" 20.0" 32.0" 10.5" 39.0" 33.4" 20.0" 33.3" 5.0" 21.0" CABIN DOOR BAGGAGE DOOR OPENING OPENING SR22_FM01_5315 Location Length Width...
  • Page 16 1: G ECTION ENERAL IRRUS ESIGN SR22 NTRODUCTION Figure 1-3: Turning Radius GROUND TURNING CLEARANCE 24.3 ft. (7.41 m) RADIUS FOR WING TIP 7.0 ft. (2.16 m) RADIUS FOR NOSE GEAR 0.5 ft. (0.15 m) RADIUS FOR INSIDE GEAR 9.1 ft.

  • Page 17: The Airplane

    1: G IRRUS ESIGN ECTION ENERAL SR22 IRPLANE The Airplane Engine Number of Engines .................... 1 Number of Cylinders ..................6 Engine Manufacturer ............Continental Motors Engine Model ..................IO-550-N Engine Metering ................Fuel Injected Engine Cooling .................. Air Cooled Engine Type..........Horizontally Opposed, Direct Drive Horsepower Rating............

  • Page 18: Oil

    1: G ECTION ENERAL IRRUS ESIGN SR22 IRPLANE Oil Capacity (Sump)............8 U.S. Quarts (7.6 L) Refer to Section 2, Powerplant Limitations, for approved oil grades. Maximum Certificated Weights Maximum Gross for Takeoff..........3600 lb (1633 Kg) Maximum Zero Fuel Weight..........3400 lb (1542 Kg) Maximum Baggage Compartment Loading......

  • Page 19: Terminology

    1: G IRRUS ESIGN ECTION ENERAL SR22 IRPLANE Terminology Table 1: General Airspeed Terminology General Airspeed Terminology Terminology Definition KCAS Knots Calibrated Airspeed is the indicated airspeed corrected for position and instrument error. Calibrated airspeed is equal to true airspeed in standard atmosphere at sea level.
  • Page 20 1: G ECTION ENERAL IRRUS ESIGN SR22 IRPLANE General Airspeed Terminology (Continued) Terminology Definition Stalling Speed is minimum steady flight speed at which S 50% the aircraft is controllable with 50% flaps. Stalling Speed is the minimum steady flight speed at...
  • Page 21 1: G IRRUS ESIGN ECTION ENERAL SR22 IRPLANE Meteorological Terminology (Continued) Terminology Definition Mean Sea Level is the average height of the surface of the sea for all stages of tide. In this Handbook, altitude given as MSL is the altitude above the mean sea level. It is the altitude read from the altimeter when the altimeter’s barometric adjustment has been set to the...
  • Page 22 1: G ECTION ENERAL IRRUS ESIGN SR22 IRPLANE Table 4: Performance and Flight Planning Terminology Performance and Flight Planning Terminology Terminology Definition One “g” is a quantity of acceleration equal to that of earth’s gravity. Demonstrated Demonstrated Crosswind Velocity is the velocity of...
  • Page 23 1: G IRRUS ESIGN ECTION ENERAL SR22 IRPLANE Table 5: Weight and Balance Terminology Weight and Balance Terminology Terminology Definition Reference Datum Reference Datum is an imaginary vertical plane from which all horizontal distances are measured for balance purposes. Tare Tare is the weight of all items used to hold or position the airplane on the scales for weighing.
  • Page 24 1: G ECTION ENERAL IRRUS ESIGN SR22 IRPLANE Weight and Balance Terminology (Continued) Terminology Definition Maximum Ramp Maximum Ramp Weight is the maximum weight Weight approved for ground maneuver and includes the weight of the fuel used for startup and taxi.
  • Page 25 Maximum Occupancy................ 19 Child Restraint System ..............19 Systems and Equipment Limits ............20 Cirrus Perspective+ Integrated Avionics System ......20 L-3 Stormscope Weather Information System (Optional)....23 Max Viz Enhanced Vision System (Optional) ........23 MD302 Standby Attitude Module (Optional)........24 Air Conditioning System (Optional) ..........
  • Page 26 2: L ECTION IMITATIONS IRRUS ESIGN SR22 Flap Limitations ................24 Paint ....................24 Cirrus Airframe Parachute System (CAPS) ........24 Other Limitations ................24 Smoking................... 24 Placards..................... 25 P/N 13772-006 Reissue A...

  • Page 27: Introduction

    2: L IRRUS ESIGN ECTION IMITATIONS SR22 NTRODUCTION Introduction The limitations included in this Section of the Pilot’s Operating Handbook (POH) are approved by the Federal Aviation Administration. This section provides operating limitations, instrument markings, and basic placards required by regulation and necessary for the safe operation of the aircraft and its standard systems and equipment.

  • Page 28: Airspeed Limitations

    2: L ECTION IMITATIONS IRRUS ESIGN SR22 IRSPEED IMITATIONS Airspeed Limitations The indicated airspeeds in the following table are based on Section 5, Airspeed Calibration - Normal Static Source Table. When using the alter- nate static source, allow for the airspeed calibration variations between the normal and alternate static sources.

  • Page 29: Airspeed Indicator Markings

    2: L IRRUS ESIGN ECTION IMITATIONS SR22 IRSPEED NDICATOR ARKINGS Airspeed Indicator Markings The airspeed indicator markings are based on Section 5, Airspeed Calibra- tion - Normal Static Source Table. When using the alternate static source, allow for the airspeed calibration variations between the normal and alter- nate static sources.

  • Page 30: Powerplant Limitations

    2: L ECTION IMITATIONS IRRUS ESIGN SR22 OWERPLANT IMITATIONS Powerplant Limitations Engine Continental Motors ................IO-550-N Power Rating ..............310 HP @ 2700 RPM Maximum RPM ..................2700 RPM Oil Temperature............240 °F (116 °C) maximum Minimum Oil Temperature for Takeoff........75 °F (24 °C) Oil Pressure: Minimum .....................10 psi...
  • Page 31 2: L IRRUS ESIGN ECTION IMITATIONS SR22 OWERPLANT IMITATIONS • N • The correct grade of oil to be used is based on environmental conditions. If the aircraft is going to be flown into an area that is much warmer or colder than the aircraft is usually operated in, use a different viscosity of oil.

  • Page 32: Propeller

    2: L ECTION IMITATIONS IRRUS ESIGN SR22 OWERPLANT IMITATIONS Propeller Hartzell Propeller Type ............ Constant Speed, Three Blade Model Number............PHC-J3YF-1RF/F7694(B) Diameter................78.0” (76.0” Minimum) Model Number........... PHC-J3YF-1RF/F7693DF(B) Diameter.................78.0" (76.0" Minimum) McCauley Propeller Type ............ Constant Speed, Three Blade Model Number.............. D3A34C443/78CYA-0 Diameter................78.0”...

  • Page 33: Engine Instrument Markings & Annunciations

    2: L IRRUS ESIGN ECTION IMITATIONS SR22 OWERPLANT IMITATIONS Engine Instrument Markings & Annunciations The following describes the engine instrument markings. Associated Warning and Caution Annunciations are shown in capitalized text. Powerplant Yellow Green Yellow Arc/Bar Arc/Bar Arc/Bar Arc/Bar Arc/Bar...

  • Page 34: Fuel

    2: L ECTION IMITATIONS IRRUS ESIGN SR22 OWERPLANT IMITATIONS Fuel Yellow Green Yellow Arc/Bar Arc/Bar Arc/Bar Arc/Bar Arc/Bar Instrument Minimum Maximum (Range & Units) Normal Minimum Caution Caution Maximum Range Range Range Fuel Flow –– –– –– –– 0 – 25 (0 –...

  • Page 35: Electrical

    2: L IRRUS ESIGN ECTION IMITATIONS SR22 OWERPLANT IMITATIONS Electrical Yellow Green Yellow Arc/Bar Arc/Bar Arc/Bar Arc/Bar Arc/Bar Instrument Minimum Maximum (Range & Units) Normal Minimum Caution Caution Maximum Range Range Range Essential Bus Volts 0 – 24.4 –– 24.5 – 32 ––...

  • Page 36: Center Of Gravity Limits

    2: L ECTION IMITATIONS IRRUS ESIGN SR22 ENTER OF RAVITY IMITS Center of Gravity Limits Reference Datum ..........100 inches forward of firewall Forward ................. Refer to Figure 2-1 Aft................... Refer to Figure 2-1 Figure 2-1: Center of Gravity Envelope 3600 21.1% MAC...

  • Page 37: Maneuver Limits

    60°. • N • Because the aircraft has not been certified for spin recovery, the Cirrus Airframe Parachute System (CAPS) must be deployed if the airplane departs controlled flight. Refer to Section 3, Inadver- tent Spin Entry.
  • Page 38 2: L ECTION IMITATIONS IRRUS ESIGN SR22 INDS OF PERATION Kinds of Operation System, Instrument Remarks, Notes, and/or Equipment and/or Exceptions Night Night PLACARDS AND MARKINGS Airplane Flight Manual (Included w/ POH) COMMUNICATIONS VHF COM ELECTRICAL POWER Battery 1 Battery 2...
  • Page 39 2: L IRRUS ESIGN ECTION IMITATIONS SR22 INDS OF PERATION Kinds of Operation System, Instrument Remarks, Notes, and/or Equipment and/or Exceptions Night Night Pitch Trim Indicator Pitch Trim System Roll Trim Indicator Roll Trim System Stall Warning System FUEL Auxiliary Fuel Pump...
  • Page 40 2: L ECTION IMITATIONS IRRUS ESIGN SR22 INDS OF PERATION Kinds of Operation System, Instrument Remarks, Notes, and/or Equipment and/or Exceptions Night Night MFD Backlighting *Required if PFD Backlighting Fails. Engine Indicators Must Be Shown in Backup Mode. Anticollision Lights...
  • Page 41 2: L IRRUS ESIGN ECTION IMITATIONS SR22 INDS OF PERATION Kinds of Operation System, Instrument Remarks, Notes, and/or Equipment and/or Exceptions Night Night PFD Attitude Indication PFD Heading Indication PFD Slip/Skid Indication Turn Coordinator Altitude Encoder As required per procedure.

  • Page 42: Icing

    2: L ECTION IMITATIONS IRRUS ESIGN SR22 IMITS Kinds of Operation System, Instrument Remarks, Notes, and/or Equipment and/or Exceptions Night Night Oil Quantity Indicator (Dipstick) Oil Temperature Indication Engine Speed SPECIAL EQUIPMENT Cirrus Airframe Parachute (CAPS) Icing Flight into known icing conditions is prohibited.

  • Page 43: Altitude Limits

    Environmental Conditions For operation of the airplane below an outside air temperature of -10°F (-23°C), use of cowl inlet covers approved by Cirrus Design and listed in the Winterization Kit AFM Supplement P/N 13772-118 is required. Maximum Occupancy Occupancy of this airplane is limited to “4+1” persons, the pilot and four passengers.

  • Page 44: Systems And Equipment Limits

    Systems and Equipment Limits Cirrus Perspective+ Integrated Avionics System 1. The appropriate revision of the Cirrus Perspective+ Cockpit Reference Guide (p/n 190-02184-XX, where X can be any digit from 0 to 9) must be immediately available to the pilot during flight. The system software version stated in the reference guide must be appropriate for the system software version displayed on the equipment.
  • Page 45 RNAV approaches must be conducted utilizing the GPS sensor. g) The Perspective+ Integrated Avionics System is compliant with AC 90-100A. As such, the Cirrus Perspective+ system is eligible to fly RNAV 'Q' or 'T' routes, RNAV SID/STAR/ODPs and eligible to use RNAV substitution or RNAV alternate means of navigation (US Only).
  • Page 46 2: L ECTION IMITATIONS IRRUS ESIGN SR22 YSTEMS AND QUIPMENT IMITS 5. Navigation using the Perspective+ Integrated Avionics System is not authorized in the following geographic areas: a) north of 70° North latitude (northern polar region), b) south of 70° South latitude (southern polar region), c) north of 65°...

  • Page 47: Stormscope Weather Information System (Optional)

    2: L IRRUS ESIGN ECTION IMITATIONS SR22 YSTEMS AND QUIPMENT IMITS 13.The installed ADS-B OUT system, including GTX 335 Mode S Tran- sponder and GTX 345 Mode S UAT in Transponder (optional), has been shown to meet the equipment requirements of 14 CFR 91.227.

  • Page 48: Md302 Standby Attitude Module (Optional)

    Airplane Main- tenance Manual. Refer to Airplane Maintenance Manual (AMM), Chapter 51, for specific paint requirements. Cirrus Airframe Parachute System (CAPS) Maximum Demonstrated Deployment Speed ......140 KIAS • N •...

