Led Diagram Of Lan Connectors; Hdmi Connector - Beijer Electronics C2 base Manual

7.1.5
Table: Status of LEDs from GbE RJ-45 Connector
7.1.6
Table: Pinout HDMI Connector
Beijer, MAEN278
Pin
1
2
3
4

LED Diagram of LAN Connectors

Left LED:
activ-
ity/link
Off
Yellow
Yellow
blinking

HDMI Connector

Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Signal
Name Pin
TX1+ 5
TX1- 6
TX2+ 7
TX3+ 8
Right LED:
activ-
ity/link
No LAN con- Off
nectivity
Link Green
Activity Orange
Signal Name
TMDS Data2+
GND
TMDS Data2-
TMDS Data1+
GND
TMDS Data1-
TMDS Data0+
GND
TMDS Data0-
TMDS Clock+
GND
TMDS Clock-
Reserved
Reserved
DDC_CLK
DDC_DATA
Connectors
Signal
Name
TX3-
TX2-
TX4+
TX4-
10 Mbit
100
Mbit
1 GbE
21
