GB Instruction for use

Lietošanas pamācība

POWERTEX

Aluminum Chain Block PACB-S1

User Manual

Need help?

Do you have a question about the PACB-S1 and is the answer not in the manual?

Questions and answers

Summary of Contents for POWERTEX PACB-S1

Page 1 GB Instruction for use Lietošanas pamācība POWERTEX Aluminum Chain Block PACB-S1 User Manual...
Page 2 POWERTEX Chain Block PACB-S1 0,25 – 3 ton Instruction for use (GB) (Original instructions) Read through these user instructions carefully before using the chain block. Improper operation may lead to hazardous situations! General safety provisions • Only to be used by trained operator.
Page 3 Function The load hook is raised or lowered by pulling on the hand chain. The load will remain where it is even when the hand chain is released because of the effective reaction brake. Suspension of chain block Suspend the block from an eye, shackle, girder trolley etc. with sufficient load capacity. With the chain tightened, both hooks must be vertically aligned.
Page 4 Defective hooks must be replaced before using the chain block again. FIG. 3 The chain must not be twisted Fig. 4 Load hook Table 1 Load hook WLL t 0,25 Model PACB-S1 PACB-S1 PACB-S1 PACB-S1 PACB-S1 Dimension E nominal mm 35,5...
Page 5 EN 818-7, Grade T from the following manufacturers: Chaineries Limousines, Pewag, Kito Chain, Retezarna or Rud. Repairs The chain block must not be modified. Repairs must be carried out by specialists. Damaged parts must only be replaced with original Powertex spare parts. Order them through your dealer.
Page 6 POWERTEX ķēdes bloks PACB-S1 0,25 – 3 tonnas Lietošanas pamācība (LV) Pirms ķēdes bloka izmantošanas izlasiet šo lietošanas pamācību. Nepareiza lietošana var būt bīstama! Vispārēji drošības noteikumi • Drīkst izmantot tikai apmācīta persona. • Nelietojiet sprādzienbīstamā vai korozīvā vidē. •...
Page 7 Darbība Velkot rokas ķēdi, tiek pacelts vai nolaists kravas āķis. Efektīvā bremze notur kravu nekustīgā stāvoklī, pat ja tiek atlaista rokas ķēde. Ķēdes bloka piekāršana Piekariniet ķēdes bloku pie pietiekami izturīgas cilpas, skavas, sijas troleja utt. Kad ķēde ir nostiepta, abiem āķiem ir jāatrodas vertikālā stāvoklī. Uzmanību! Bloku, āķus un kravas ķēdi nedrīkst pakļaut lieces spēka iedarbībai.
Page 8 Pirms atsākt lietot ķēdes bloku bojātie āķi ir jānomaina. Rätt Pareizi Nepareizi 3. attēls. Ķēde nedrīkst būt sagriezusies 4. attēls. Kravas āķis 2. tabula. Āķu izmēri Maksimālā slodze tonnas 0,25 Modelis PACB-S1 PACB-S1 PACB-S1 PACB-S1 PACB-S1 Izmērs E nominālais mm 35,5 49,5 58,5 61,9 Izmērs E maksimālais mm...
Page 9 Remontdarbi Ķēdes bloku nedrīkst modificēt. Remontdarbus drīkst veikt tikai speciālisti. Bojātās detaļas ir jānomaina ar oriģinālām Powertex detaļām. Pasūtiet tās pie sava piegādātāja. Periodisko pārbaužu kontrolsaraksts (parasti – reizi gadā, ja nepieciešams – biežāk) Ikdienas Reizi gadā Pārbaudes objekts Pārbaudes metode Piezīme...
Page 10 POWERTEX Chain Block PACB-S1 – Spare parts 0,25 - 3 t When ordering spare parts, specify model, WLL, part number and the quantity needed. When ordering chain, also specify lifting height. If the load chain has been damaged or worn out the load sheave probably has to be replaced.
Page 11 Spare parts list 0,25 t Pos Description Qty. 250 kg 500 kg 1000 kg 2000 kg 3000kg Warning tag 16.10PACBS10250-1 16.10PACBS10500-1 16.10PACBS11000-1 16.10PACBS12000-1 16.10PACBS13000-1 Screw and washer 16.10PACBS10250-2 16.10PACBS10500-2 16.10PACBS11000-2 16.10PACBS12000-2 16.10PACBS13000-2 Hand wheel cover 16.10PACBS10250-3 16.10PACBS10500-3 16.10PACBS11000-3 16.10PACBS12000-3 16.10PACBS13000-3 Lock nut 16.10PACBS10250-4 16.10PACBS10500-4...
Page 13: Warning Tag
Standard: EN 13157 Warning tag The warning tag shows some specific and important situations, in which you must pay special attention, when using POWERTEX Chain Blocks and Lever Hoists. User Manuals You can always find the valid and updated User Manuals on the web.
Page 14 Canary Islands www.powertex-products.com...