  • Page 49: Placards

    2: L IRRUS ESIGN ECTION IMITATIONS SR22 LACARDS Placards Figure 2-3: Placards (1 of 6) Engine compartment, inside oil filler access: ENGINE OIL GRADE ABOVE 40°F (4°C) SAE 50, 20W50, OR 20W60 BELOW 40°F (4°C) SAE 30 OR 10W30, 15W50, OR 20W50...
  • Page 50 2: L ECTION IMITATIONS IRRUS ESIGN SR22 LACARDS Figure 2-3: Placards (2 of 6) Left fuselage, on external power supply door: EXTERNAL POWER 28 V DC Doors, adjacent to latch: OPEN Wing, adjacent to fluid filler cap: TKS ICE PROTECTION FLUID USE ONLY AL-5 (DTD-406B) FLUID 4.0 US GALLONS (15.1 LITERS)
  • Page 51 2: L IRRUS ESIGN ECTION IMITATIONS SR22 LACARDS Figure 2-3: Placards (3 of 6) Engine control panel: CREW SEATS MUST BE LOCKED IN POSITION AND CONTROL HANDLES FULLY DOWN BEFORE FLIGHT ALTITUDE GPH 16000 ----- 17 12000 ----- 18 8000 ----- 21...
  • Page 52 2: L ECTION IMITATIONS IRRUS ESIGN SR22 LACARDS Figure 2-3: Placards (4 of 6) Cabin Door Window, lower edge, centered, applied upside down: RESCUE: FRACTURE AND REMOVE WINDOW Bolster Switch Panel, left edge: THIS AIRCRAFT IS CERTIFIED FOR THE FOLLOWING FLIGHT OPERATIONS:...
  • Page 53 2: L IRRUS ESIGN ECTION IMITATIONS SR22 LACARDS Figure 2-3: Placards (5 of 6) Instrument Panel, center: DISPLAY BACKUP Baggage Compartment, aft edge: ELT LOCATED BEHIND BULKHEAD REMOVE CARPET AND ACCESS PANEL Instrument Panel: FASTEN SEATBELTS • NO SMOKING Cabin Window, above door latch:...
  • Page 54 MUST BE WORN AT ALL TIMES USE OF THIS DEVICE COULD RESULT IN INJURY OR DEATH MAXIMUM DEMONSTRATED DEPLOYMENT SPEED 140 KIAS CIRRUS AIRFRAME PARACHUTE SYSTEM ACTIVATION PROCEDURE 1. THIS COVER..........REMOVE 2. ACTIVATION HANDLE..PULL STRAIGHT DOWN BOTH HANDS, MAXIMUM FORCE, STEADY PULL DO NOT JERK HANDLE 3.
  • Page 55 3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 Section 3: Emergency Procedures Table of Contents Introduction..................5 Crew Alert System (CAS) Messaging ..........5 Warnings ..................5 CAPS Guidance ................5 Preflight Planning ................6 Preflight Inspections/Maintenance ............ 6 Methodology..................6 Maintain Aircraft Control ..............
  • Page 56 3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 Emergency Landing w/o Power............19 Ditching.................... 20 Landing Without Elevator Control............ 20 Engine System Emergencies ............21 Engine Partial Power Loss .............. 21 OIL PRESS Warning ............... 23 OIL TEMP Warning ................. 23 CHT Caution and Warning ..............
  • Page 57 3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 Emergency Ground Egress ............41 CAPS Deployment ................ 42 P/N 13772-006 Reissue A...
  • Page 58 3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 Intentionally Left Blank P/N 13772-006 Reissue A...

  • Page 59: Introduction

    2647.N3 or later. CAPS Guidance All Cirrus aircraft are equipped with a pilot or passenger activated ballistic airframe parachute system. The system is capable of lowering the aircraft and occupants safely to the ground for life threatening emergencies. CAPS provides pilots and passengers an alternative means of handling various life threatening emergency situations.

  • Page 60: Preflight Planning

    ESIGN SR22 NTRODUCTION option for occupants as compared to continued flight or traditional countermeasures. Pilots flying Cirrus aircraft must be properly trained and familiar with CAPS guidance, limitations, and operating procedures. Refer to Section 10, Cirrus Airframe Parachute System (CAPS), for CAPS deployment and guidance information.

  • Page 61: Take Appropriate Action

    MHz. If the display is available, it will also show it in the “Active” frequency window. The Cirrus Airframe Parachute System (CAPS) should be activated in the event of a life-threatening emergency where CAPS deployment is deter- mined to be safer than continued flight and landing.

  • Page 62: Memory Items

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 NTRODUCTION Memory Items Checklist steps emphasized by a rectangular enclosure, such as the example below, should be memorized for accomplishment without reference to the procedure, due to the nature of their urgency.

  • Page 63: Land As Soon As Possible

    IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 NTRODUCTION Land as Soon as Possible Land without delay at the first site at which a safe landing can be made. Continued flight beyond an available airfield at which a safe landing can be made will result in increased risk and shall not be attempted.

  • Page 64: Airspeeds For Emergency Operations

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 IRSPEEDS FOR MERGENCY PERATIONS Airspeeds for Emergency Operations Maneuvering Speed 3600 lb (1633 kg).................. 140 KIAS Best Glide (Gear and Flaps: UP) All Weights ..................... 92 KIAS Emergency Landing Flaps UP ....................90 KIAS Flaps 50% ....................

  • Page 65: Engine Failures

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 NGINE AILURES Engine Failures Engine Failure On Takeoff - Low Altitude 1. Best Glide or Landing Speed ............ESTABLISH 2. Mixture..................... CUTOFF 3. Fuel Selector....................OFF 4. Ignition Switch ..................OFF 5. Flaps ..................AS REQUIRED ◆...

  • Page 66: Engine Failure In Flight

    If altitude or terrain does not permit a safe landing, CAPS deployment may be required. Refer to Section 10, Cirrus Airframe Parachute System (CAPS) for CAPS deployment scenarios and landing consider- ations.

  • Page 67: Airstart

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 IRSTART Airstart Engine Airstart 1. BAT 1 and BAT 2 Switches ..............ON 2. Power Lever ................OPEN ½ INCH 3. Mixture................RICH, AS REQ’D 4. Fuel Selector..............SWITCH TANKS 5. Ignition Switch ..................BOTH 6.

  • Page 68: Smoke And Fire

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 MOKE AND Smoke and Fire Cabin Fire In Flight 1. BAT 1, ALT 1, and ALT 2 Switches......OFF, AS REQUIRED 2. Fire Extinguisher ................ ACTIVATE 3. AVIONICS Switch ...................OFF 4. All other switches ..................OFF 5.

  • Page 69: Engine Fire In Flight

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 MOKE AND (Continued) • N • If the airplane is in IMC conditions, turn ALT 1, ALT 2, and BAT 1 switches OFF. Power from battery 2 will keep the Primary Flight Display operational for approximately 30 minutes.

  • Page 70: Wing Fire In Flight

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 MOKE AND Wing Fire In Flight 1. Pitot Heat Switch..................OFF 2. Navigation Light Switch ................OFF 3. Landing Light....................OFF 4. Strobe Light Switch ..................OFF 5. If possible, side slip to keep flames away from fuel tank and cabin.

  • Page 71: Smoke And Fume Elimination

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 MERGENCY ESCENT Smoke and Fume Elimination 1. Air Conditioner (if installed) ..............OFF 2. Temperature Selector ................COLD 3. Vent Selector........FEET/PANEL/DEFROST POSITION 4. Airflow Selector........SET AIRFLOW TO MAXIMUM ◆ If source of smoke and fume is firewall forward: a.

  • Page 72: Glide

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 LIDE Glide Conditions Example Power Altitude 10,000 ft. AGL Propeller Windmilling Airspeed Best Glide Flaps 0% (UP) Glide Distance 14.5 NM Wind Zero Best Glide Speed 3600 lb (1633 kg)..................92 KIAS Figure 3-1: Maximum Glide Ratio ~ 8.8 : 1...

  • Page 73: Forced Landings

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 ORCED ANDINGS Forced Landings Emergency Landing w/o Power 1. Best Glide Speed.................ESTABLISH 2. Radio..TRANSMIT (121.5 MHz) MAYDAY GIVING LOCATION AND INTENTIONS 3. Transponder .................SQUAWK 7700 4. Power Lever .................... IDLE 5. Mixture..................... CUTOFF 6.

  • Page 74: Ditching

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 ORCED ANDINGS Ditching 1. Radio ..TRANSMIT (121.5 MHz) MAYDAY GIVING LOCATION AND INTENTIONS 2. Transponder................. SQUAWK 7700 3. CAPS .................... ACTIVATE 4. Airplane ..................EVACUATE 5. Flotation Devices....INFLATE WHEN CLEAR OF AIRPLANE Procedure Complete •...

  • Page 75: Engine System Emergencies

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 NGINE YSTEM MERGENCIES Engine System Emergencies Engine Partial Power Loss 1. Air Conditioner (if installed) ..............OFF 2. Fuel Pump................... BOOST 3. Fuel Selector..............SWITCH TANKS 4. Mixture....CHECK APPROPRIATE FOR FLIGHT CONDITIONS 5. Power Lever ..................SWEEP 6.
  • Page 76 3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 NGINE YSTEM MERGENCIES (Continued) • N • Low oil pressure may be indicative of an imminent engine failure. OIL PRESS Warning Checklist in this Section for special procedures with low oil pressure.

  • Page 77: Oil Press Warning

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 NGINE YSTEM MERGENCIES OIL PRESS Warning OIL PRESS Oil Pressure Out of Range 1. Oil Pressure Gauge ................CHECK ◆ If pressure low / high: a. Power..REDUCE TO MINIMUM FOR SUSTAINED FLIGHT b.

  • Page 78: Cht Caution And Warning

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 NGINE YSTEM MERGENCIES CHT Caution and Warning High Cylinder Head Temperature ◆ If on ground: a. Power Lever ................REDUCE b. Annunciations and Engine Temperatures .......MONITOR ❍ If Caution or Warning annunciation is still illuminated: (1)Power Lever..........MINIMUM REQUIRED...

  • Page 79: Propeller System Emergencies

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 ROPELLER YSTEM MERGENCIES Propeller System Emergencies RPM Warning Engine Speed High 1. Tachometer..................CHECK ◆ If engine speed normal: a. If on ground........CORRECT PRIOR TO FLIGHT b. If in flight ............CONTINUE, MONITOR Procedure Complete ◆...

  • Page 80: Fuel System Emergencies

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 YSTEM MERGENCIES Fuel System Emergencies FUEL FLOW Warning FUEL FLOW High Fuel Flow ◆ If on ground: a. Correct prior to flight. Procedure Complete ◆ If in flight: a. Mixture..................ADJUST Adjust engine operation to correct condition. Check engine instru- ments to verify HIGH FLOW Warning is not erroneous, i.e.

  • Page 81: Fuel Low Right Warning

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 YSTEM MERGENCIES FUEL LOW RIGHT Warning FUEL LOW RIGHT Low Fuel Quantity in Right Tank 1. Fuel Quantity Gauges............... CHECK 2. Fuel Pump................... BOOST 3. Fuel Selector................LEFT TANK Procedure Complete • N •...

  • Page 82: Fuel Imbalance Warning

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 YSTEM MERGENCIES FUEL IMBALANCE Warning FUEL IMBALANCE Fuel Imbalance 1. Fuel Quantity Gauges ...............CHECK 2. Fuel Pump ...................BOOST a. If the Boost Pump is already in use for vapor suppression, pump should be left in this position for tank switch.

  • Page 83: Electrical System Emergencies

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 LECTRICAL YSTEM MERGENCIES Electrical System Emergencies M BUS 1 Warning M BUS 1 High Voltage on Main Bus 1 1. ALT 1 Switch ..................CYCLE 2. M Bus 1 Voltage (M1) ..............CHECK ◆...

  • Page 84: M Bus 2 Warning

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 LECTRICAL YSTEM MERGENCIES M BUS 2 Warning M BUS 2 High Voltage on Main Bus 2 1. Main Bus 1 Voltage (M1)..............CHECK ◆ If M Bus 1 Voltage is greater than 32 volts: a.

  • Page 85: Ess Bus Warning

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 LECTRICAL YSTEM MERGENCIES ESS BUS Warning ESS BUS High or Low Voltage on Essential Bus 1. Essential Bus Voltage (ESS)............. CHECK ◆ If Essential Bus Voltage is greater than 32 Volts: a. Main Bus 1 and Main Bus 2 Voltages (M1 and M2) ..... CHECK b.

  • Page 86: Environmental System Emergencies

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 NVIRONMENTAL YSTEM MERGENCIES Environmental System Emergencies CO LVL HIGH Warning CO LVL HIGH Carbon Monoxide Level High 1. Air Conditioner (if installed)......NOT IN RECIRC MODE 2. Temperature Selector................COLD 3. Vent Selector........FEET/PANEL/DEFROST POSITION 4.

  • Page 87: Oxygen System Emergencies

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 XYGEN YSTEM MERGENCIES Oxygen System Emergencies OXYGEN FAULT Warning OXYGEN FAULT Oxygen System Fault - Above 12,500 Ft 1. Oxygen Flow Rate ................CHECK ◆ If no flow: a. Initiate Emergency Descent to below 12,500 ft: (1)Power Lever ................

  • Page 88: Oxygen Qty Warning

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 XYGEN YSTEM MERGENCIES OXYGEN QTY Warning OXYGEN QTY Oxygen Quantity Low 1. Oxygen Pressure and Flow Rate............CHECK 2. Initiate Normal Descent (non-emergency) below 12,500 ft. 3. Oxygen Flow Rate ...............MONITOR ◆ Below 12,500 ft: a.

