Assa Abloy HES iCLASS IC0020 Installation Supplement

iCLASS Module
1
Dielectric Grease (apply to connections in humid applications)
2
#6-32 Module Mounting Screws (for optional strike mount)
3
Reader/Antenna Body
4
#6-32 Reader/Antenna Screws
5
Reader/Antenna Mounting Plate
6
18" Cable (connecting reader/antenna and iCLASS module)
7
2 pin DPS & LBM Pigtail Connector
8
Dielectric
Grease
2
Access Control System
Control Panel and Power Supply
(By others)
Wiring Diagram
Operating Voltage 12 to 24 VDC +/- 10%
Operating Current 125 mA Max @ 12VDC
Cable Detail
Distance to Host 500 ft Max
Recommended Type 18-22 AWG
(Dependent on distance) Stranded and shielded
Compliance FCC Part 15/IC Class B
Door Position Sensor (DPS)
Contact Rating 300ma @ 30VDC
Switch Type Form A (SPST) Reed
Installation Supplement
IC0020: iCLASS
To be used when IC0020 is added to an electric strike
7
6
5
4
3
-or-
9
11
8
To Access Control System
8 Pin Connector (iCLASS Module) Pigtail
Red (+) Board Power
-
Black ( ) Board Power
Green Data 0
White Data 1
Yellow LED/Buzzer
Blue Not Used
Orange Not Used
Brown Not Used
® Module
4 pin 12V Strike Power Pigtail
9
4 pin 24V Strike Power Pigtail
Data Connector (connects to iCLASS Module)
10
8 pin Connector (iCLASS Module) Pigtail
11
Door Position Sensor (DPS)
12
DPS/LBM Adapter
13
13
To Electric Strike LBM
To Electric Strike power
1
The iCLASS Module can be supported by the
electrical connection to the electric strike, or
by mounting it directly to the back of some
models of HES electric strikes using the #6-32
module mounting screws. Do not attempt to
support the iCLASS Module with the 18"
antenna cable.
10
4 Pin Connector (12V Strike Power)
11
Red (12VDC +) Strike Power
Black (−) Strike Power
OR
4 Pin Connector (24V Strike Power)
Violet (24VDC +) Strike Power
Black ( - ) Strike Power
2 pin Connector (LBM Pigtail)
Tan Common
Pink Door Closed and Latch Engaged
HES, Inc.
Phoenix, AZ
800-626-7590
www.hesinnovations.com
12
9
Card reader
Interfaces with any Weigand-compatible access
control system
Supported credential formats
9
All iCLASS
MIFARE 14443A Read Only
ISO 15693, 14443A, 14443B (MIFARE CSN ONLY)
MIFARE transmits Wiegand data based on card
8
serial number in 26, 32, 34, 37, 40, 56 bit formats
3
HID 13.56 MHz
