- Page 1 PV-ezRack SolarFloating I Installation Guide V1.0 0 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn...
- Page 2 Ensuring that PV-ezRack and other products are appropriate for the particular installation and the installation environment. Using only PV-ezRack parts and installer-supplied parts as specified by Clenergy (substitution of parts may void the warranty and invalidate the letter of certification). Recycling: according to local related statutes.
-
Page 3: Tools And Components
Traction boat Life jacket and lifebuoy Temporary fixed rope 2 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn... - Page 4 HDPE Washer, Self-drilling screw HDPE Bolt 3 Rear Clamp T15mm ST6.3*25 3 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn...
-
Page 5: System Overview
②Apply lubricant (grease or 40# engine oil) to fasteners prior to tightening to avoid galling or seizing in the threads; 3.2.2General installation instructions 4 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn... - Page 6 3.2.3 Safe Torques Please refer to safe torques defined in this guide. If power tools are required, Clenergy recommends the use of low speed only. High speed and impact drivers increase the risk of bolt galling (deadlock). If deadlock occurs and you need to cut fasteners, please make sure that there is no load on the fastener before you cut it.
- Page 7 6 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn...
-
Page 8: Installation Instruction
Main Floater. After completion, shown in Figure 4. Figure 3 7 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn... - Page 9 Figure 5 and Figure 6. Figure 5 8 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China...
- Page 10 Figure 7. 9 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China...
- Page 11 Bolt HDPE Bolt Figure 9 HDPE Bolt 3 to the 10 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn...
- Page 12 Figure 12 same, and then lock the M8 bolt and nut .The 11 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China...
- Page 13 Figure 15 block anchoring. The length of the anchor rope determined 12 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China sales@clenergy.com.cn...
- Page 14 4.6.3 Mark the depth of the floater in water. 13 / 13 Clenergy China Telephone +86 592 311 0088 999-1009 Min'an Rd, Huoju Hi-tech Ind. Dev. Zone Facsimile +86 592 599 5028 Xiang'an District 361101, Xiamen, Fujian, China...