  • Page 89: Integrated Avionics System Emergencies

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 NTEGRATED VIONICS YSTEM MERGENCIES Integrated Avionics System Emergencies A “Red X” through any electronic display field, such as COM frequencies, NAV frequencies, or engine data, indicates that display field is not receiving valid data.

  • Page 90: Pfd Display Failure

    The aircraft is not approved for spins, and has not been certified for traditional spin recovery characteristics. The only approved and demonstrated method of spin recovery is activation of the Cirrus Airframe Parachute System (see CAPS Deployment Checklist, this section). Because of this, if the aircraft enters a spin, CAPS must be deployed immediately.

  • Page 91: Spin Spin Spin Warning

    The aircraft is not approved for spins, and has not been certified for traditional spin recovery characteristics. The only approved and demonstrated method of spin recovery is activation of the Cirrus Airframe Parachute System (see CAPS Deployment Checklist, this section). Because of this, if the aircraft enters a spin, CAPS must be deployed immediately.

  • Page 92: Inadvertent Spiral Dive During Imc Flight

    • N • In all cases, if the aircraft enters an unusual attitude from which recovery is not assured, immediately deploy CAPS. Refer to Section 10, Cirrus Airframe Parachute System (CAPS) for CAPS deployment information. 3-38 P/N 13772-006 Reissue A...

  • Page 93: Other Emergencies

    3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 THER MERGENCIES Other Emergencies Power Lever Linkage Failure 1. Power Lever Movement ..............VERIFY 2. Power ..................SET IF ABLE 3. Flaps ..................SET IF NEEDED 4. Mixture ........AS REQUIRED (FULL RICH TO CUTOFF) 5.

  • Page 94: Brake Temp Warning

    3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 THER MERGENCIES BRAKE TEMP Warning BRAKE TEMP Left/Right Brake Over-Temperature Annunciation 1. Stop aircraft and allow the brakes to cool. Procedure Complete • WARNING • Do not set parking brake unless required for safety.
  • Page 95 3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 THER MERGENCIES (Continued) c. Flight..................CONTINUE (1)Engine start will not be available at destination. Procedure Complete • WARNING • Use caution after shutdown if STARTER circuit breaker required pull (failed relay or solenoid). If breaker is unknowingly or unintentionally reset, starter will instantly engage if Battery 1 power is supplied;...
  • Page 96 – a “chin-up” type pull ensures successful activation. • N • The Cirrus Airframe Parachute System (CAPS) should be acti- vated immediately in the event of a spin. It should also be used in other life threatening emergencies where CAPS deployment is determined to be safer than continued flight and landing.
  • Page 97 3: E IRRUS ESIGN ECTION MERGENCY ROCEDURES SR22 THER MERGENCIES (Continued) • CAUTION • CAPS deployment will likely result in damage or loss to the airframe. • N • Several possible scenarios in which the activation of the CAPS would be appropriate are discussed in...
  • Page 98 3: E ECTION MERGENCY ROCEDURES IRRUS ESIGN SR22 THER MERGENCIES Intentionally Left Blank 3-44 P/N 13772-006 Reissue A...
  • Page 99 3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 Section 3A: Abnormal Procedures Table of Contents Introduction..................3 Crew Alert System (CAS) Messaging ..........3 Cautions ..................3 Advisories ..................3 Abnormal Procedures Guidance ............3 Circuit Breakers................. 4 Procedure Division Symbols ............. 4 Landing Guidance ................
  • Page 100 3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 Pitot Static System ................17 Static Source Blocked ..............17 Pitot Tube Blocked ................17 PITOT HEAT FAIL Caution ............. 18 PITOT HEAT REQD Caution............18 Flight Control System ................ 19 Electric Trim/Autopilot Failure............19 FLAPS OVERSPEED Caution ............

  • Page 101: Introduction

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 NTRODUCTION Introduction This section provides procedures for handling abnormal system and/or flight conditions which, if followed, will maintain an acceptable level of airworthiness or reduce operational risk. The guidelines described in this section are to be used when an abnormal condition exists, and should be considered and applied as necessary.

  • Page 102: Circuit Breakers

    BNORMAL ROCEDURES IRRUS ESIGN SR22 NTRODUCTION Sound judgment as well as thorough knowledge of the aircraft, its charac- teristics, and the flight manual procedures are essential in the handling of any abnormal system and/or flight condition. In addition to the outlined...

  • Page 103: Landing Guidance

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 LIGHT NVIRONMENT Landing Guidance Land as Soon as Practicable Extended flight is not recommended and the pilot should proceed to land the plane, but not necessarily at the first or closest landing location. The landing location and duration of flight remains at the discretion of the pilot in command, after considering all factors related to the safety of the flight.

  • Page 104: Inadvertent Imc Encounter

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 LIGHT NVIRONMENT Inadvertent IMC Encounter 1. Airplane Control ..ESTABLISH STRAIGHT AND LEVEL FLIGHT 2. Autopilot ....ENGAGE TO HOLD HEADING AND ALTITUDE 3. Heading ..........RESET TO INITIATE 180° TURN Procedure Complete •...

  • Page 105: Abnormal Landings

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 BNORMAL ANDINGS Abnormal Landings Landing With Failed Brakes ◆ One brake inoperative: a. Land on the side of runway corresponding to the inoperative brake. b. Maintain directional control using rudder and working brake.

  • Page 106: Engine System

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 NGINE YSTEM Engine System OIL PRESS Caution OIL PRESS Low Idle Oil Pressure ◆ If in flight: a. Land as soon as practicable. Procedure Complete • N • Oil pressure between 10 psi and 30 psi at or above 1000 RPM.

  • Page 107: Start Engaged Caution

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 NGINE YSTEM START ENGAGED Caution START ENGAGED Starter Engaged Annunciation ◆ If on ground: a. Ignition Switch....DISENGAGE PRIOR TO 10 SECONDS b. Wait 20 seconds before next start attempt. ❍ If starter does not disengage (relay or solenoid failure): (1)BAT 1 Switch ................OFF...

  • Page 108: Fuel System

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 YSTEM Fuel System FUEL LOW TOTAL Caution FUEL LOW TOTAL Low Fuel Quantity 1. Fuel Quantity Gauges ...............CHECK 2. Totalized Fuel Quantity ..............CHECK ◆ If totalized value differs significantly from sensed quantity: a.

  • Page 109: Fuel Imbalance Advisory

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 LECTRICAL YSTEM FUEL IMBALANCE Advisory FUEL IMBALANCE Fuel Imbalance 1. Fuel Quantity Gauges............... CHECK 2. Fuel Pump................... BOOST a. If BOOST already in use for vapor suppression, pump should be left in this position for tank switch.

  • Page 110: M Bus 2 Caution

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 LECTRICAL YSTEM M BUS 2 Caution M BUS 2 Low Voltage on Main Bus 2 1. Perform ALT 1 Caution (Failure) ALT 2 Caution (Failure) Check- lists. Procedure Complete • N •...

  • Page 111: Alt 1 Caution (Failure)

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 LECTRICAL YSTEM ALT 1 Caution (Failure) ALT 1 Low Alternator 1 Output 1. ALT 1 Circuit Breaker ........... CHECK AND SET 2. ALT 1 Switch ..................CYCLE ◆ If alternator does not reset: a.

  • Page 112: Alt 2 Caution (Failure)

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 NTEGRATED VIONICS YSTEM ALT 2 Caution (Failure) ALT 2 Low Alternator 2 Output 1. ALT 2 Circuit Breaker ........... CHECK AND SET 2. ALT 2 Switch..................CYCLE ◆ If alternator does not reset: a.

  • Page 113: Pfd Fan Fail Advisory

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 NTEGRATED VIONICS YSTEM PFD FAN FAIL Advisory PFD FAN FAIL PFD Cooling Fan Failure 1. AVIONICS FAN 2 Circuit Breaker..........CYCLE ◆ If annunciation does not extinguish: a. High cabin temps....LAND AS SOON AS PRACTICABLE b.

  • Page 114: Flight Displays Too Dim

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 NTEGRATED VIONICS YSTEM Flight Displays Too Dim 1. INSTRUMENT dimmer knob ...............OFF (FULL COUNTER-CLOCKWISE) ◆ If flight displays do not provide sufficient brightness: a. Revert to standby instruments. Procedure Complete • N •...

  • Page 115: Pitot Static System

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 ITOT TATIC YSTEM Pitot Static System Static Source Blocked 1. Pitot Heat ....................ON 2. Alternate Static Source ................ OPEN Procedure Complete • N • If erroneous readings of the static source instruments (airspeed, altimeter and vertical speed) are suspected, the alternate static source valve, on side of console near pilot’s right ankle, should be...

  • Page 116: Pitot Heat Fail Caution

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 ITOT TATIC YSTEM PITOT HEAT FAIL Caution PITOT HEAT FAIL Pitot Heat Current Sensor 1. Pitot Heat Circuit Breaker ..............CYCLE 2. Pitot Heat................CYCLE OFF, ON ◆ If inadvertent icing encountered, perform...

  • Page 117: Flight Control System

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 LIGHT ONTROL YSTEM Flight Control System Electric Trim/Autopilot Failure 1. Airplane Control ..........MAINTAIN MANUALLY 2. Autopilot (if engaged) .............DISENGAGE ◆ If Problem Is Not Corrected: a. Circuit Breakers ..........PULL AS REQUIRED •...

  • Page 118: Takeoff Flaps Caution

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 LIGHT ONTROL YSTEM TAKEOFF FLAPS Caution TAKEOFF FLAPS Flaps Not In Takeoff Configuration 1. Takeoff ....................ABORT 2. Aircraft Control ................. MAINTAIN 3. Aircraft Configuration..............CHECK Procedure Complete • N • Flaps are not set to 50% during takeoff.

  • Page 119: Landing Gear System

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 ANDING YSTEM Landing Gear System Brake Failure During Taxi 1. Engine Power................ AS REQUIRED To stop airplane - REDUCE If necessary for steering - INCREASE 2. Directional Control ........MAINTAIN WITH RUDDER 3.

  • Page 120: Oxygen System

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 XYGEN YSTEM Oxygen System OXYGEN QTY Caution OXYGEN QTY Oxygen Quantity Low 1. Oxygen Pressure and Flow Rate............CHECK 2. Oxygen Duration..............CALCULATE See Oxygen AFMS; calculate duration based on remaining pressure, number of occupants and type of device (mask or cannula).

  • Page 121: Oxygen Rqd Caution

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 XYGEN YSTEM OXYGEN RQD Caution OXYGEN RQD Oxygen Required 1. Oxygen System ..................ON 2. Oxygen Mask/Canula................DON 3. Oxygen Flow Rate ............ SET AND MONITOR 4. Pulse Oximeter ............MONITOR O2 LEVELS Procedure Complete •...

  • Page 122: Check Oxygen Advisory

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 XYGEN YSTEM CHECK OXYGEN Advisory CHECK OXYGEN Check Oxygen System Status 1. Pulse Oximeter ........CHECK SATURATION LEVELS ◆ If O2 saturations are low: Oxygen Mask/Canula ..........DON 2. Oxygen Flow Rates................CHECK 3. Oxygen Lines ........VERIFY SECURITY AND ROUTING 4.

  • Page 123: Other Conditions

    3A: A IRRUS ESIGN ECTION BNORMAL ROCEDURES SR22 THER ONDITIONS Other Conditions Aborted Takeoff 1. Power Lever .................... IDLE 2. Brakes ..................AS REQUIRED Procedure Complete • N • Use as much of the remaining runway as needed to safely bring the airplane to a stop or to slow the airplane sufficiently to turn off runway.

  • Page 124: Communications Failure

    3A: A ECTION BNORMAL ROCEDURES IRRUS ESIGN SR22 THER ONDITIONS Communications Failure 1. Switches, Controls................CHECK 2. Frequency ..................CHANGE 3. Circuit Breakers..................SET 4. Headset ................... CHANGE 5. Handheld Microphone ...............CONNECT Procedure Complete • N • If, after following the checklist procedure, communication is not restored, proceed with CFR/AIM lost communications proce- dures.
  • Page 125 4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 Section 4: Normal Procedures Table of Contents Introduction..................3 Airspeeds for Normal Operation............3 Normal Procedures ................4 Preflight Inspection................4 Before Engine Start ................. 10 Engine Start..................11 Before Taxiing ................. 12 Taxiing.....................
  • Page 126 4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 Intentionally Left Blank P/N 13772-006 Reissue A...

  • Page 127: Introduction

    ESIGN ECTION ORMAL ROCEDURES SR22 NTRODUCTION Introduction This section provides amplified procedures for normal operation of the Cirrus Design SR22 aircraft. • N • Refer to Section 9: Log of Supplements for optional equipment Normal Procedures. Airspeeds for Normal Operation Unless otherwise noted, the following speeds are based on a maximum weight of 3600 lb.

