Summary of Contents for Wesemann SYSTEM DELTA 30
- Page 1 SYSTEM DELTA 30 LABORATORY FUME CUPBOARD I USER MANUAL...
- Page 3 SYSTEM DELTA 30 LABORATORY FUME CUPBOARD I USER MANUAL...
-
Page 5: Table Of Contents
List of Contents 1 INTRODUCTION 06-09 2 SAFETY 10-17 3 PRODUCT DESCRIPTION 18-39 4 PUTTING FUME CUPBOARD INTO OPERATION 40-51 5 MEDIUM SYSTEM: ARMATURES 52-59 6 CHEMICAL RESISTANCE 60-71 7 CLEANING OF FUME CUPBOARDS 72-81 8 INSPECTION AND MAINTENANCE OF FUME CUPBOARDS 82-87 9 SPARE-PARTS LIST AND PROTOTYPE TEST REPORT 88-90... - Page 6 User Manual | Laboratory Fume Cupboard | Introduction...
- Page 7 User Manual | Laboratory Fume Cupboard | Introduction 1 INTRODUCTION Preamble Product variants Other applicable documents Text design EU Declaration of Conformity Type plate with connection parameters...
-
Page 8: Introduction
Keep these instructions in a safe place for further use. In the event of a sale of the laboratory fume cupboard, this manual must also handed over to the buyer. Wesemann GmbH does not accept liability for damage caused by non-observance of the user manual. Product variants These instructions apply to the following products: •... - Page 9 User Manual | Laboratory Fume Cupboard | Introduction • Operating instructions of the employer • Operating instructions for work materials Text design To facilitate readability and overview in the user manual, some lines of the text and/or text paragraphs are accentuated: •...
- Page 10 User Manual | Laboratory Fume Cupboard | Safety...
-
Page 11: User Manual | Laboratory Fume Cupboard | Safety
User Manual | Laboratory Fume Cupboard | Safety 2 SAFETY Marking of safety instructions List of safety markings used 2.2.1 Warning signs 2.2.2 Mandatory signs Proper use 2.3.1 General information for all fume cupboards 2.3.2 All-purpose fume cupboards Improper use Obligation of operating company Obligation of personnel Liability... -
Page 12: Safety
Safety Marking of safety instructions To avoid danger, you must observe the safety instructions. Wesemann GmbH does not accept any liability for damage caused by non-observance of the safety instructions. You will fi nd the following symbols with all important safety instructions in this user manual. Always follow these instructions exactly and exercise particular caution in these cases. -
Page 13: List Of Safety Markings Used
User Manual | Laboratory Fume Cupboard | Safety List of safety markings used 2.2.1 Warning signs Warning of toxic substances Warning of toxic substances Warning of electrical voltage Warning of electrical voltage 2.2.2 Mandatory signs Hand protection must be worn Proper use 2.3.1 General rules for all laboratory fume cupboards... -
Page 14: All-Purpose Fume Cupboards
(at least 5 cm) (floor clearance) to the worktop, as well as a sufficiently large clearance to the sash (at least 10 cm) must be observed. The fume cupboard may not be used in a potentially explosive atmosphere. Wesemann GmbH offers EX fume cupboards for such areas. -
Page 15: Obligation Of Operating Company
User Manual | Laboratory Fume Cupboard | Safety • if the operating company has performed a risk analysis and has taken the necessary protective measures. • if those carrying out the activities to be performed are competent and reliable. The expertise is determined by the nature and duration of the relevant training, the general professional experience in the respective field, as well as the experience in the activities to be carried out. -
Page 16: Other Provisions
User Manual | Laboratory Fume Cupboard | Safety • Use of spare parts that have not been approved by Wesemann GmbH. Other provisions In addition to this user manual, the relevant national laws, rules and regulations in the applicable version are to be observed (i.e. - Page 17 User Manual | Laboratory Fume Cupboard | Safety...
