7.1.2
Figure: Power switch and LEDs.
1. LED power
2. Power on
3. LED drive activity
Table: Power LED
LED
Off
Green
Green blinking
Table: Drive Activity
LED
Off
Green
7.1.3
Table: Pinout USB 3.0
7.1.4
Table: Pinout GbE RJ-45 Connector
Beijer, MAEN278

Power-Switch and LEDs

USB3.0 Type-A Connector

Pin Signal Name
1 +USB_VCC
2 USB_D-
3 USB_D+
4 GND

GbE RJ-45 Connector

Signal
No Power
Active
Standby
Signal
No Power
Active
Pin Signal Name
5 USB_RX-
6 USB_RX+
7 GND
8 USB_TX-
9 USB_TX+
Connectors