  • Page 128: Normal Procedures

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES Normal Procedures Preflight Inspection • WARNING • Before carrying out preflight inspections, ensure that all required main- tenance has been accomplished. Review your flight plan and compute weight and balance and performance requirements. Throughout the walk-around: check all hinges, hinge pins, and bolts for security;...
  • Page 129 4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES (Continued) 1. Cabin a. Required Documents ............ON BOARD b. AVIONICS Switch ................OFF c. BAT 2 Switch..................ON d. PFD..................VERIFY ON e. Essential Bus Voltage ............23-25 VOLTS f. Flap Position Light ................OUT g.
  • Page 130 4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES (Continued) u. BAT 1 and BAT 2 Switches ..............OFF v. Alternate Static Source ............NORMAL w. Circuit Breakers..................IN x. Fire Extinguisher........CHARGED AND AVAILABLE y. Emergency Egress Hammer ..........AVAILABLE z. CAPS Handle..............PIN REMOVED 2.
  • Page 131 4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES (Continued) 4. Right Fuselage a. Static Button ..........CHECK FOR BLOCKAGE b. Wing/Fuselage Fairings ............. CHECK c. Door Lock .................UNLOCK 5. Right Wing Trailing Edge a. Flap and Rub Strips (if installed)..CONDITION AND SECURITY b.
  • Page 132 4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES (Continued) c. Cowling ............. ATTACHMENTS SECURE d. Exhaust Pipe ..CONDITION, SECURITY, AND CLEARANCE 9. Nose Gear, Propeller, and Spinner • WARNING • Keep clear of propeller rotation plane. Do not allow others to approach propeller.
  • Page 133 4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES (Continued) 11.Left Main Gear and Forward Wing a. Wheel Fairings ...SECURITY, ACCUMULATION OF DEBRIS b. Tire........CONDITION, INFLATION, AND WEAR c. Wheel and Brakes ......FLUID LEAKS, EVIDENCE OF OVERHEATING, GENERAL CONDITION, AND SECURITY d.

  • Page 134: Before Engine Start

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES Before Engine Start 1. Preflight Inspection..............COMPLETED • WARNING • Ensure that the airplane is properly loaded and within the AFM’s weight and balance limitations prior to takeoff. 2. Weight and Balance ......... VERIFY WITHIN LIMITS 3.

  • Page 135: Engine Start

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES Engine Start If the engine is warm, no priming is required. For the first start of the day and in cold conditions, prime will be necessary. Weak intermittent firing followed by puffs of black smoke from the exhaust stack indicates over-priming or flooding.

  • Page 136: Before Taxiing

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES (Continued) 1. External Power (If applicable)...........CONNECT 2. Brakes....................HOLD 3. BAT 1 and BAT 2 Switches........ON (CHECK VOLTS) 4. Strobe Lights ....................ON 5. Mixture ..................FULL RICH 6. Power Lever..............FULL FORWARD 7.

  • Page 137: Taxiing

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES Taxiing When taxiing, directional control is accomplished with rudder deflection and intermittent braking (toe taps) as necessary. Use only as much power as is necessary to achieve forward movement. Deceleration or taxi speed control using brakes but without a reduction in power will result in increased brake temperature.

  • Page 138: Before Takeoff

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES Before Takeoff During cold weather operations, the engine should be properly warmed up before takeoff. In most cases this is accomplished when the oil temperature has reached at least 100 °F (38 °C). In warm or hot weather, precautions should be taken to avoid overheating during prolonged ground engine operation.
  • Page 139 4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES (Continued) 16.Alternator................... CHECK a. Pitot Heat..................... ON b. Navigation Lights................ON c. Landing Light ..................ON 17.Voltage....................CHECK 18.Pitot Heat ................AS REQUIRED • N • Pitot Heat should be turned ON for flight into IMC, flight into visible moisture, or whenever ambient temperatures are 41 °F (5...

  • Page 140: Maximum Power Fuel Flow

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES Maximum Power Fuel Flow Target fuel flow is indicated by the top of a dynamically calculated green arc displayed on the fuel gauge. Target fuel flow should be maintained at the top of this arc by use of the mixture lever.

  • Page 141: Normal Takeoff

    IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES Takeoffs into strong crosswinds are normally performed with the flaps set at 50% to minimize the drift angle immediately after takeoff. With the aile- rons fully deflected into the wind, accelerate the airplane to a speed slightly...

  • Page 142: Climb

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES Climb Normal climbs are performed flaps UP (0%) and full power at speeds 5 to 10 knots higher than best rate-of-climb speeds. These higher speeds give the best combination of performance, visibility and engine cooling.

  • Page 143: Cruise

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES Cruise Normal cruising is performed between 55% and 85% power. The engine power setting and corresponding fuel consumption for various altitudes and temperatures can be determined by using the cruise data in Section 5.

  • Page 144: Cruise Leaning

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES Cruise Leaning Exhaust gas temperature (EGT) may be used as an aid for mixture leaning in cruise flight. • N • For “Best Power” use 75% power or less. For “Best Economy” use 65% power or less.

  • Page 145: Descent

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES Descent 1. Altimeter ....................SET 2. Cabin Heat/Defrost ............. AS REQUIRED 3. Landing Light .................... ON 4. Fuel System ..................CHECK 5. Mixture.................. AS REQUIRED 6. Brake Pressure ................... CHECK Before Landing 1.

  • Page 146: Short Field Landing

    ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ORMAL ROCEDURES Actual touchdown should be made with power off and on the main wheels first to reduce the landing speed and subsequent need for braking. Gently lower the nose wheel to the runway after airplane speed has diminished.

  • Page 147: After Landing

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 ORMAL ROCEDURES 1. Autopilot ...................DISENGAGE 2. Power Lever ..............FULL FORWARD 3. Flaps ......................50% 4. Airspeed ..................80 - 85 KIAS After clear of obstacles: 5. Flaps ......................UP After Landing 1.

  • Page 148: Stalls

    ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 TALLS Stalls Aircraft stall characteristics are conventional. Power-off stalls may be accompanied by a slight nose bobbing if full aft stick is held. Power-on stalls are marked by a high sink rate at full aft stick. Power-off stall speeds at...

  • Page 149: Environmental Conditions

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 NVIRONMENTAL ONDITIONS Environmental Conditions Cold Weather Operation • CAUTION • An engine that has been superficially warmed, may start and appear to run satisfactorily, but can be damaged from lack of lubrication due to the congealed oil blocking proper oil flow through the engine.
  • Page 150 4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 NVIRONMENTAL ONDITIONS 1. Ignition Switch ..................OFF • WARNING • Use caution when pulling the propeller through by hand. Make sure ig- nition switch is OFF, keys are out of ignition, and then act as if the en- gine will start.

  • Page 151: Hot Weather Operation

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 NVIRONMENTAL ONDITIONS Hot Weather Operation Avoid prolonged engine operation on the ground. Fuel BOOST must be ON for engine start and takeoff, and should be ON during climb for vapor suppression which could occur under hot ambient conditions or after extended idle.

  • Page 152: Lead Reduction Before Shut Down

    4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 NVIRONMENTAL ONDITIONS Lead Reduction Before Shut Down If required, complete the following procedure before shutdown to reduce potential for lead build-up in the combustion chamber, spark plugs, and engine oil. • CAUTION •...

  • Page 153: Noise Characteristics/Abatement

    4: N IRRUS ESIGN ECTION ORMAL ROCEDURES SR22 OISE HARACTERISTICS BATEMENT Noise Characteristics/Abatement The certificated noise levels for the aircraft established in accordance with CFR 36 Appendix G are: Configuration Actual Maximum Allowable Hartzell 3-blade Propeller, 84.7 dB(A) 88.0 dB(A)
  • Page 154 4: N ECTION ORMAL ROCEDURES IRRUS ESIGN SR22 ONSERVATION Intentionally Left Blank 4-30 P/N 13772-006 Reissue A...
  • Page 155 5: P IRRUS ESIGN ECTION ERFORMANCE SR22 Section 5: Performance Data Table of Contents Introduction..................3 Standard Charts .................. 3 Associated Conditions Affecting Performance ........3 Demonstrated Operating Temperature ..........3 Temperature Conversion..............4 OAT for International Standard Atmosphere (ISA) Condition.... 5 Pressure Conversion - Inches of Mercury to Millibars .......
  • Page 156 5: P ECTION ERFORMANCE IRRUS ESIGN SR22 Landing Distance................40 Landing Distance Table - Flaps 100%..........41 Landing Distance Table - Flaps 50%..........42 Landing Distance Table - Flaps 0%..........43 P/N 13772-006 Reissue A...

  • Page 157: Introduction

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 NTRODUCTION Introduction Performance data in this section are presented for operational planning so that you will know what performance to expect from the airplane under various ambient and field conditions. Performance data are presented for takeoff, climb, and cruise (including range &...

  • Page 158: Temperature Conversion

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Temperature Conversion Temp to Convert Temp to Convert Temp to Convert °C or °F °C or °F °C or °F °C < > °F °C < > °F °C < >...

  • Page 159: Oat For International Standard Atmosphere (Isa) Condition

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 TANDARD HARTS OAT for International Standard Atmosphere (ISA) Condition Press -30 °C -15 °C +15 °C +30 °C °C °F °C °F °C °F °C °F °C °F 1000 2000 3000 4000 5000...

  • Page 160: Pressure Conversion - Inches Of Mercury To Millibars

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Pressure Conversion - Inches of Mercury to Millibars Inches Of Inches Of Millibars Millibars Mercury Mercury 28.0 29.6 1002 28.1 29.7 1006 28.2 29.8 1009 28.3 29.9 1012 28.4 30.0 1016 28.5...

  • Page 161: Fuel Quantity Conversion - U.s. Gallons To Liters

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 TANDARD HARTS Fuel Quantity Conversion - U.S. Gallons to Liters • N • Fuel mass provided for reference assuming nominal 6.0 lb/gallon at 59 °F (15 °C). U.S. U.S. Gallons Lb (Kg) Gallons...

  • Page 162: Weight Conversion - Pounds To Kilograms

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Weight Conversion - Pounds to Kilograms Pounds Kilograms Pounds Kilograms 2000 907.2 2900 1315.4 2100 952.5 3000 1360.1 2200 998.0 3100 1406.1 2300 1043.3 3200 1451.5 2400 1088.6 3300 1497.0 2500 1134.0...

  • Page 163: Distance Conversion: Feet To Meters

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 TANDARD HARTS Distance Conversion: Feet to Meters Feet Meters Feet Meters 1000 2000 3000 4000 1219 5000 1524 6000 1829 7000 2134 8000 2438 9000 2743 10,000 3048 P/N 13772-006 Reissue A...

  • Page 164: Length Conversion: Inches To Centimeters

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Length Conversion: Inches to Centimeters Inches Centimeters Inches Centimeters 2.54 50.8 5.08 76.2 7.62 101.6 10.16 12.70 142.4 15.24 177.8 17.78 203.2 20.32 228.6 22.86 25.40 27.94 30.48 5-10 P/N 13772-006...

  • Page 165: Airspeed Calibration

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 TANDARD HARTS Airspeed Calibration Normal Static Source Conditions: • Power for level flight or maximum continuous, whichever is less. • N • Indicated airspeed values assume zero instrument error. KCAS KIAS Flaps 0%...

  • Page 166: Alternate Static Source

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Alternate Static Source Conditions: • Power for level flight or maximum continuous, whichever is less. • Heater, Defroster & Vents ..............ON • N • Indicated airspeed values assume zero instrument error.

  • Page 167: Altitude Correction

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 TANDARD HARTS Altitude Correction Normal Static Source: Primary Flight Display Conditions: • Power for level flight or maximum continuous, whichever is less. • 3600 LB • N • Add correction to desired altitude to obtain indicated altitude to fly.

  • Page 168: Normal Static Source: Standby Altimeter

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Normal Static Source: Standby Altimeter Conditions: • Power for level flight or maximum continuous, whichever is less. • 3600 LB • N • Add correction to desired altitude to obtain indicated altitude to fly.

  • Page 169: Alternate Static Source: Primary Flight Display

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 TANDARD HARTS Alternate Static Source: Primary Flight Display Conditions: • Power for level flight or maximum continuous, whichever is less. • Heater, Defroster & Vents..............ON • N • Add correction to desired altitude to obtain indicated altitude to fly.

  • Page 170: Alternate Static Source: Standby Altimeter

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Alternate Static Source: Standby Altimeter Conditions: • Power for level flight or maximum continuous, whichever is less. • Heater, Defroster & Vents ..............ON • N • Add correction to desired altitude to obtain indicated altitude to fly.

  • Page 171: Stall Speeds

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 TANDARD HARTS Stall Speeds Conditions: • Weight....................3600 LB • CG......................Noted • Power......................Idle • Bank Angle ..................Noted • N • Altitude loss during wings level stall may be 250 ft or more.

  • Page 172: Wind Components

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 TANDARD HARTS Wind Components Example: Runway Heading..................... 10° Wind Direction ....................60° Wind Velocity ..................15 Knots • N • The maximum demonstrated crosswind is 21 knots. Value not considered limiting. Figure 5-1: Wind Components 0°...

  • Page 173: Takeoff Distance

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 AKEOFF ISTANCE Takeoff Distance Conditions: • Winds ..................... Zero • Runway................Dry, Level, Paved • Flaps......................50% • Air Conditioner ..................OFF • Power..................Full Throttle • Mixture.............Set to very top of GREEN ARC Set prior to brake release for short field takeoff.

