Date: 2007-11-14
Author: Javy Huang

LCD Diagram

LCD Indicator:

1.
ON / THERMO / OFF: Indicates operation MODE of system.
ON indicates the system is on, either manually or thermostatically.
OFF indicates the entire system is turned off.
THERMO indicates the system will automatically cycle on/off,
5301 Operation description

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5301 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Skytech 5301

Summary of Contents for Skytech 5301

  • Page 1 5301 Operation description Date: 2007-11-14 Author: Javy Huang LCD Diagram LCD Indicator: ON / THERMO / OFF: Indicates operation MODE of system. ON indicates the system is on, either manually or thermostatically. OFF indicates the entire system is turned off.
  • Page 2 depending on programmed. System ON flame: Indicates whether system ON or not. Clock: Indicates the current time in AM/PM. Low Battery: Battery power is low. Replace batteries within two weeks. Reserve Flame Icon : Reserved for providing multiple flame modulation levels by providing a variable current output to specific modulation device.
  • Page 3 press and hold and “UP” buttons for 5 seconds, “ ” will briefly appear/disappear on screen. Swing Setting: Press the and “DOWN” buttons simultaneously to enter Swing Setting mode. Operation Description: Mode: ON OPERATION: Press the “MODE” key into the ON mode. The appliance flame will come on.
  • Page 4 current “SWING” setting in the SET TEMP frame. The letter “S” will display in the ROOM TEMP frame on the LCD screen. Press the UP or DOWN button to change the temperature differential or “SWING” (1-3). See above for 1-3 “SWING” temperature valves. To store the “swing number press the SET button or allow 15 seconds to lapse, and the new “swing number”...
  • Page 5 10. The Fan icon ( ) is reserved for specific modulation device. Further Description Radio Frequency range: 303.8MHZ The remote receiver is SR 1001. The remote controller effective distance is above 40 feet. FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
