Parker OSPP-Classic Operating Instructions Manual page 29

Replacement Parts OSPP-Classic Ø 16 - 80
Item
Description
(Pos. No.)
1,2 Cylinder barrel with magnetstrip **
10 Mounting
11 Outer sealing band cut to stroke **
12-16,26 Clamping piece Kit stainless
17 Inner sealing band cut to stroke **
20 Cushioning spigot
25 Support ring white
25 Support ring red
25 Support ring green
27 Piston yoke
35 End cap standard complete
35 End cap standard complete Viton
35 End cap, end air port, complete
35 End cap, end air port, complete Viton
35 End cap, single side left, complete
35 End cap, single side right, complete
35 End cap, single side left, compl., Viton
35 End cap, single side right, compl., Viton
36 Screw for end cap (set 8 pcs.)
36 Screw for end cap stainless (set 8 pcs.)
60 Grease standard, Tube 25 gr
60 Grease slow speed < 0.2m/s, tube 25 gr
Pos. Description
1, 2 Cylinder barrel with magnetstrip
5 Counter sunk screw for cover
6 Spring for wiper, stainless
7 O-Ring for scraper
8 Scraper
9 Wiper cover
10 Mounting
11 Outer sealing band cut to stroke
12 Clamp cap
13 Clamping screw for outer band
14 Clamping piece for outer band
15 Clamping screw for inner band
16 Clamping piece for inner band
17 Inner sealing band cut to stroke
18 O-Ring for end cap, outer
19 O-Ring for end cap, inner
20 Cushioning spigot
* Please use this order pattern: IDENT-NO. + „FIL", example piston yoke Ø 25: 11349FIL
** Please use this order pattern: IDENT-NO. + „stroke in mm" (5-digits),
Example: Cylinder barrel with magnetstrip Ø 16 (1000 mm stroke): 10346-01000
Ident - No. *(**)
Ø 16 Ø 25 Ø 32
10346 10002 10293
11384 11350 11382
10348 10004 10295
21701 21702 21702
10347 10003 10294
10310 10028 10265
10303 10008 10268
10325 10009 10276
10326 10010 10277
11378 11349 11379
20530 20534 20542
20531 20535 20543
20532 20536 20544
20533 20537 20545
- 20538 20546
- 20540 20548
- 20539 20547
- 20541 20549
21720 21721 21722
21727 21728 21729
Pos. Description
21 O-ring for cushioning spigot
22 Cushioning disk
23 Cushioning seal
24 Piston seal
25 Support ring
26 Inlay nut
27 Piston yoke
28 Slide shoe
29 Keeper plate for magnet
30 Magnet
31 Wiper (side)
35 End cap
36 Screw for end cap
38 Screw for Mounting
39 Nut for Mounting
40 Al-Keeper for magnet
60 Grease
29
Ø 40 Ø 50 Ø 63
10062 10232 10381
11353 2502 -
10064 10234 10367
21703 21703 21703
10063 10233 10380
10086 10205 10363
10067 10211 10368
10068 10219 10369
10069 10220 10370
11351 11380 11386
20550 20558 20566
20551 20559 20567
20552 20560 20568
20553 20561 20569
20554 20562 20570
20556 20564 20572
20555 20563 20571
20557 20565 20573
21723 21724 21725
21730 21731 21732
1598
3185
EN
Ø 80
10417
-
10419
21704
10418
10405
10421
10422
10423
11387
20574
20575
20576
20577
20578
20580
20579
20581
21733
21733