  • Page 174: Takeoff Distance: 3600 Lb (1633 Kg)

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 AKEOFF ISTANCE Takeoff Distance: 3600 lb (1633 kg) Weight: 3600 lb (1633 kg) Headwind: Subtract 10% per each 12 Approximate Speed at Liftoff: knots headwind. 76 KIAS Tailwind: Add 10% per each 2 knots Speed over 50 ft Obstacle: 84 KIAS tailwind up to 10 knots.

  • Page 175: Takeoff Distance: 2900 Lb (1315 Kg)

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 AKEOFF ISTANCE Takeoff Distance: 2900 lb (1315 kg) Weight: 2900 lb (1315 kg) Headwind: Subtract 10% per each 12 Approximate Speed at Liftoff: knots headwind. 70 KIAS Tailwind: Add 10% per each 2 knots Speed over 50 ft Obstacle: 74 KIAS tailwind up to 10 knots.

  • Page 176: Takeoff Climb Gradient

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 AKEOFF ISTANCE Takeoff Climb Gradient Conditions: • Power ..................Full Throttle • Mixture.............Set to very top of GREEN ARC • Flaps ......................50% • Airspeed ................ Best Rate of Climb • N • Climb Gradients shown are the gain in altitude for the horizontal distance traversed expressed as Feet per Nautical Mile.
  • Page 177 5: P IRRUS ESIGN ECTION ERFORMANCE SR22 AKEOFF ISTANCE CLIMB GRADIENT - Feet per Nautical Mile Weight Press Alt Climb Speed TEMPERATURE ~°C KIAS 2900 1172 1122 1070 1019 1083 2000 1049 1000 4000 6000 8000 10000 P/N 13772-006 5-23...

  • Page 178: Takeoff Rate Of Climb

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 AKEOFF ISTANCE Takeoff Rate of Climb Conditions: • Power ..................Full Throttle • Mixture.............Set to very top of GREEN ARC • Flaps ......................50% • Airspeed ................ Best Rate of Climb • N • Rate-of-Climb values shown are change in altitude for unit time expended expressed in Feet per Minute.
  • Page 179 5: P IRRUS ESIGN ECTION ERFORMANCE SR22 AKEOFF ISTANCE RATE OF CLIMB - Feet per Minute Weight Press Alt Climb Speed TEMPERATURE ~°C KIAS 2900 1646 1638 1621 1598 1585 1626 2000 1518 1505 1484 1457 1442 1494 4000 1389...

  • Page 180: Enroute Climb

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 NROUTE LIMB Enroute Climb Enroute Climb Gradient Conditions: • Power ..................Full Throttle • Mixture.............Set to very top of GREEN ARC • Flaps ....................0% (UP) • Airspeed ................ Best Rate of Climb • N •...

  • Page 181: Enroute Rate Of Climb

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 NROUTE LIMB Weight Press Alt Climb CLIMB GRADIENT - Feet per Nautical Mile Speed TEMPERATURE ~°C KIAS 2900 1130 1078 1026 1039 2000 1015 4000 6000 8000 10000 12000 14000 16000 Enroute Rate Of Climb Conditions: •...
  • Page 182 5: P ECTION ERFORMANCE IRRUS ESIGN SR22 NROUTE LIMB RATE OF CLIMB - Feet per Minute Weight Press Alt Climb Speed TEMPERATURE ~°C KIAS 3600 1285 1268 1245 1217 1202 1251 2000 1172 1150 1123 1093 1076 1136 4000 1057...

  • Page 183: Enroute Rate Of Climb Vs Density Altitude

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 NROUTE LIMB Enroute Rate of Climb Vs Density Altitude Conditions: • Power..................Full Throttle • Mixture.............Set to very top of GREEN ARC • Flaps....................0% (UP) • Airspeed .................Best Rate of Climb Figure 5-2: Enroute Rate of Climb Vs Density Altitude...

  • Page 184: Time, Fuel, & Distance To Climb

    5: P ECTION ERFORMANCE IRRUS ESIGN , & D SR22 ISTANCE TO LIMB Time, Fuel, & Distance to Climb Conditions: • Power ..................Full Throttle • Mixture..............Per Schedule, Section 4 • Fuel Density ................6.0 LB/GAL • Weight ....................3600 LB •...
  • Page 185 5: P IRRUS ESIGN ECTION ERFORMANCE SR22 , & D ISTANCE TO LIMB Press Climb Rate Of TIME, FUEL, DISTANCE ~ From Sea Level (ISA) Speed Climb Time Fuel Distance °C KIAS Minutes U.S. Gal 15000 21.2 41.4 16000 24.3 47.6...

  • Page 186: Cruise Performance

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 RUISE ERFORMANCE Cruise Performance Conditions: • Weight ....................3400 LB • Winds .....................Zero • Shaded Cells: Cruise Pwr above 85% not recommended. • N • Subtract 10 KTAS if nose wheel pant and fairing removed. Lower KTAS by 10% if nose and main wheel pants and fairings are removed.
  • Page 187 5: P IRRUS ESIGN ECTION ERFORMANCE SR22 RUISE ERFORMANCE ISA -30 °C ISA +30 °C Press Alt RPM MAP PWR KTAS GPH PWR KTAS GPH PWR KTAS GPH 6000 2700 23.5 89% 184 21.2 85% 184 20.1 81% 179 19.6 2600 23.5 85% 181 20.3 81% 181 19.2 77% 176 19.1...
  • Page 188 5: P ECTION ERFORMANCE IRRUS ESIGN SR22 RUISE ERFORMANCE ISA -30 °C ISA +30 °C Press Alt RPM MAP PWR KTAS GPH PWR KTAS GPH PWR KTAS GPH 16000 2700 15.8 61% 176 14.5 58% 176 13.7 55% 171 13.0 2600 15.8 58% 173 13.8 55% 173 13.1 52% 167 12.5...

  • Page 189: Range / Endurance Profile

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 ANGE NDURANCE ROFILE Range / Endurance Profile Conditions: • Weight.........3600 LB for Climb, Avg 3400 LB for Cruise • Temperature................Standard Day • Winds ..................... Zero • Mixture..................See Tables • Total Fuel ..................92 Gallons •...
  • Page 190 5: P ECTION ERFORMANCE IRRUS ESIGN SR22 ANGE NDURANCE ROFILE 65% POWER Mixture = Best Power Press Climb Fuel Airspeed Fuel Endurance Range Specific Range Fuel Remaining Flow For Cruise KTAS HOURS NM/GAL 81.2 15.4 10.3 2000 79.3 15.4 10.5 4000 77.4...
  • Page 191 5: P IRRUS ESIGN ECTION ERFORMANCE SR22 ANGE NDURANCE ROFILE 55% POWER Mixture = Best Economy Press Climb Fuel Airspeed Fuel Endurance Range Specific Fuel Remaining Flow Range For Cruise KTAS HOURS NM/GAL 81.2 11.3 1067 13.1 2000 79.3 11.3 1080 13.4...

  • Page 192: Balked Landing

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 ALKED ANDING Balked Landing Balked Landing Climb Gradient Conditions: • Power ..................Full Throttle • Mixture.................Set per Placard • Flaps .................... 100% (DN) • Airspeed ....................V • N • Balked Landing Climb Gradients shown are the gain in altitude for the horizontal distance traversed expressed as Feet per Nautical Mile.

  • Page 193: Balked Landing Rate Of Climb

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 ALKED ANDING Balked Landing Rate of Climb Conditions: • Power..................Full Throttle • Mixture................. Set per Placard • Flaps.................... 100% (DN) • Airspeed ....................V • N • Balked Landing Rate of Climb values shown are the full flaps change in altitude for unit time expended expressed in Feet per Minute.

  • Page 194: Landing Distance

    5: P ECTION ERFORMANCE IRRUS ESIGN SR22 ANDING ISTANCE Landing Distance Conditions: • Winds .....................Zero • Runway................Dry, Level, Paved • Flaps .................100%, 50%, or 0% • Power ..........3° Power Approach to 50 ft obstacle, then reduce power passing the estimated 50 ft point and smoothly continue power reduction to reach idle just prior to touchdown.

  • Page 195: Landing Distance Table - Flaps 100

    5: P IRRUS ESIGN ECTION ERFORMANCE SR22 ANDING ISTANCE Landing Distance Table - Flaps 100% Weight: 3600 lb (1633 kg) Headwind: Subtract 10% per each 13 Speed over 50 ft Obstacle: 79 KIAS knots headwind. Flaps: 100% Tailwind: Add 10% per each 2 knots Power: Idle tailwind up to 10 knots.
  • Page 196 5: P ECTION ERFORMANCE IRRUS ESIGN SR22 ANDING ISTANCE Landing Distance Table - Flaps 50% Weight: 3600 lb (1633 kg) Headwind: Subtract 10% per each 13 Speed over 50 ft Obstacle: 87 KIAS knots headwind. Flaps: 50% Tailwind: Add 10% per each 2 knots Power: Idle tailwind up to 10 knots.
  • Page 197 5: P IRRUS ESIGN ECTION ERFORMANCE SR22 ANDING ISTANCE Landing Distance Table - Flaps 0% Weight: 3600 lb (1633 kg) Headwind: Subtract 10% per each 13 Speed over 50 ft Obstacle: 94 KIAS knots headwind. Flaps: 0% Tailwind: Add 10% per each 2 knots Power: Idle tailwind up to 10 knots.
  • Page 198 5: P ECTION ERFORMANCE IRRUS ESIGN SR22 ANDING ISTANCE Intentionally Left Blank 5-44 P/N 13772-006 Reissue A...
  • Page 199 6: W IRRUS ESIGN ECTION EIGHT AND ALANCE SR22 Section 6: Weight and Balance Table of Contents Introduction..................3 Weight and Balance Record..............3 Weight and Balance Data..............3 Loading Instructions ................4 Weight and Balance Loading Form ............. 5 Loading Data ..................
  • Page 200 6: W ECTION EIGHT AND ALANCE IRRUS ESIGN SR22 Intentionally Left Blank P/N 13772-006 Reissue A...

  • Page 201: Introduction

    IRRUS ESIGN ECTION EIGHT AND ALANCE SR22 NTRODUCTION Introduction This section describes the procedure for calculating the weight and moment for various operations. A comprehensive list of all equipment available for this airplane is included at the back of this section.

  • Page 202: Loading Instructions

    6: W ECTION EIGHT AND ALANCE IRRUS ESIGN SR22 EIGHT AND ALANCE ECORD Loading Instructions It is the responsibility of the pilot to ensure that the airplane is properly loaded and operated within the prescribed weight and center of gravity limits.

  • Page 203: Weight And Balance Loading Form

    6: W IRRUS ESIGN ECTION EIGHT AND ALANCE SR22 EIGHT AND ALANCE OADING Weight and Balance Loading Form • N • The Takeoff Condition Weight must not exceed 3600 lb. The Takeoff Condition Moment must be within the Minimum Moment to Maximum Moment range at the Takeoff Condition Weight.

  • Page 204: Loading Data

    6: W ECTION EIGHT AND ALANCE IRRUS ESIGN SR22 OADING Loading Data Use the following chart or table to determine the moment/1000 for fuel and payload items to complete the Loading Form. Figure 6-3: Loading Chart Fuel Aft Pass Fwd Pass...

  • Page 205: Moment Limits

    6: W IRRUS ESIGN ECTION EIGHT AND ALANCE SR22 OMENT IMITS Moment Limits Use the following chart or table to determine if the weight and moment from the completed Weight and Balance Loading Form (Figure 6-2) are within limits. Figure 6-4: Moment Limits Chart...

  • Page 206: Weight & Balance Record

    6: W ECTION EIGHT AND ALANCE IRRUS ESIGN & B SR22 EIGHT ALANCE ECORD Weight & Balance Record Use this form to maintain a continuous history of changes and modifica- tions to airplane structure or equipment affecting weight and balance: Figure 6-5: Weight &...
  • Page 207 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 Section 7: Airplane and Systems Table of Contents Introduction..................5 Airframe....................5 Fuselage.................... 5 Wings ....................5 Empennage ..................6 Flight Controls ..................6 Elevator System ................6 Aileron System .................. 9 Rudder System................
  • Page 208 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 Key Fob ................... 31 Windshield and Windows ..............31 Engine ....................31 Engine Controls ................31 Engine Indicating ................32 Engine Lubrication System.............. 36 Ignition and Starter System ............. 36 Air Induction System................ 37 Engine Exhaust ................
  • Page 209 Emergency Locator Transmitter (ELT) ..........90 Fire Extinguisher ................92 Hour Meters..................93 Emergency Egress Hammer ............93 Convenience Outlet(s)..............93 Cirrus Airframe Parachute System............ 94 System Description ................. 94 Activation Handle ................95 Deployment Characteristics ............96 P/N 13772-006...
  • Page 210 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 Intentionally Left Blank P/N 13772-006 Reissue A...

  • Page 211: Introduction

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NTRODUCTION Introduction This section provides a basic description and operation of the standard airplane and its systems. Optional equipment described within this section is identified as optional. • N • Some optional equipment may not be described in this section.