- Page 18 User Manual | Laboratory Fume Cupboard | Product Description...
-
Page 19: User Manual | Laboratory Fume Cupboard | Product Description
User Manual | Laboratory Fume Cupboard | Product Description 3 PRODUCT DESCRIPTION Overview of the products Technical Data 3.2.1 Dimensions table fume cupboard DS-DG03 3.2.2 Dimensions low ceilings fume cupboard DSN-DG03 3.2.3 Dimensions low work-level fume cupboard DT-DG03 3.2.4 Dimensions walk-in fume cupboard DB-DG03 3.2.5 Weights 3.2.6... -
Page 20: Product Description
User Manual | Laboratory Fume Cupboard | Product Description Product description Overview of the products COMPLETE PRODUCT OVERVIEW Frame Sash Side panel bottom right Worktop Side panel bottom left Front panel Lab fume cupboard top left Electric cable duct Lab fume cupboard top right... - Page 21 User Manual | Laboratory Fume Cupboard | Product Description PRODUCT OVERVIEW FRONT In this view the sash and front panel have been blended out. Electrical box right Pilaster strip below Electrical box left Pilaster strip plug Skirt profile Air baffle Grid strut Air baffle top Pilaster strip adapter right...
- Page 22 User Manual | Laboratory Fume Cupboard | Product Description PRODUCT OVERVIEW ABOVE Laboratory fume cupboard side above left Ceiling back Rope roller bracket Flange Laboratory fume cupboard side above right Sheet metal skirt Pressure equalization valve Fume cupboard lamp Ceiling front...
-
Page 23: Technical Data
User Manual | Laboratory Fume Cupboard | Product Description Technical Data D (910) 3.2.1 Dimensions table fume cupboard DS-DG03 85 20 DS-DG03-1500 Ø 250 H (690) G (710) F (720) A (1500) E (940) B (Interior width 1460) C (Opening width 1440) Grid width 1200 1500... -
Page 24: Dimensions Low Ceilings Fume Cupboard Dsn-Dg03
User Manual | Laboratory Fume Cupboard | Product Description 3.2.2 Dimensions fume cupboard for low ceilings DSN-DG03 D (910) DSN-DG03-1500 85 20 Ø 250 H (680) G (710) F (720) A (1500) E (940) B (Interior width 1460) C (Opening width 1440) Grid width 1200 1500... -
Page 25: Dimensions Low Work-Level Fume Cupboard Dt-Dg03
User Manual | Laboratory Fume Cupboard | Product Description 3.2.3 Dimensions low work-level fume cupboard DT-DG03 D (910) 85 20 DT-DG03-1500 Ø 250 H (650) J (680) G (710) F (720) A (1500) E (940) B (Interior width 1460) C (Opening width 1440) Grid width 1200 1500... -
Page 26: Dimensions Walk-In Fume Cupboard Db-Dg03
User Manual | Laboratory Fume Cupboard | Product Description 3.2.4 Dimensions walk-in fume cupboard DB-DG03 D (910) DB-DG03-1500 Ø 250 H (650) G (710) J (680) A (1500) E (940) B (Interior width 1460) Grid width 1200 1500 1800 2100 Interior width 1160 1460... -
Page 27: Weights
User Manual | Laboratory Fume Cupboard | Product Description 3.2.5 Weights* Grid (mm) 1200 1500 1800 2100 Fume cupboard type DS-DG03 310 kg 340 kg 380 kg 420 kg DSN-DG03 295 kg 340 kg 385 kg 440 kg DT-DG03 345 kg 400 kg 455 kg 510 kg... -
Page 28: Overview Of Function And Control Elements
User Manual | Laboratory Fume Cupboard | Product Description Overview of function and control elements This section provides an overview of the most important functions and control elements of a fume cupboard. SASH The sash is an adjustable protective plate between the operator and the interior of the fume cupboard. In the case of a multi-part sash, two or more panels are so arranged that they can be simultaneously operated in the free opening area of the fume cupboard. - Page 29 User Manual | Laboratory Fume Cupboard | Product Description of hazardous substances and flying (glass) splinters. Therefore, for reasons of personal safety, work should only be carried out through the laterally closeable parts (cross slide). FUME CUPBOARD FUNCTION INDICATOR The fume cupboard function indicator is situated in/on the pilaster strip on the right side of the fume cupboard. It indicates the correct functioning of the air flow to the fume cabinet.
