TEMCO FIREPLACE PRODUCTS, Inc.
UNIVERSAL CUSTOM HOME VENT-FREE FIREBOX
MODELS: ADCH39F and ADCH45F
These fireboxes are approved as universal fireboxes and can be paired with any ANSI Z21.11.2 approved
vent-free log set.
The vent-free log manufacturer's instructions - including their required dimensional
clearances for firebox size - must be followed.
Refer to the manual that is packed with the log set for operating instructions
This book contains your installation instructions and should
be kept in a safe place.
advantages and use of the reliable service that has been
engineered into your TEMCO fireplace, you must carefully
follow all of the instructions contained in this book regarding
installation and operation of the fireplace.
These instructions should be read carefully in their entirety
before beginning installation of the fireplace.
It is suggested that you wear work gloves and safety
glasses to protect your hands and eyes when installing your
fireplace.
CLASSIFIED
UNVENTED GAS
FIREPLACE
ACCESSORY
Click here to print
INSTALLATION INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
PRESTIGE SERIES
For you to realize all the
NOTE:
Authorities having jurisdiction (i.e. building
inspectors, fire marshals, etc.) should be consulted before
installation to determine the need to obtain a permit.
The following optional accessories are available for use
with your fireplace.
Decorative Louver Trim Kit - (polished brass finish)
Flush Panel Kit -
Heat Reducing Canopy - UC42, UC36
Brick Canopy - BC42 (For ADCH45F), BC36 (For
ADCH39F)
P.O. Box 1349 Manchester, TN 37349
P.O. Box 1148 Perris, CA 92572
A subsidiary of Temtex Industries, Inc.
REV. 8/28/02 12:49 PM
76345J
Advertisement
Table of Contents
Related Manuals for Temco PRESTIGE Series
Summary of Contents for Temco PRESTIGE Series
- Page 1 TEMCO fireplace, you must carefully follow all of the instructions contained in this book regarding The following optional accessories are available for use installation and operation of the fireplace.
-
Page 2: Table Of Contents
CONTENTS Planning Ahead ....................................Page 3 Choosing a location ....................................3 Gas line ........................................3 Drafts ........................................3 Fireplace clearances ....................................4 Installing the Firebox ....................................4 Step 1: Framing the firebox ..................................4 Step 2: Installing the firebox .................................4 Step 3: Leveling the firebox ..................................4 Step 4: Securing the firebox .................................4 Step 5: Gas piping and connection ..............................5 Step 6: Cold climate installation ................................5 Finishing the Fireplace ....................................6... -
Page 3: Planning Ahead
PLANNING AHEAD CHOOSING THE LOCATION FOR YOUR Figure 1 FIREPLACE: Figure 1 shows some of the many ways your fireplace may be installed. Consider the traffic pattern in your room and the location of doors and windows. Moving air from ceiling fans, open doors and hot air grills may cause the flames to soot. -
Page 4: Fireplace Clearances
less than 42" from the top of the fireplace opening. FIREPLACE CLEARANCES The fireplace may be placed directly on a combustible floor, 3. Mantel Clearances: against a combustible wall at marked clearances or on a A. If the fireplace has no mantelpiece, then the heat raised wooden platform. -
Page 5: Step 5: Gas Piping And Connection
Figure 4 Step 5: Gas Piping and Connection The gas piping must be installed in accordance with local codes or, in the absence of local codes, in accordance with the National Fuel Gas Code, ANSI Z223.1, latest edition. The normal gas connection is 1/2" NPT, made at the left side facing the unit. -
Page 6: Finishing The Fireplace
Always check for gas leaks after servicing. REPAIR PARTS A parts list follows. Always include correct name, part TEMCO FIREPLACE PRODUCTS, Inc. number and model number of the appliance when ordering P. O. Box 1349 Manchester, TN 37349 service parts. -
Page 7: Warranty Information
ONE YEAR WARRANTY TEMCO warrants all components of the Product to be free of defects in materials and workmanship for a period of one year from the date of installation, with the exception of the warranty on logs and ember base. -
Page 8: Installation And Startup Checklist
INSTALLATION AND STARTUP CHECKLIST Customer Copy NOTE: TEMCO gas logs and fireplaces require installation by a qualified gas appliance installer. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement. - Page 9 INSTALLATION AND STARTUP CHECKLIST Installer’s Copy NOTE: TEMCO gas logs and fireplaces require installation by a qualified gas appliance installer. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement.
-
Page 10: Warranty Registration
CUSTOMER COPY Model # __________________________________________ Serial #_________________________________________ I certify that I have followed all codes and regulations and adhered to the TEMCO installation instructions. I have completed the proper installation and startup checklist. Installers Signature Print Installer’s Name WARRANTY REGISTRATION...