  • Page 212: Empennage

    ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LIGHT ONTROLS in a C-section, and is continuous from wing tip to wing tip. The wing spar passes under the fuselage below the two front seats and is attached to the fuselage in two locations. Lift and landing loads are carried by the single carry-through spar, plus a pair of rear shear webs (one on each wing) attached to the fuselage.
  • Page 213 IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LIGHT ONTROLS motor. Moving the switch forward will initiate nose-down trim and moving the switch aft will initiate nose-up trim. Neutral (takeoff) trim is indicated by the alignment of a reference mark on the yoke tube with a tab attached to the instrument panel bolster.
  • Page 214 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LIGHT ONTROLS Figure 7-1: Elevator System SR22_FM07_5342 P/N 13772-006 Reissue A...

  • Page 215: Aileron System

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LIGHT ONTROLS Aileron System The ailerons provide airplane roll control. The ailerons are of conventional design with skin, spar and ribs manufactured of aluminum. Each aileron is attached to the wing shear web at two hinge points.
  • Page 216 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LIGHT ONTROLS Figure 7-2: Aileron System SR22_FM07_5344 7-10 P/N 13772-006 Reissue A...

  • Page 217: Rudder System

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LIGHT ONTROLS Rudder System The rudder provides airplane directional (yaw) control. The rudder is of conventional design with skin, spar and ribs manufactured of aluminum. The rudder is attached to the aft vertical stabilizer shear web at three hinge points and to the fuselage tailcone at the rudder control bell crank.
  • Page 218 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LIGHT ONTROLS Figure 7-3: Rudder System SR22_FM07_5345 7-12 P/N 13772-006 Reissue A...

  • Page 219: Instrument Panel

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NSTRUMENT ANEL Instrument Panel The instrument panel is of all metal construction and is installed in sections so equipment can be easily removed for maintenance. The surrounding glareshield is made of composite material and projects over the instrument panel to reduce reflections on the windshield from lighted equipment and to shield the panel equipment from glare.
  • Page 220 USB POWER 5 VDC, 2.1 AMPS AUDIO MAX PER PORT INPUT LEGEND 1. Cirrus Airframe Parachute System 13. Engine & Fuel System Controls (CAPS) Activation T-Handle Cover 14. Left Side Console 2. Magnetic Compass · Circuit Breaker Panel 3. Multifunction Display ·...
  • Page 221 USB POWER 5 VDC, 2.1 AMPS AUDIO MAX PER PORT INPUT LEGEND 1. Cirrus Airframe Parachute System 13. Engine & Fuel System Controls (CAPS) Activation T-Handle Cover 14. Left Side Console 2. Magnetic Compass · Circuit Breaker Panel 3. Multifunction Display ·...

  • Page 222: Flight Instruments

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LIGHT NSTRUMENTS Flight Instruments Flight instruments and annunciations are displayed on the Primary Flight Display (PFD) located directly in front of the pilot. The PFD presents the primary flight instruments arranged in the conventional basic “T” config- uration.
  • Page 223 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LIGHT NSTRUMENTS Figure 7-5: Flight Instruments 125° LEGEND 1. True Airspeed TERM 2. Airspeed Indicator 3. Horizontal Situation Indicator (HSI) 4. Attitude Indicator 5. Slip/Skid Indicator 1.01NM 6. Vertical Deviation Indicator (VDI) 7.

  • Page 224: Attitude Indicator

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LIGHT NSTRUMENTS Attitude Indicator The primary attitude indicator is shown on the upper center of the PFD and displays pitch, roll, and slip/skid information provided by the Attitude and Heading Reference System (AHRS).

  • Page 225: Airspeed Indicator

    IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LIGHT NSTRUMENTS “earth”. The pitch scale on the attitude display is graduated in 5° incre- ments. Chevrons appear on the pitch scale at extreme pitch attitudes. The MD302 Standby Attitude Module is electrically driven. A red X indicates the attitude display is absent due to exceedance of internal rate sensors, loss of airspeed, or other reasons.

  • Page 226: Altimeter

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LIGHT NSTRUMENTS airspeed tape and denotes the current airspeed. Color coded bars are provided to indicate flap operating range, normal operating range, caution range, and never-exceed speed. 28 VDC for the MD302 Standby Attitude Module is supplied through the 5-amp STDBY ATTD A circuit breaker on ESS BUS 1 and the 5-amp STDBY ATTD B circuit breaker on MAIN BUS 1.

  • Page 227: Horizontal Situation Indicator

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LIGHT NSTRUMENTS Serials w/ MD302 Standby Attitude Module: The MD302 Standby Attitude Module is mounted on the LH bolster panel and displays the current barometric corrected altitude. The instrument senses the local barometric pressure adjusted for altimeter setting and displays the result in the Altitude Window.

  • Page 228: Vertical Speed Indicator

    IRPLANE AND YSTEMS IRRUS ESIGN SR22 LAPS The Course Deviation Indicator (CDI) navigation source shown on the HSI is set using the CDI softkey to select GPS, NAV1, or NAV2 inputs. The course pointer is set on the GCU 479 FMS Keyboard by selecting the CRS button and then selecting the desired course by turning the multi-function knob.

  • Page 229: Flap Control Switch

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LAPS The wing flaps actuator, flap control switch and indicator lights are powered by 28 VDC through the 10-amp FLAPS circuit breaker on NON ESS BUS. Flap Control Switch An airfoil-shaped FLAPS control switch is located at the bottom of the vertical section of the center console.
  • Page 230 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LAPS Figure 7-6: Wing Flaps SR22_FM07_5349 7-24 P/N 13772-006 Reissue A...

  • Page 231: Landing Gear

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 ANDING Landing Gear Main Gear The main landing gear are bolted to composite wing structure between the wing spar and shear web. The landing gear struts are constructed of composite material for fatigue resistance. The composite construction is both rugged and maintenance free.

  • Page 232: Baggage Compartment

    ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 AGGAGE OMPARTMENT Should any of these symptoms occur, immediate maintenance is required. If, during taxi or landing roll, braking action decreases, let up on the toe brakes and then reapply the brakes with heavy pressure. If the brakes are spongy or pedal travel increases, pumping the pedals may build braking pressure.

  • Page 233: Seats

    ESIGN ECTION IRPLANE AND YSTEMS SR22 EATS The aircraft is equipped with a retractable cargo net to secure items in the baggage compartment. Integral inertia reels attached to the rear bulkhead allow the cargo net to be extended forward, placed over baggage, and secured to the seat back via four latch assemblies.

  • Page 234: Rear Seats

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 ELT AND HOULDER ARNESS Rear Seats The rear seats employ a one-piece bench seat and two seat backs configured in 60/40 split. This “2+1” seating configuration provides for a center seat/restraint area for a third passenger on the wider left hand seat.

  • Page 235: Child Restraint System

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 ELT AND HOULDER ARNESS To Use Restraints • CAUTION • No slack may exist between the occupant’s shoulder and restraint harness shoulder strap. Stow the seat belts in the latched position when not in use.
  • Page 236 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 ELT AND HOULDER ARNESS Route child seat’s top tether through the seat back pass-through. Fasten top tether to rear bulkhead anchor. Firmly tension the child seat straps according to the manufacturer's instructions.

  • Page 237: Cabin Doors

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 ABIN OORS Cabin Doors Two large forward hinged doors allow crew and passengers to enter and exit the cabin. The door handles engage latching pins in the door frame receptacles at the upper aft and lower aft door perimeter. Gas charged struts provide assistance in opening the doors and hold the doors open against gusts.

  • Page 238: Engine Indicating

    ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 NGINE Power (Throttle) Lever The single-lever throttle control, labeled MAX-POWER-IDLE, on the console adjusts the engine throttle setting in addition to automatically adjusting propeller speed. The lever is mechanically linked by cables to the air throttle body/fuel-metering valve and to the propeller governor.
  • Page 239 IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NGINE Engine System Annunciations Engine system health, caution, and warning messages are displayed in color-coded text in the Crew Alerting System (CAS) window located to the right of the Altimeter and Vertical Speed Indicator. In combination with a...
  • Page 240 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 NGINE Figure 7-7: Engine Controls and Indicating Density Alt 8000 Ft Oat 31°F -1°C (ISA +0°C) Engine Instruments LEGEND 1. Percent Power 2. CHT 3. Tachometer 4. EGT 5. Manifold Pressure 6.
  • Page 241 IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NGINE Tachometer Engine speed (RPM) is shown in the upper mid-left corner of the ENGINE page as both a simulated tachometer and as a digital value. The tachometer pointer sweeps a scale range from 0 to 3000 RPM in 100 RPM increments.

  • Page 242: Engine Lubrication System

    ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 NGINE The oil pressure sensor is mounted below the oil cooler and provides a signal to the Engine Airframe Unit that is processed and transmitted to the Engine Indicating System for display. Manifold Pressure Gauge Manifold pressure is shown in the upper center portion of the ENGINE page as both a simulated pressure gauge and as a digital value.

  • Page 243: Air Induction System

    IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NGINE rotary-type key switch, located on the instrument panel, controls ignition and starter operation. The switch is labeled OFF-R-L- BOTH-START. In the OFF position, the starter is electrically isolated, the magnetos are grounded and will not operate. Normally, the engine is operated on both magnetos (switch in BOTH position) except for magneto checks and emer- gency operations.

  • Page 244: Engine Cooling

    ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 ROPELLER Engine Cooling Engine cooling is accomplished by discharging heat to the oil and then to the air passing through the oil cooler, and by discharging heat directly to the air flowing past the engine. Cooling air enters the engine compartment through the two inlets in the cowling.

  • Page 245: Fuel System

    IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 YSTEM Fuel System A 92-gallon usable wet-wing fuel storage system provides fuel for engine operation. The system consists of a 47.25-gallon capacity (46-gallon usable) vented integral fuel tank and a fuel collector/sump in each wing, a three position selector valve, an electric fuel pump, and an engine-driven fuel pump.

  • Page 246: Fuel Selector Valve

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 YSTEM Fuel Selector Valve A fuel selector valve, located at the rear of the center console, provides the following functions: • LEFT Allows fuel to flow from the left tank •...
  • Page 247 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 YSTEM Figure 7-8: Fuel System Schematic ANNUNCIATOR FUEL INDICATION VENT VENT FILLER FILLER L. WING TANK R. WING TANK R. WING L. WING COLLECTOR COLLECTOR SELECTOR FLAPPER FLAPPER VALVE VALVE VALVE...

  • Page 248: Fuel Indicating

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 YSTEM Fuel Indicating Fuel quantity is measured by float-type quantity sensors installed in each fuel tank and displayed on the Fuel Quantity Gauge. • CAUTION • When the fuel tanks are 1/4 full or less, prolonged uncoordinated flight such as slips or skids can uncover the fuel tank outlets.
  • Page 249 IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 YSTEM Fuel Totalizer and Calculated Information Fuel totalizer calculations are located in the lower right section of the ENGINE page and are separate and independent of the fuel quantity gauge and float sensor system. The fuel totalizer monitors fuel flow and calculates fuel-to-destination, fuel used, fuel remaining, time remaining, fuel range, and nautical miles per gallon.
  • Page 250 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 YSTEM Figure 7-9: Fuel System Controls and Indicating Fuel System Indication LEGEND 1. Fuel Flow Gauge 2. Fuel Calculations: ·Fuel At Destination (Totalizer) ·Fuel Used (Totalizer) ·Fuel Remaining (Totalizer) ·Time Remaining (Totalizer) ·Fuel Range (Totalizer)

  • Page 251: Mixture Management

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 IXTURE ANAGEMENT Mixture Management The mixture control needs to be carefully monitored and managed during all phases of flight to avoid damage to the engine or a possible loss of power.

  • Page 252: Electrical System

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LECTRICAL YSTEM Electrical System The airplane is equipped with a two-alternator, two-battery, 28-volt direct current (VDC) electrical system designed to reduce the risk of electrical system faults. The system provides uninterrupted power for avionics, flight instrumentation, lighting, and other electrically operated and controlled systems during normal operation.
  • Page 253 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LECTRICAL YSTEM Figure 7-10: Electrical System Schematic 100A LANDING LIGHT ALT 1 7.5A ALT 1 VOLT REG RELAY LANDING LIGHT SWITCH EXTERNAL POWER RELAY ALT 1 EXTERNAL SWITCH POWER 125A BAT 1...

  • Page 254: Power Distribution

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LECTRICAL YSTEM Power Distribution Power is supplied to the airplane circuits through three distribution buses contained in the MCU: Main Distribution Bus 1, Main Distribution Bus 2, and the Essential Distribution Bus. The three distribution buses power the associated buses on the circuit breaker panel.

  • Page 255: Electrical System Protection

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LECTRICAL YSTEM Constant Power Bus (CONV) The Constant Power Bus (CONV) is fed by BAT 1 in the MCU through one 5-amp fuse located on top of the MCU. Electrical System Protection...
  • Page 256 ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LECTRICAL YSTEM Main Buses The circuit breaker panel MAIN BUS 1 and MAIN BUS 2 are powered by ALT 2 from the MCU Main Distribution Bus 2 and - in the event of ALT 2...
  • Page 257 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LECTRICAL YSTEM Figure 7-11: Circuit Breaker Panel AVIONICS PROTECT 2 PROTECT 1 LANDING STDBY ALT2 LIGHTS ATTD B CONV ENGINE MFD B LIGHTS SERVO INSTR STALL CABIN LIGHTS A/C COND CAMERA...