-
Page 30: Extraction Function Displays
User Manual | Laboratory Fume Cupboard | Product Description Fume cupboard function displays 3.4.1 Fume cupboard function display Type 7.1 FUNCTION OLED-Display Display of volumetric flow, as well as operating and status reports LED OK (green) Volumetric flow okay LED LOW (red) Volumetric flow too low LED CLOSE SASH (yellow) Warning: Close sash if opening >... - Page 31 User Manual | Laboratory Fume Cupboard | Product Description 3.4.2 Fume cupboard function display Type 7.2 FUNCTION OLED-Display Display of volumetric flow, as well as operating and status reports LED OK (green) Volumetric flow okay LED LOW (red) Volumetric flow too low LED CLOSE SASH (yellow) Warning: Close sash if opening >...
- Page 32 User Manual | Laboratory Fume Cupboard | Product Description 3.4.3 Fume cupboard function display Type 7.6 FUNCTION OLED-Display Display of volumetric flow, as well as operating and status reports LED OK (green) Volumetric flow okay LED LOW (red) Volumetric flow too low LED CLOSE SASH (yellow) Warning: Close sash if opening >...
- Page 33 User Manual | Laboratory Fume Cupboard | Product Description 3.4.4 Fume cupboard function display Type 4.1 FUNCTION LED OK (green) Volumetric flow okay LED LOW (red) Volumetric flow too low RESET button Reset acoustic alarm LED CLOSE SASH (yellow) Warning: Close sash if opening > 50 cm LIGHT button Fume cupboard interior lighting ON/OFF Sash OPEN / CLOSE...
- Page 34 User Manual | Laboratory Fume Cupboard | Product Description 3.4.5 Fume cupboard function display Type 4.2 FUNCTION LED OK (green) Volumetric flow okay LED LOW (red) Volumetric flow too low RESET button Reset acoustic alarm LED CLOSE SASH (yellow) Warning: Close sash if opening > 50 cm LIGHT button Fume cupboard interior lighting ON/OFF Sash OPEN / CLOSE...
- Page 35 User Manual | Laboratory Fume Cupboard | Product Description 3.4.6 Fume cupboard function display Type 4.3 FUNCTION LED OK (green) Volumetric flow okay LED LOW (red) Volumetric flow too low RESET button Reset acoustic alarm LED CLOSE SASH (yellow) Warning: Close sash if opening > 50 cm LIGHT button Fume cupboard interior lighting ON/OFF LED SERVICE...
- Page 36 User Manual | Laboratory Fume Cupboard | Product Description 3.4.7 Fume cupboard function display Type 4.6 FUNCTION LED OK (green) Volumetric flow okay LED LOW (red) Volumetric flow too low RESET button Reset acoustic alarm LED CLOSE SASH (yellow) Warning: Close sash if opening > 50 cm LIGHT button Fume cupboard interior lighting ON/OFF Button V...
- Page 37 User Manual | Laboratory Fume Cupboard | Product Description 3.4.8 Detailed description of the functions OLED- Display Display of volumetric flow, as well as operating and status reports By means of the graphic OLED Display (64x64 Pixel) in the function display, all important operating and status information on the fume cupboard can be read off directly.
