INSTALLATION AND OPERATION INSTRUCTIONS
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO
NOTE: This product is designed for use with an attended hearth appliance or fire feature. Adults must be present when
the Control System is operating. DO NOT program or thermostatically set this Control to operate a hearth appliance or fire
feature when Adults are not physically present. Furthermore, DO NOT leave the hearth appliance or fire feature burning
unattended; it may cause damage or serious injury. If an Adult is going to be away from the hearth appliance or fire
feature for any length of time, then the handheld/wall mount, receiver/control module and application should be in the
"OFF" position.
INTRODUCTION
his remote control system was developed to provide a safe, reliable, and user-friendly remote control system for gas
T
heating appliances. The system can be operated thermostatically, manually or with the built-in factory program inside the
transmitter. The built-in program has two segments, a weekdays and a weekend segment. The factory presets are time
periods for each day. SEE PROGRAM SEQUENCE BELOW. Custom programming may be achieved after the initial
setup has been performed.
This system operates on radio frequencies (RF) within a 20-foot range using non-directional signals. The system
operates one of 1,048,576 security codes that are programmed into the transmitter at the factory; the remote receiver's
code must be matched to that of the transmitter prior to initial use.
Weekdays - Mon. Tues. Wed.Thurs. Fri.
Program 1 (P1)
Weekends - Sat. Sun.
Program 1 (P1)
Table 1 Factory program.
Skytech: 5320P
Model: 5320P
NOT ATTEMPT TO INSTALL OR OPERATE
Built-in Factory Programs
MORN
5:00AM
9:00AM
72°
MORN
6:00AM
10:00AM
72°
Program 2 (P2) 4:00PM
Program 2 (P2) 5:00PM
DAY
10:00PM
72°
DAY
10:00PM
72°
REV. 8-11-20
Page 1
