1. DESCRIPTION
This section covers that portion of the system which provides information to determine position from
sources which are mainly independent of ground installations. This includes the Stormscope, SkyWatch,
Terrain Awareness and Warning System (TAWS), Synthetic Vision System, and Garmin Traffic System
(GTS 800).
A. Stormscope System
The Stormscope system consists of an antenna located on top of the fuselage and a processor unit
mounted under the aft baggage floor. The antenna detects the electrical and magnetic fields generated
by intra-cloud, inter-cloud, or cloud to ground electrical discharges occurring within 200 nm of the air-
plane and sends the "discharge" data to the processor. The processor digitizes, analyzes, and con-
verts the "discharge" signals into range and bearing data and communicates the data to the MFD
every two seconds.
Serials 22-0002 thru 22-1086: The Stormscope system is powered by 28 VDC through the 3-amp
STORMSCOPE circuit breaker on the Avionics Non-Essential Bus.
Serials 22-1087 & subs w/o Perspective Avionics: The Stormscope system is powered by 28 VDC
through the 3-amp WEATHER/STORMSCOPE circuit breaker on the Avionics Non-Essential Bus.
Serials w/ Perspective Avionics: The Stormscope system is powered by 28 VDC through the 3-amp
WEATHER circuit breaker on the Avionics Bus.
For additional information on the Stormscope system, refer to the Stormscope WX-500 User's Guide.
(Refer to 05-10)
B. SkyWatch System
Serials w/o Perspective Avionics: The SkyWatch system consists of an antenna located on top of the
fuselage and a Transmitter Receiver Computer (TRC) box installed below either the RH (Serials 22-
0002 thru 22-1601, 22-1603 thru 22-1820, 22-1822 thru 22-1839, 22-1841 thru 22-1862) or LH cabin
seat (Serials 22-1602, 22-1821, 22-1840, 22-1863 & subs, 22T-0001 & subs). SkyWatch is an airborne
Traffic Advisory System (TAS) that monitors airspace by interrogating transponder-equipped aircraft in
the area and determining if a collision threat exists. Traffic advisories are indicated on the MFD and
GNS 430 displays. Aural "Traffic, Traffic" warnings are announced in the headphones and cabin
speaker.
Serials 22-0002 thru 22-1601, 22-1603 thru 22-1643, 22-1645 thru 22-1662 after SB 2X-34-18, 22-
1602, 22-1644, 22-1663 & subs, 22T-0001 & subs: To minimize distractions during critical phases of
flight, the SkyWatch aural warnings are inhibited and system sensitivity is decreased when the flap
switch is set to either the 50% or 100% positions. For maintenance practices pertinent to the flap
switch, see Flaps.
Serials 22-0002 thru 22-1035: The SkyWatch system is powered by 28 VDC through the 5-amp SKY-
WATCH circuit breaker on the Avionics Non-Essential Bus.
Serials 22-1036 & subs w/o Perspective Avionics: The SkyWatch system is powered by 28 VDC
through the 5-amp SKYWATCH/TAWS circuit breaker on the Avionics Non-Essential Bus.
Serials w/ Perspective Avionics: The L-3 Skywatch HP system consists of an antenna located on top of
the fuselage and a Transmitter Receiver Computer (TRC) box installed on bulkhead 222 in the empen-
nage. Skywatch is an airborne Traffic Advisory System (TAS) that advises the pilot of transponder-
equipped aircraft that may pose a collision threat. Traffic advisory information is displayed on the MFD
and indicates the relative range, bearing, and altitude of intruder aircraft. The system utilizes inputs
from the secondary Integrated Avionics Units via the primary Air Data Computer and is controlled via
the MFD or Flight Management System Keyboard. The SkyWatch system is powered by 28 VDC
through the 5-amp TRAFFIC circuit breaker on the Avionics Bus.
EFFECTIVITY:
All
INDEPENDENT POSITION DETERMINING
(Refer to 27-50)
M O D E L S S R 2 2 A N D S R 2 2 T
34-40
Page 1
15 Jun 2010