  • Page 258: Electrical System Control

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LECTRICAL YSTEM Electrical System Control The rocker type electrical system MASTER switches are ‘on’ in the up posi- tion and ‘off’ in the down position. The switches, labeled BAT 2, BAT 1, ALT 1, ALT 2 are located in the bolster switch panel immediately below the instrument panel.

  • Page 259: Ground Service Receptacle

    IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LECTRICAL YSTEM regardless of the position of the MASTER switch or the individual equip- ment switches. For normal operations, the AVIONICS switch should be placed in the OFF position prior to activating the MASTER switches, starting the engine, or applying an external power source.
  • Page 260 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 LECTRICAL YSTEM System Emergencies, and Section 3A - Abnormal Procedures, Electrical System. For additional information on Engine Instrument Markings and Annunciations, refer to Section 2: Limitations. For additional information on the System Annunciations And...
  • Page 261 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 LECTRICAL YSTEM Figure 7-12: Electrical / Lighting Controls and Indicating Anti Ice - TKS Time (H+MM) 0+00 0+00 High Density Alt 8000 Ft 0+00 Norm Oat 31°F -1°C (ISA +0°C) Range...

  • Page 262: Lighting Systems

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 IGHTING YSTEMS Lighting Systems Exterior Lighting The airplane is equipped with wing tip navigation lights with integral anti-collision strobe lights and recognition lights. The landing light is located in the lower cowl.

  • Page 263: Interior Lighting

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 IGHTING YSTEMS Interior Lighting Interior lighting for the airplane consists of overhead lights for general cabin lighting, individual lights for the pilots and passengers, and dimmable panel floodlights. The flight instrumentation and avionics equipment lights are dimmable.

  • Page 264: Convenience Lighting

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 IGHTING YSTEMS Reading Lights Individual eyeball-type reading lights are installed in the headliner above each passenger position. Each light is aimed by positioning the lens in the socket and is controlled by a push-button switch located next to the light.
  • Page 265 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 IGHTING YSTEMS Convenience Lighting Operation When the cabin light switch is in the ON position: • Dome light and footwell lights will turn on. • Entry step lights will turn on when either cabin door is opened or the doors are unlocked via the key fob and will turn off when both cabin doors are closed or the doors are locked via the key fob.

  • Page 266: Environmental System

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 NVIRONMENTAL YSTEM Environmental System • N • To facilitate faster cabin cooling, prior to engine start leave the cabin doors open for a short time to allow hot air to escape.
  • Page 267 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NVIRONMENTAL YSTEM Figure 7-13: Standard Environmental System RAM AIR RAM AIR HOT AIR VALVE MIXING CHAMBER HEAT EXCHANGER FRESH AIR VALVE AIR FLOW VALVE CONTROL PANEL SERVO MOTOR FLOOR AIRFLOW WINDSHIELD...
  • Page 268 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 NVIRONMENTAL YSTEM Figure 7-14: Optional Air Conditioning System RAM AIR RAM AIR HOT AIR VALVE MIXING CHAMBER HEAT EXCHANGER COMPRESSOR FRESH AIR VALVE WINDSHIELD AIR FLOW VALVE DIFFUSER SERVO MOTOR FLOOR...

  • Page 269: Distribution

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NVIRONMENTAL YSTEM Distribution Ventilation and cooling is provided by ducting fresh air from a NACA inlet on the RH lower cowl to the mixing chamber located on the lower RH portion of the firewall. Depending on operating mode and temperature...

  • Page 270: Airflow Selection

    ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 NVIRONMENTAL YSTEM In Air Conditioning mode (optional), R134A refrigerant enters the engine mounted compressor as a vapor and is pressurized until the heat-laden vapor reaches a point much hotter than the outside air. The compressor then pumps the vapor to the condenser where it cools, changes to a liquid, and passes to the receiver-drier.

  • Page 271: Temperature Selection

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 NVIRONMENTAL YSTEM When the Windshield selector button is pushed, the cabin floor butterfly valve is closed providing maximum airflow to the windshield diffuser. Temperature Selection The temperature selector is electrically linked to the hot and cold air valves.
  • Page 272 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 NVIRONMENTAL YSTEM Figure 7-15: Environmental System Operation Rotating the selector controls the volume of airflow allowed into the cabin distribution system through use of an electro-mechanical linkage to a butterfly (hot air) valve in the mixing chamber on the forward firewall.

  • Page 273: Stall Warning System

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 TALL ARNING YSTEM Stall Warning System The airplane is equipped with an electro-pneumatic stall warning system to provide audible warning of an approach to aerodynamic stall. The system consists of an inlet in the leading edge of the right wing, a pressure switch and associated plumbing, and the avionics system aural warning system.

  • Page 274: Pitot Heat Annunciation

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 ITOT TATIC YSTEM Pitot Heat Annunciation Illumination of the PITOT HEAT FAIL Caution indicates that the Pitot Heat switch is ON and the Pitot heater is not receiving electrical current. Illumination of PITOT HEAT REQD Caution indicates the system detects OAT is less than 41 °F (5 °C) and Pitot Heat Switch is OFF.
  • Page 275 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 ITOT TATIC YSTEM Figure 7-16: Pitot-Static System - Serials w/o MD302 (1 of 2) ADAHRS 1 ADAHRS 2 (optional) PFD Air Data AIRSPEED ALTIMETER INDICATOR ALTERNATE PITOT-STATIC STATIC WATER TRAPS AIR SOURCE...
  • Page 276 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 ITOT TATIC YSTEM Figure 7-16: Pitot-Static System - Serials w/ MD302 (2 of 2) ADAHRS 1 ADAHRS 2 (optional) PFD Air Data MD302 STANDBY ATTITUDE MODULE ALTERNATE PITOT-STATIC STATIC WATER TRAPS...

  • Page 277: Avionics

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS Avionics Perspective+ Integrated Avionics System The Perspective+ Integrated Avionics System provides advanced cockpit functionality and improved situational awareness through the use of fully integrated flight, engine, communication, navigation and monitoring equipment, and consists of the following components: •...
  • Page 278 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS Figure 7-17: Perspective+ Integrated Avionics System Schematic XM SATELLITE DATA LINK RECEIVER (optional) KEYBOARD MAG 1 MAG 2 AUTOPILOT MODE CONTROLLER (optional) ADAHRS 1 ADAHRS 2 (optional) IRIDIUM GLOBAL SATELLITE DATALINK...
  • Page 279 IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS GDU 1050A Primary Flight Display (PFD), 10-inch, or GDU 1250A, 12-inch (Optional) The Primary Flight Display, located directly in front of the pilot, is intended to be the primary display of flight parameter information (attitude, airspeed, heading, and altitude) during normal operations.
  • Page 280 ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS GCU 479 Flight Management System Keyboard The Flight Management System Keyboard is found on the upper section of the center console and is the primary interface for avionics system data entry, PFD/MFD operation, NAV/COM tuning, and course selection.
  • Page 281 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS Figure 7-18: Perspective+ Integrated Avionics System (1 of 2) 3 4 5 6 7 8 9 13 14 15 19 20 21 Legend 1. Soft Keys 12. MFD 2. PFD 13.
  • Page 282 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS Figure 7-18: Perspective+ Integrated Avionics System (2 of 2) Flight Management System Keyboard LEGEND 22. MFD Clear/Cancel Information 32. MFD Range/Pan Joystick 23. MFD Flight Plan Page 33. Frequency Transfer (121.5 Tune) 24.
  • Page 283 IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS GIA 63W/64W Integrated Avionics Units The Integrated Avionics Units, located behind the MFD and instrument panel, function as the main communication hub, linking all Integrated Avionics System components with the PFD. Each Integrated Avionics Unit...
  • Page 284 ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS Annunciation and Alert System Aircraft annunciations and alerts are displayed in the Crew Alerting System (CAS) window located to the right of the altimeter and VSI. Aircraft annunciations are grouped by criticality and sorted by order of appearance with the most recent message on top.
  • Page 285 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS While executing an LNAV/VNAV approach, between FAF and missed approach point (MAP), excessive deviation indicators appear as vertical yellow lines to indicate an area where the vertical deviation exceeds ±75 feet.
  • Page 286 IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS Serials w/ dual Air Data Computer (ADC) installations: The Outside Air Temperature (OAT) from the selected-side ADC will be used. If the OAT becomes invalid, the VDI on that side will be flagged as invalid. The pilot must select the off-side ADC sensor and VDI will return regardless of if prior to or after the FAF.
  • Page 287 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS Figure 7-19: Baro-VNAV Vertical Deviation Indicator 29.92 LEGEND NOTE 1.Excessive Deviation While Baro-VNAV is being utilized, Indicator the Glidepath Indicator appears as 2.Glidepath Indicator a magenta pentagon. SR22_FM07_5360 P/N 13772-006...
  • Page 288 7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS Optional Avionics GTX 345 Mode S Transponder w/ UAT in The GTX 345 solid state transponder communicates with the primary Inte- grated Avionics Unit, provides Modes A and C interrogation/reply capabil- ities, and performs the following functions: •...
  • Page 289 IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS 28 VDC for Satellite Datalink Receiver operation is supplied through the 5-amp WEATHER/DATA LINK circuit breaker on AVIONICS. Refer to the Perspective+ Integrated Avionics System Pilot’s Guide for a complete description of the system, its operating modes, and additional detailed operating procedures.
  • Page 290 ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS tion is supplied through the 3-amp DME/ADF circuit breaker on AVIONICS. Refer to the Perspective+ Integrated Avionics System Pilot’s Guide for a general description of the system and its operating modes. Refer to the Bendix/King DME System Pilot’s Guide for a detailed discus- sion of the system.
  • Page 291 PFD to improve pilot situational awareness during ground operations and air operations in the airport environment. Refer to the Cirrus Perspective+ Integrated Flight Deck Pilot’s Guide for a detailed discussion of the SurfaceWatch feature. Flight Stream 510 Wireless Avionics Interface The Flight Stream 510 Wireless Avionics Interface allows the connection of a compatible mobile electronic device to the avionics.
  • Page 292 This data can then be accessed by the pilot via a mobile application provided by Cirrus. The Gateway Module also provides access to the current status of aircraft consumables when the aircraft is unat- tended by remotely powering select systems on the aircraft when requested via the mobile application.
  • Page 293 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS Figure 7-20: Equipment Locations LEGEND 1. GSU 75 ADAHRS 1 2. Integrated Avionics Unit 1 3. GSU 75 ADAHRS 2 4. Avionics Cooling Fan 5. Integrated Avionics Unit 2 6. Engine Airframe Unit 7.

  • Page 294: Avionics Support Equipment

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 VIONICS Avionics Support Equipment Antennas Two rod-type COM antennas are mounted to the airplane’s exterior; COM 1 is mounted directly above the passenger compartment, COM 2 is mounted directly below the baggage compartment. These antennas are connected to the two VHF communication transceivers contained in the Integrated Avionics Units.
  • Page 295 ESIGN ECTION IRPLANE AND YSTEMS SR22 VIONICS The forward headset mics use the remote Push-To-Talk (PTT) switches located on the top of the associated control yoke grip. The rear headsets do not have COM transmit capabilities and do not require PTT switches.

  • Page 296: Cabin Features

    The transmitter is automatically activated upon sensing a change of velocity along its longitudinal axis exceeding 4 to 5 feet per second, or upon sensing deployment of the Cirrus Airframe Parachute System (CAPS). Once activated, the ELT transmits VHF band audio sweeps at 121.5 MHz until battery power is gone.
  • Page 297 7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 ABIN EATURES Figure 7-21: Artex ELT 1000 System CENTER CONSOLE (REF) ELT SHELF (REF) LEGEND 1. LED Annunciator 2. Remote Switch 3. Antenna 4 Remote Cable 5. Main Control Switch 6. Antenna Jack 7.

  • Page 298: Fire Extinguisher

    ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 ABIN EATURES To Use ELT portably The ELT transmitter can be removed from the airplane and used as a personal locating device if it is necessary to leave the airplane after an acci- dent.

  • Page 299: Hour Meters

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 ABIN EATURES Hour Meters The airplane is equipped with two hour meters located inside the armrest storage compartment between the pilot and copilot seats. The #1 hour meter, labeled HOBBS begins recording when the BAT 1 switch is ON and either the ALT 1 or ALT 2 switch is ON.

  • Page 300: Cirrus Airframe Parachute System

    YSTEM Cirrus Airframe Parachute System The airplane is equipped with a Cirrus Airframe Parachute System (CAPS) designed to bring the airplane and its occupants to the ground in the event of a life-threatening emergency. The system is intended to save the lives of the occupants but will most likely destroy the airplane and may, in adverse circumstances, cause serious injury or death to the occupants.

  • Page 301: Activation Handle

    7: A IRRUS ESIGN ECTION IRPLANE AND YSTEMS SR22 IRRUS IRFRAME ARACHUTE YSTEM A three-point harness connects the airplane fuselage structure to the para- chute. The aft harness strap is stowed in the parachute canister and attached to the structure at the aft baggage compartment bulkhead. The forward harness straps are routed from the canister to firewall attach points just under the surface of the fuselage skin.