- Page 38 User Manual | Laboratory Fume Cupboard | Product Description Button V with LED Operation (Emergency) The maximum exhaust air volumetric flow can be requested via the V button (emergency extraction). Button V with LED Reduced Operation ON/OFF This V button can be activated or deactivated. The yellow glowing Status LED indicates the night reduction status when the terminals Day/Night X11.39 and X11.40 are activated.
- Page 39 User Manual | Laboratory Fume Cupboard | Product Description...
- Page 40 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard...
-
Page 41: User Manual | Laboratory Fume Cupboard | Commissioning Of Laboratory Fume Cupboard
User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard 4 COMMISSIONING OF LABORATORY FUME CUPBOARD Preconditions for commissioning by the user Prerequisites for safe operation Commissioning of fume cupboard 4.3.1 Check before commissioning 4.3.2 Emergency OFF and operation of electrical components 4.3.3 Uninterruptible Power Supply UPS 4.3.4... -
Page 42: Putting Fume Cupboard Into Operation
• training has been conducted by a person appointed by Wesemann and the above-mentioned protocols handed over. • the laboratory fume cupboard is connected to a sufficiently dimensioned ventilation system. -
Page 43: Commissioning Of Laboratory Fume Cupboard
User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard Commissioning of fume cupboard 4.3.1 Check before commissioning The fume cupboard must be so placed that it can be safely operated with the nominal air volume. Alternatively, a minimum infl ow of 0.25m/s is to be guaranteed. WARNING Danger of hazardous substances outbreak by improper use of the fume cupboard. - Page 44 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard EMERGENCY OFF KEY-OPERATED BUTTON without key with key The emergency OFF button is to be pressed in the case of an emergency or to avert a danger. By pressing the button, all experimental sockets are disconnected from the power supply.
-
Page 45: Uninterruptible Power Supply Ups
User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard 4.3.3 Uninterruptible power supply UPS The colour coding of the UPS power sockets is customer-specific. The configuration of the sockets is in the colours red, green or orange, according to customer requirements. In some cases, the socket is marked with the letters UPS. - Page 46 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard WARNING Danger due to toxic substances Toxic substances can lead to serious injury if the following instructions for safe working with the sash are not observed. • The sash is to be kept closed at all times. Exceptions are short-term interventions, i.e. for monitoring, installation and dismantling, as well as feeding/loading of an apparatus, whereby the opening of the sash must be limited to what is necessary for the activities.
- Page 47 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard It is possible to unlock the limitation of the sash to enable, for example, the positioning of high experimental set-ups in the fume cupboard. By turning the sash handle bar and by means of the twist-unlock mechanism, the limiter is unlocked and the sash can be moved further upwards over the work opening.
- Page 48 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard the user is not protected against the spraying out of hazardous substances and flying (glass) splinters. Due to the low working height, an opening limiter is not prescribed in the case of low and walk-in fume cupboards.
- Page 49 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard During the downwards movement of the sash, the light barrier on the sash handle bar monitors the area directly below the sash. If it detects an obstacle, for instance a protruding object or hose, or if the user intervenes in the area, the sash stops automatically.
- Page 50 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard Inching mode DOWN If the sash is moved manually or in inching mode in the direction DOWN, the internal electronics recognize the direction und close the sash. If a 3rd break point was set during the commissioning of the fume cupboard, this is not actuated by the downwards movement of the sash.
- Page 51 User Manual | Laboratory Fume Cupboard | Commissioning of laboratory fume cupboard...
- Page 52 User Manual | Laboratory Fume Cupboard | Media system: Armatures...
