4 Technical Data and
Environmental Specification
Table: Technical Data C2 base/C2 pro/C2 marine Line
Product
Front options
Touch surface
Mounting
Processor
Ram
Application Memory*
Standard interfaces
Wireless interfacess**
Power supply
Power consumption
InputFuse
EMC
Certifications
Altitude
Shock, according to EN
60068-2-27
Vibration, according to EN
60068-2-6
Operating temperature
Storage Temperature
Protection class
Humidity
MTBF
Verified OS
Beijer, MAEN278
Technical Data and Environmental Specification
C2 Base
Projected Capacitive
Touch screen
Glass
Intel® 7th generation
Dual Core™ Celeron®
3965U (2x 2.2GHz)
Main Memory 4GB
DDR4
Application
memory 256GB 2.5"
industrial-grade SSD
2x GbE, 1x HDMI, 1x DP,
4x USB3.0 900mA
RFID, WiFi
+24VDC (18 - 30VDC)
See table below
Internal DC fuse, 5A
slow
EN55032 class B
CE, FCC, UL, cUL
Up to 10.000 ft (3.000
m)
15 G 11 ms duration
(half sine)
1g 10-500Hz 3 axis
0 °C to +50 °C
-20°C - +70°C
IP65 front, IP20 rear
10% - 90 % non
condensing
> 50.000 h
Windows® 10 IoT
Enterprise
C2 Pro
Projected Capacitive
Touch screen
Glass
Intel® 7th generation
Dual Core™ i5-7300U
(2x 2.6-3.5GHz
4Threads)
Main Memory 4GB DDR4
Application
memory 256GB 2.5"
industrial-grade SSD
2x GbE, 1x HDMI, 1x DP,
4x USB3.0 900mA
RFID, WiFi
+24VDC (18 - 30VDC)
See table below
Internal DC fuse, 5A
slow
EN61000-6-2 class B
CE, FCC, UL, cUL
Up to 10.000 ft (3.000
m)
15 G 11 ms duration
(half sine)
1g 10-500Hz 3 axis
0 °C to +50 °C
-20°C - +70°C
IP65 front, IP20 rear
10% - 90 % non
condensing
> 50.000 h
Windows® 10 IoT
Enterprise