  • Page 302: Deployment Characteristics

    7: A ECTION IRPLANE AND YSTEMS IRRUS ESIGN SR22 IRRUS IRFRAME ARACHUTE YSTEM The pin is inserted through the handle retainer and barrel locking the handle in the “safe” position. A “Remove Before Flight” streamer is attached to the pin.
  • Page 303 Airworthiness Directives ..............5 Airplane Inspection Periods..............5 Annual Inspection................5 100-Hour Inspection ................6 Cirrus Design Progressive Inspection Program ........ 6 Pilot Performed Preventative Maintenance ........7 Ground Handling ................. 8 Application of External Power ............8 Towing....................9 Taxiing.....................
  • Page 304 8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 Recommended Exterior Cleaning Products ........24 Care of Graphics ................25 Cleaning Interior Surfaces ..............29 Interior Windshield and Windows ............ 29 Instrument Panel and Electronic Display Screens......30 Headliner and Trim Panels .............. 30 Leather Upholstery and Seats ............

  • Page 305: Introduction

    This section provides general guidelines for handling, servicing, and main- taining your aircraft. In order to ensure continued safe and efficient opera- tion of your airplane, keep in contact with your Authorized Cirrus Service Center to obtain the latest information pertaining to your aircraft.

  • Page 306: Obtaining Publications

    Service Bulletin. Pay careful attention to the Service Advi- sory information. Obtaining Publications Pilot’s Operating Handbooks and aircraft service publications can be obtained from Cirrus at www.cirrusaircraft.com, or the Cirrus Connection at www.cirrusconnection.com. Airplane Records and Certificates The Federal Aviation Administration (FAA) requires that certain data, certificates, and licenses be displayed or carried aboard the airplane at all times.

  • Page 307: Airworthiness Directives

    ADs are mandatory changes and must be complied with within a time limit set forth in the AD. Operators should periodically check with Cirrus Service Centers or A&P mechanic to verify receipt of the latest issued AD for their airplane.

  • Page 308: 100-Hour Inspection

    Airframe and Powerplant (A&P) mechanic holding an Inspection Authorization (IA). Annual inspections can only be performed by facilities approved by Cirrus. The inspection is listed, in detail, in Chapter 5 of the Airplane Maintenance Manual.

  • Page 309: Pilot Performed Preventative Maintenance

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 IRPLANE NSPECTION ERIODS Pilot Performed Preventative Maintenance The holder of a Pilot Certificate issued under CFR Part 61 may perform certain preventive maintenance described in CFR Part 43, Appendix A. This maintenance may be performed only on an aircraft that the pilot owns or operates and which is not used in air carrier service.

  • Page 310: Ground Handling

    8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 ROUND ANDLING Logbook Entry After any of the above work is accomplished, appropriate logbook entries must be made. Logbook entries should contain: • The date the work was accomplished. • Description of the work.

  • Page 311: Towing

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 ROUND ANDLING To Remove External Power from Airplane If battery power is no longer required, set BAT 1 switch ‘off.’ Pull external power unit plug. Towing The airplane may be moved on the ground by the use of the nose wheel...

  • Page 312: Taxiing

    ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 ROUND ANDLING To obtain a minimum radius turn during ground handling, the airplane may be rotated around either main landing gear by pressing down on the fuselage just forward of the horizontal stabilizer to raise the nose wheel off the ground.

  • Page 313: Parking

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 ROUND ANDLING Parking The airplane should be parked to protect the airplane from weather and to prevent it from becoming a hazard to other aircraft. The parking brake may release or exert excessive pressure because of heat buildup after heavy braking or during wide temperature swings.

  • Page 314: Tie Down

    8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 ROUND ANDLING Tie Down The airplane should be moored for immovability, security, and protection. FAA Advisory Circular AC 20-35C, Tie-down Sense, contains additional information regarding preparation for severe weather, tie down, and related information.

  • Page 315: Servicing

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 ERVICING Servicing Landing Gear Servicing The main landing gear wheel assemblies use 15 x 6.00 x 6 tubeless tires. The nose wheel assembly uses a 5.00 x 5 tubeless tire. Always keep tires inflated to the rated pressure to obtain optimum perfor- mance and maximum service.

  • Page 316: Propeller Servicing

    8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 ERVICING To Inflate Tires Open access doors on wheel pants to gain access to valve stems. It may be necessary to move airplane to get valve stem aligned with the access hole.

  • Page 317: Fuel System Servicing

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 ERVICING • N • Mineral oil conforming to MIL-C-6529 Type II contains a corro- sion preventive additive and must not be used for more than 25 hours or six months, whichever occurs first. If oil consumption...
  • Page 318 8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 ERVICING To Refuel Airplane • CAUTION • Aviation grade 100 LL (blue) or 100 (green) fuel is the minimum octane approved for use in this airplane. Place fire extinguisher near fuel tank being filled.
  • Page 319 IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 ERVICING Fuel Contamination and Sampling Typically, fuel contamination results from foreign material such as water, dirt, rust, and fungal or bacterial growth. Additionally, chemicals and addi- tives that are incompatible with fuel or fuel system components are also a source of fuel contamination.

  • Page 320: Battery Service

    Service the oxygen system per the appropriate revision of the Precise Flight Instructions for Continued Airworthiness for the Cirrus SR22/SR22T Built-In Oxygen System, STC number SA01708SE, document number 102NPMAN0003.

  • Page 321: Artex Elt 1000 Servicing

    IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 ERVICING Artex ELT 1000 Servicing The ELT batteries must be inspected in accordance with the Airplane Maintenance Manual, 5-20 - Scheduled Maintenance Checks. The ELT batteries must be replaced upon reaching the date stamped on the batteries, after an inadvertent activation of unknown duration, or when- ever the batteries have been in use for one cumulative hour.
  • Page 322 ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 ERVICING multiple flashes separated by 1-second periods, will begin to display after approximately 1 second. Flash Codes displayed with the associated conditions are as follows: 1-Flash: Indicates that the system is operational and that no error conditions were found.

  • Page 323: Cleaning Exterior Surfaces

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 LEANING XTERIOR URFACES Cleaning Exterior Surfaces • CAUTION • Airplane serials with Ice Protection System: Do not wax leading edge porous panels. Refer to Section 9: Log of Supplements of this handbook for instructions and limitations for airplanes equipped with the Ice Protection System.

  • Page 324: Exterior Windshield And Windows

    8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 LEANING XTERIOR URFACES Exterior Windshield and Windows Before cleaning an acrylic window, rinse away all dirt particles before applying cloth or chamois. Never rub dry acrylic. Dull or scratched window coverings may be polished using a special acrylic polishing paste.

  • Page 325: Engine Compartment

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 LEANING XTERIOR URFACES To Clean EVS Sensor Windows Apply mild liquid soap and water or isopropyl alcohol, then wipe away with a soft, cotton cloth. Dry the sensor windows using a dry non-abrasive cotton cloth.

  • Page 326: Recommended Exterior Cleaning Products

    8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 LEANING XTERIOR URFACES collected, it may be necessary to brush areas that were sprayed, in order to clean them. Allow the solvent to remain on the gear from five to ten minutes. Then rinse the gear with additional solvent and allow to dry.

  • Page 327: Care Of Graphics

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 LEANING XTERIOR URFACES Care of Graphics Graphics require care similar to any fine paint finish. Use high quality products designed specifically for use on automobile finishes. Use products in accordance with the manufacturer’s instructions.
  • Page 328 8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 LEANING XTERIOR URFACES To Spot Clean Difficult Contaminants Difficult contaminants such as bugs, bird droppings, or tree sap may require spot cleaning. • CAUTION • To prevent scratching the graphic, refrain from rough scrubbing and the use of abrasive tools.
  • Page 329 8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 LEANING XTERIOR URFACES Graphic Restoration If typical cleaning methods fail to produce satisfactory results, refer to the recommended restoration products and mixtures below to help preserve the condition of the graphics on your aircraft.
  • Page 330 8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 LEANING XTERIOR URFACES Recommended Graphic Restoration Products and Mixtures Film or Finish Type Cleaning Product or Mixture Supplier Smooth Gloss 3M™ Perfect-it™ Show Car Paste 3M Company Wax 39526 Meguiar's Gold Class™ Carnuaba...

  • Page 331: Cleaning Interior Surfaces

    8: H IRRUS ESIGN ECTION ANDLING AND ERVICING SR22 LEANING NTERIOR URFACES Cleaning Interior Surfaces Seats, carpet, upholstery panels, and headliners should be vacuumed at regular intervals to remove surface dirt and dust. While vacuuming, use a fine bristle nylon brush to help loosen particles.

  • Page 332: Instrument Panel And Electronic Display Screens

    8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 LEANING NTERIOR URFACES Instrument Panel and Electronic Display Screens The instrument panel, control knobs, and plastic trim need only to be wiped clean with a soft, damp cloth. The multifunction display, primary...

  • Page 333: Leather Upholstery And Seats

    For deeper cleaning, start with mix of mild detergent and water and, if necessary, work your way up to the products available from Cirrus for more stubborn marks and stains. Do not use soaps as they contain alka- line which will alter the leather’s pH balance and cause the leather to age...
  • Page 334 8: H ECTION ANDLING AND ERVICING IRRUS ESIGN SR22 LEANING NTERIOR URFACES Recommended Interior Cleaning Products Cleaning Application Cleaning Product Supplier Interior Windshield Plastic and Glass Prist Aerospace and Windows Cleaner Display Screens Optimax PhotoDon Cabin Interior Mild Dishwasher Any Source...
  • Page 335 9: L IRRUS ESIGN ECTION OG OF UPPLEMENTS SR22 Section 9: Log of Supplements Table of Contents As Required P/N 13772-006 Reissue A...
  • Page 336 This Log of Supplements shows all Cirrus Supplements available for the aircraft at the corresponding date of the revision level shown in the lower left corner.
  • Page 337 Table of Contents Introduction..................3 Taxiing, Steering, and Braking Practices ..........3 Operating Practices................4 Brake Maintenance ................4 Cirrus Airframe Parachute System (CAPS)......... 5 Deployment Scenarios ..............5 Mid-Air Collision ................6 Structural Failure ................6 Loss of Control ................6 Landing Required in Terrain not Permitting a Safe Landing....
  • Page 338 10: S ECTION AFETY NFORMATION IRRUS ESIGN SR22 Intentionally Left Blank 10-2 P/N 13772-006 Reissue A...

  • Page 339: Introduction

    Taxiing, Steering, and Braking Practices Cirrus aircraft use a castering nose wheel and rely on aerodynamic forces and differential braking for directional control while taxiing. Proper braking practices are therefore critical to avoid potential damage to the brakes.

  • Page 340: Operating Practices

    10: S ECTION AFETY NFORMATION IRRUS ESIGN SR22 AXIING TEERING RAKING RACTICES Operating Practices When taxiing, directional control is accomplished with rudder deflection and intermittent braking (toe taps) as necessary. Use only as much power as is necessary to achieve forward movement. Deceleration or taxi speed control using brakes but without a reduction in power will result in increased brake temperature.

  • Page 341: Cirrus Airframe Parachute System (Caps)

    Cirrus also recommends that pilots discuss CAPS deployment scenarios with instructors as well as fellow pilots through forums such as the Cirrus Owners and Pilots Association. In the event of a spin or loss of aircraft control, immediate CAPS activation is required. (See Section 3) In other situations, CAPS activation is at the informed discretion of the pilot in command.

  • Page 342: Mid-Air Collision

    CAPS activation is strongly recommended. Numerous fatalities that have occurred in Cirrus aircraft accidents likely could have been avoided if pilots had made the timely decision to deploy CAPS.

  • Page 343: Pilot Incapacitation

    10: S IRRUS ESIGN ECTION AFETY NFORMATION SR22 (CAPS) IRRUS IRFRAME ARACHUTE YSTEM Pilot Incapacitation Pilot incapacitation may be the result of anything from a pilot's medical condition to a bird strike that injures the pilot. If incapacitation occurs and the passengers are not trained to land the aircraft, CAPS activation by the passengers is highly recommended.

  • Page 344: Deployment Attitude

    10: S ECTION AFETY NFORMATION IRRUS ESIGN (CAPS) SR22 IRRUS IRFRAME ARACHUTE YSTEM Deployment Attitude The CAPS has been tested in all flap configurations at speeds ranging from to V . Most CAPS testing was accomplished from a level attitude.

  • Page 345: Water Landings

    10: S IRRUS ESIGN ECTION AFETY NFORMATION SR22 (CAPS) IRRUS IRFRAME ARACHUTE YSTEM There is the possibility that one or both doors could jam at impact. If this occurs, to exit the airplane, the occupants will have to force open a partially jammed door or break through a door window using the Emergency Exit Hammer located in the lid of the center armrest.

  • Page 346: Ground Gusts

    10: S ECTION AFETY NFORMATION IRRUS ESIGN (CAPS) SR22 IRRUS IRFRAME ARACHUTE YSTEM Ground Gusts If it is known or suspected that ground gusts are present in the landing zone, there is a possibility that the parachute could drag the airplane after touchdown, especially if the terrain is flat and without obstacles.

Table of Contents

Save PDF