-
Page 53: User Manual | Laboratory Fume Cupboard | Media System: Armatures
User Manual | Laboratory Fume Cupboard | Media system: Armatures 5 MEDIA SYSTEM: ARMATURES Marking of Armatures Colour-coding Zone 1and abbreviation 5.2.1 Water 5.2.2 Combustible gaseous hydrocarbons 5.2.3 Other combustible gases, gas mixtures 5.2.4 Incombustible gases / including combustive gases 5.2.5 Toxic Gases 5.2.6... -
Page 54: Medium System: Armatures
Zone 1 Zone 2 Zone 3 The 3 zones are colour-coded. Zone 2 includes the short designation / long text for the flow substance and is a Wesemann standard. Colour-coding Zone 1 and abbreviations 5.2.1 Water The colour green of Zone 1 indicates that it refers to the flow substance water. Which water it is can be can be recognized by the colours in Zones 2 and 3. -
Page 55: Combustible Gaseous Hydrocarbons
User Manual | Laboratory Fume Cupboard | Media system: Armatures 5.2.2 Combustible gaseous hydrocarbons The colour yellow of Zone 1 indicates that it refers to the flow substance combustible gaseous hydrocarbons. Which combustible gaseous hydrocarbon it is can be recognized by the colours in Zones 2 and 3. Natural gas Propane / Butane (LPG) Methane... -
Page 56: Toxic Gases
User Manual | Laboratory Fume Cupboard | Media system: Armatures the colours in Zones 2 and 3. Nitrogen Nitrous oxide Synthetic air 80 / 20 Compressed air Oxygen Carbon dioxide Control air Breath (air) Carbogen (CO2 + O2) Krypton Xenon Neon Argon Helium... -
Page 57: Other Substance
Operation of armatures The operation of the armatures is described in separate operating instructions of the respective manufacturer of the armatures. These instructions are provided together with the audit documents of Wesemann GmbH. The following applies to the armatures in general:... -
Page 58: Operation Of Central Isolation Equipment
The position of the shut-off device is determined during the planning of the laboratories. The planning drawings and the operating instructions for the isolation devices are provided together with the audit documents of Wesemann GmbH. Please read these very carefully. - Page 59 User Manual | Laboratory Fume Cupboard | Media system: Armatures...
- Page 60 User Manual | Laboratory Fume Cupboard | Chemical resistance...
- Page 61 User Manual | Laboratory Fume Cupboard | Chemical resistance 6 CHEMICAL RESISTANCE Chemical resistance of surface materials...
-
Page 62: Chemical Resistance
User Manual | Laboratory Fume Cupboard | Chemical resistance Chemical resistance Chemical resistance of surface materials Decorative Melamine-coated Molecular Name PP material formula laminate HPL Chipboard (DBS) Formic acid 99% Formic acid in a concentration of No information No significant impairment over 10%: No resistance (24 hours) Benzene... - Page 63 User Manual | Laboratory Fume Cupboard | Chemical resistance Compact board (coloured high-pres- TRESPA ® Fine stoneware Stoneware Epoxy resin grouting TOPLAB PLUS ® sure-compressed laminate board HPL) Formic acid 90%: No information Formic acid Formic acid Formic acid 5%: resistant; no perceptible staining, 99%: no staining 98-100%:...
- Page 64 User Manual | Laboratory Fume Cupboard | Chemical resistance Decorative Melamine-coated Molecular Name PP-material formula laminate HPL chipboard (DBS) Acetic anhydride No information No information No significant impairment (24 hours) Amyl acetate Isoamyl acetate: No information No significant impairment Resistant max. 16 hours (24 hours) Hydrofluoric acid 48% Hydrofluoric acid in concentration...
- Page 65 User Manual | Laboratory Fume Cupboard | Chemical resistance Compact board (coloured high- TRESPA ® Fine stoneware Stoneware Epoxy resin grouting TOPLAB PLUS ® pressure-compressed laminate board HPL) No perceptible staining, no No information Acetic anhydride: No information No information loss of gloss / no change to No staining the worktop surface...
