Installation Instructions – HDF LED
3.
Chain Mounting Bracket:
Figure 9. Chain Mounting Bracket
Step 1: Place the Chain Mounting Bracket to the fixture as shown and orient it in the desired direction.
Step 2: Close the Latch Brackets.
Step 3: Mount the chain to the Bracket.
Mounting the Fixture:
Attach the Ceiling Mounting Brackets to a structural support using Customer Mountings.
Customer Provided Mounting
Chain
Bracket
Figure 10. HDF Chain Mounting to Ceiling
5
COOPER LIGHTING SOLUTIONS
IB519082EN
Installation Instructions
