Display Port; Com2 Rs-232/422/485; Cn16, Option) - Beijer Electronics C2 base Manual

7.1.7
Table: Pinout Display Port Connector
7.1.8
Table: Pinout RS-232/422/485 Connector
Beijer, MAEN278
Pin
17
18
19

Display Port

Pin Signal Name
1 TX0+
2 GND
3 TX0-
4 TX1+
5 GND
6 TX1-
7 TX2+
8 GND
9 TX2-
10 TX3+
COM2 RS-232/422/485 (via internal
cable connection to CN16, Option)
Pin RS-232
1 DCD
2 RxD
3 TxD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 RI
Signal Name
GND
+5 V Power
Hot Plug Detect
Pin Signal
11 GND
12 TX3-
13 GND
14 GND
15 AUX+
16 GND
17 AUX-
18 HPD
19 GND
20 PWR
Half Full
Duplex Duplex
RS-422 RS-485 RS-485
Tx- Data- Tx-
Tx+ Data+ Tx-
Rx+ - Rx+
Rx- - Rx-
GND GND GND
- -
-
- -
- -
Connectors
-
-
-
-
22