- Page 66 User Manual | Laboratory Fume Cupboard | Chemical resistance Decorative laminate Melamine-coated Molecular Name PP-material formula chipboard (DBS) Natrium Chloride NaCl Cooking salt: No information Natrium Chloride 10%: Resistant max. 16 hours No significant impairment (24 hours) Phenol Resistant max. 16 hours No information No significant impairment (24 hours)
- Page 67 User Manual | Laboratory Fume Cupboard | Chemical resistance Compact board (coloured high- TRESPA ® Fine stoneware Stoneware Epoxy resin grouting TOPLAB PLUS ® pressure-compressed laminate board HPL) Natrium Chloride 10%: Table salt: no damage Natrium Chloride Resistant, Natrium Chloride solution, no perceptible staining, after max.
- Page 68 User Manual | Laboratory Fume Cupboard | Chemical resistance Decorative Melamine-coated Molecular Name PP-material formula laminate HPL chipboard (DBS) Toluol Resistant max. 16 hours No information No significant impairment (24 hours) Hydrogen Peroxide Hydrogen Peroxide 3%: Hydrogen Peroxide 3%: Hydrogen Peroxide Resistant max.16 hours, Hydro- Resistant max.
- Page 69 User Manual | Laboratory Fume Cupboard | Chemical resistance Compact board (coloured high- TRESPA ® Fine stoneware Stoneware Epoxy resin grouting TOPLAB PLUS ® pressure-compressed laminate board HPL) Toluene: No damage after No staining Resistant, Limited resistance; resistant to No discernable staining, max.
- Page 70 User Manual | Laboratory Fume Cupboard | Chemical resistance Pfleiderer Holzwerkstoffe GmbH: PRODUCT INFORMATION, Chemical resistance of Duropal laminates, Sep.2014, with respect to EN 438 Pfleiderer Holzwerkstoffe GmbH: Wood materials, raw and Melamine-coated. Technical data, in combination with: EN14323:2004(D) Appendix A: Staining substances Table A.1 – Test substances E-mails of 8.6.2015 and 20.4.2016: Chemical resistance of PP materials, Simona AG TRESPA TOPLABPlus - CHEMICAL RESISTANCE Identification number: G4650 - Date 18.8.2011, CONDITION 0 (Surface was rinsed with water after the test)
- Page 71 User Manual | Laboratory Fume Cupboard | Chemical resistance...
- Page 72 User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards...
-
Page 73: User Manual | Laboratory Fume Cupboard | Cleaning Of Laboratory Fume Cupboards
User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards 7 CLEANING OF LABORATORY FUME CUPBOARDS Dismantling of the air baffle for cleaning purposes Cleaning according to surface material 7.2.1 Decorative laminate HPL 7.2.2 Melamine-coated chipboard (DBS) 7.2.3 Trespa TOPLAB ®... -
Page 74: Cleaning Of Fume Cupboards
User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards Cleaning of Laboratory Fume Cupboards Cleanliness, order and hygiene are of the utmost importance in order to be able to work safely with a laboratory fume cupboard. Depending on the level of contamination of the fume cupboard, the air baffl e must be dismantled for cleaning purposes. - Page 75 User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards 1. Dismantle top air baffl e: Unlock rotary knob by rotating, at the same time supporting the air baffl e. Carefully remove top air baffl e Pos. 47. 2.
- Page 76 User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards 3. Cleaning the air baffl e and contaminated areas 4. Assembly of air baffl e: Spacer Position rod holder Pos. 50 in air baffl e Pos. 46. Position rod holder Pos. 50 in air baffl e Pos. 46. Mount the spacers on the back of the air baffl e by sliding onto the rod holder.
