TROUBLESHOOTING

In the event of a calibration failure using the ALCOSIM simulator, consult the
"Troubleshooting — Error Codes" section of the ALCOSIM Breath Alcohol Simulator
Instruction Manual (ACS #60-000180).
If a calibration fails while using a gas standard cylinder, it may be due to the following:
•
Vinyl tubing has been overused or condensation is present
•
The gas standard cylinder is expired or is empty
•
All connections to and from the gas valve are not secured properly

ERROR TABLE

The ALERT J4X screen will display an error message if the calibration fails.
E21 CAL Fact too Lo
E22 CAL Fact too Hi
E23 0 BAC in CAL
E24 BAC too low in CAL
E25 BAC too high in CAL
CALIBRATION MANUAL
The calibration was not successful.
The calibration was not successful.
Solution used to calibrate with is not correct (0 BAC).
Solution used to calibrate with is not correct (BAC too low).
Solution used to calibrate with is not correct (BAC too high).
