D C 5 9 0 P R S e r i e s D C D i g i t a l D r i v e
S E R I E S
This QuickStart will:
Provide basic installation details.
Select right field current
Start the motor and perform an Autotune
Provided with every Drive is a:
QuickStart
Safety Information
Keypad (optional)
This QuickStart assumes that:
You have read and understood the Safety Information provided separately.
HA860001U001
Compact disk containing the Product Manual and
Configuration Tool
Option cards (optional)
I S S U E 1
Q
u
i
c
k
S
t
a
r
t
Q
u
i
c
k
S
t
a
r
t
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Parker DC590PR Series
Summary of Contents for Parker DC590PR Series
- Page 1 I S S U E 1 HA860001U001 D C 5 9 0 P R S e r i e s D C D i g i t a l D r i v e S E R I E S This QuickStart will: ...
-
Page 2: Mechanical Installation
Mechanical Installation NOTE Refer to the Safety and EMC sheets provided with the drive. Mount the unit vertically inside a suitable cubicle. Drill mounting holes accurately. Check for material that could damage/restrict operation. Fit 4 x inserts into the back panel ... -
Page 3: Electrical Installation
Electrical Installation NOTE Refer to the Safety and EMC sheets provided with the drive. An EMC compliant installation is shown. Earth/Ground Connections IMPORTANT Refer to "Permanent Earthing" on the Installation Diagram. Earth/Ground Rails Provide a (dirty) earth/ground rail (11) inside the cubicle. Connect it to an external earth/ground, PE. Provide a (clean) earth/ground rail (2) inside the cubicle, connected directly to the (dirty) earth/ground rail and insulated from the mounting panel. - Page 4 Installation Diagram * Permanent Earthing The unit must be permanently earthed according to EN 50178: A cross-section conductor of at least 10mm required. This can be achieved by using a single conductor (PE) or by laying a second conductor through separate terminals (PE2 where provided) and electrically in parallel.
- Page 5 Control Connections for Local Control Refer to the Installation Diagram Control wiring must have a minimum cross-section area of 0.75mm (18AWG) Use screened control cables to comply with EMC requirements Current Limit Connection to allow the MAIN CURR. LIMIT parameter to adjust the current limit. (fixed) Removing B8 from C9 (24V) causes a Program Stop (regenerative drive only) Removing B9 from C9 (24V) causes a Coast Stop...
-
Page 6: Power Connections
Power Connections Refer to the Installation Diagram Minimum rating of 1.1 x full load current (Europe) Minimum rating of 1.25 x full load current (UL) - Page 7 Auxiliary the contactor holding VA, or MCB. Supply Connect auxiliary supply terminals directly to the incoming supply. No series sequencing switches or contacts are permitted without consultation from Parker External Connect the contactor coil to terminals CL1& CL2 Contactor Connect motor thermal switch or thermistor to TH1, TH2. Drive will trip when the thermal switch opens, or when the thermistor resistance exceeds 4k...
- Page 8 Drive Set-Up in Local Control IMPORTANT You must not exceed the maximum drive and motor ratings. Refer to the Product Code or rating label, and the motor rating plate The instructions are written in logical order. Complete each stage successfully before progressing to the next. This simple start-up routine assumes that: ...
-
Page 9: Calibrating The Control Board
2: Calibrating the Control Board CONNECT THE AUXILIARY SUPPLY: Remove 3-phase fuses (6). Re-instate branch circuit protection or circuit breaker (8). Check that the auxiliary voltage is correct. The Keypad will now display the Welcome screen. AUXILIARY POWER ONLY IS CONNECTED AT THIS STAGE Press to display the CONFIGURE DRIVE menu. -
Page 10: Initial Start-Up Routine
3: Initial Start-Up Routine AUXILIARY POWER ONLY IS CONNECTED AT THIS STAGE Complete steps 3.1 to 3.12 3.2 Check that ANIN 5 (A6) is Write down the MAIN CURR. LIMIT parameter’s value +10V. If not, check the here: wiring link between terminals A6 and B3. - Page 11 ISOLATE THE DRIVE using branch circuit protection Select Local Control on the FORWARD or circuit breaker (8). Keypad. Refer back to 3.4 for REF: 0.00 % how to do this. Install the 3-phase fuses (6). This will display the local Re-instate branch circuit protection or circuit breaker speed setpoint: 0.00%.
-
Page 12: Auto Tuning
Caution During the following set-up instructions, be ready to STOP the drive should the motor try to overspeed. 3.10 Set the speed setpoint to 5%. FORWARD Press the PROG key to display (toggle) the main menu system. REF: 5.00 % 3.11 Refer back to 2.1 to display the CONFIGURE DRIVE menu. - Page 13 Optional Equipment Motor Field current range switch selection (SW1 on power board) CHAPTER 4 Selecting Speed Feedback Initial Start-up Routine (the full routine will help with any additions you make) Performance Adjustment (any parameter changes will require another Autotune) *HA860001U001_01* www.parker.com...
- Page 14 Converting to Remote Control ISOLATE THE DRIVE using branch circuit protection or circuit breaker (8). This description assumes you have completed the "Drive Set-Up in Local Control". EMERGENCY STOP RELAY SETPOINT RAMP INPUT CLEAN EARTH The 10K potentiometer adjusts the speed setpoint: Speed Demand Zero speed = Terminal A1, 0V input (Uni-directional)
- Page 15 By default, Remote Control is already selected on the Keypad (the SEQ and REF LEDs are not lit). Your control connections will be used to start, stop, and control the speed of the drive. Refer back to 2.1 to display the CONFIGURE DRIVE menu. Set the MAIN CURR.
- Page 16 Electrical Ratings - Power Circuit Refer to Chapter 3: “Earth Fault Monitoring Systems” for circuit breaker details. Motor HP ratings as NEC Table 430-247: “Full Load Current in Amperes, DC Motors The ratings assume that the armature discontinuous current level is at or below the armature average current rating. Surroundin Output Output Current @ 100%...
-
Page 17: Power Supply Details
1. Field current range switch (SW1) has been provided on power board for improved resolution at low field current 2. The maximum externally supplied field current is 15A for Frame1 but requires de-rating of the armature output current (amp for amp) above 10A, and only apply for operation at or below 35C ambient. 3. -
Page 18: Auxiliary Power Supply Details
Auxiliary Power Supply Details Auxiliary Supply 110-240V ± 10%, 50-60Hz 10%, single phase, Overvoltage Category II 3A ac rms maximum. Nominal current used for power supplies: 0.5A at 110V ac, 0.25A at 240V ac Contactor Output 3A maximum at the auxiliary voltage The drive is powered-up and operating safely under Remote Control using Armature Volts Feedback.