-
Page 77: Cleaning According To Surface Material
When using substances such as white spirit as a cleaner, adequate ventilation is to be ensured. The instructions in the laboratory operating instructions must be strictly observed. Wesemann GmbH generally recommends that, when cleaning, the cleaning agent and the cleaning cloth are fi rst tested in an inconspicuous place. -
Page 78: Melamine-Coated Chipboard (Dbs)
User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards If the contaminants are not removed immediately, standard domestic cleaners can be used, such as washing powder, liquid or hard soap, which do not contain any abrasive components. If there is a more intense contamination, it is advisable to leave the cleaner to soak in. -
Page 79: Polypropylene (Pp)
User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards 7.2.5 Polypropylene (PP) When cleaning the surface of the compact board, a soap solution or suitable organic solvent can be used. When cleaning with organic solvents which are capable of forming an explosive mixture when in contact with air, the Polypropylene can become charged and sparking can occur when discharging. -
Page 80: Glass
User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards not be higher than 25°C. Apply a cleaning solution of water and a small amount of neutral detergent to the contaminated area with a non-abrasive cloth. Hard rubbing damages the surface. Allow to act briefl y and then remove with a damp cloth and water. - Page 81 User Manual | Laboratory Fume Cupboard | Cleaning of Laboratory Fume Cupboards...
- Page 82 User Manual | Laboratory Fume Cupboard | Inspection and Maintenance of Laboratory Fume Cupboards...
-
Page 83: User Manual | Laboratory Fume Cupboard | Inspection And Maintenance Of Laboratory Fume Cupboards
User Manual | Laboratory Fume Cupboard | Inspection and Maintenance of Laboratory Fume Cupboards 8 INSPECTION AND MAINTENANCE OF LABORATORY FUME CUPBOARDS Maintenance contract Test plan 8.2.1 Testing by user in the course of the year 8.2.2 Annual inspection of fume cupboard 8.2.3 Checks of media systems at least every 4 years 8.2.4... -
Page 84: Inspection And Maintenance Of Fume Cupboards
Maintenance contract For safety inspections, maintenance and the execution of servicing work, we recommend the company Infralab GmbH in Syke. This is an efficient and reliable cooperation and service partner of the Wesemann Group. Infralab GmbH Max-Planck-Straße 12... -
Page 85: Annual Inspection Of Fume Cupboard
User Manual | Laboratory Fume Cupboard | Inspection and Maintenance of Laboratory Fume Cupboards Installation / Equipment Inspection interval Type of test Tester Residual current, Differential current and 6 months for proper function by operation User fault voltage circuit breaker - in stationary of the test equipment installations 8.2.2... -
Page 86: Checks Of Media Systems At Least Every 4 Years
User Manual | Laboratory Fume Cupboard | Inspection and Maintenance of Laboratory Fume Cupboards • Test the sub-structure extraction function • Check the sash poti-rope/cable • Test the automatic sash closing function • Test the function of the 500mm opening-limiter signal •... - Page 87 User Manual | Laboratory Fume Cupboard | Inspection and Maintenance of Laboratory Fume Cupboards...
- Page 88 User Manual | Laboratory Fume Cupboard | Spare Parts and Prototype Test Report...
- Page 89 User Manual | Laboratory Fume Cupboard | Spare Parts and Prototype Test Report 9 SPARE PARTS AND PROTOTYPE TEST REPORT Spare Parts Prototype test report...
-
Page 90: Spare-Parts List And Prototype Test Report
Spare Parts and Prototype Test Report Spare Parts Only spare parts authorized by Wesemann GmbH may be used. Any use of unauthorized spare parts invalidates the agreed warranty claim. Spare parts can be ordered from the address on the back of this user manual or contact our sales representative. - Page 91 User Manual | Laboratory Fume Cupboard | Legal Notice Legal Notice Copyright All rights to these instructions are reserved by Wesemann GmbH. The documents are entrusted to the recipient for personal use only. Disclosure, reprinting (electronic or mechanical), translation into other languages or any other reproduction, even of parts of the instructions, are permitted only with written consent.
- Page 92 Wesemann GmbH – Headquarters Max-Planck-Straße 15–25 28857 Syke Germany Phone: +49 42 42 594-0 Fax: +49 42 42 594-333 Email: info@wesemann.com Changes to colours, dimensions and technical design to improve performance are reserved. No reproduction or reprint without our permission.
