Skytech 5001 Installation Instructions Manual

IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
INTRODUCTION
This SKYTECH remote control system was developed to provide a safe, reliable, and user-friendly remote control system
for gas heating appliances. The system can be operated manually from the transmitter. The system operates on radio
frequencies (RF) within a 20-foot range using non-directional signals. The system operates one of 1,048,576 security
codes that are programmed into the transmitter at the factory; the remote receiver's code must be matched to that of the
transmitter prior to initial use.
ON
OFF
FRONT
LCD DESCRIPTION
1
8
ON
OFF
4
Skytech Model: 5001
MODEL: 5001
DO NOT ATTEMPT TO INSTALL OR OPERATE
BATTERY
COMPARTMENT
BACK
5
6
2
7
1. BATTERY ICON - Indicates low battery. Replace batteries within 2- weeks.
2. ON- Indicates the appliance is ON – Flame Icon
3
3. OFF- Indicates the appliance is OFF – NO Flame Icon
4. FLAME ICON – Indicates burner/valve in operation.
5. ROOM – Indicates CURRENT room temperature.
6. °F -Indicates degrees Fahrenheit (ºC indicates degrees Celsius).
7. LOCK – Child lock out.
8. RF SIGNAL ICON –Appears when the RF signal is being transmitted.
The transmitter operates on (4) AAA-size 1.5V batteries. It
is recommended that ALKALINE batteries always be used
for longer battery life and maximum operational
performance. IMPORTANT: New or fully charged
batteries are essential for proper operation of the
multi-function transmitter. Insert (4) AAA-size 1.5 V
batteries into the battery compartment on the back of the
transmitter, positioning the (+) and (-) ends of the batteries
as indicated on the casing. When the batteries are i
nserted, the screen at right (with similar numbers) will
display.
Note: On initial start up if a LOW
battery icon appears on the screen,
check the position of the batteries.
Note: Due to the sensitive
temperature-monitoring components
in the transmitter, it may be
necessary to allow the transmitter to
stabilize to room temperature
before accurate room temperatures
are displayed on the screen. If the
transmitter is activated from a
severe cold condition, it can take up
to fifteen minutes for accurate
temperature readings to appear.
ON
OFF
REV. 11-10-16 Page 1 of 6
