Microchip Technology Microsemi Silicon Sculptor 4 Quick Start Card

Silicon Sculptor 4

Quickstart Card

Kit Contents

Quantity

Description

Silicon Sculptor 4 Concurrent Programmer

Power Supply

Power Cord

USB 2.0 A to B Cable

Quickstart Card

Congratulations on your purchase of a Microsemi device programmer. Your new device programmer is

designed to provide years of support for thousands of devices, with the use of optional socket cards.

Before you get started, take the time to carefully read the following instructions that guide you towards a

successful programming operation.

This Quickstart Card applies to the Microsemi Silicon Sculptor 4. Silicon Sculptor 4 is an FPGA

programming tool equipped to deliver high data throughput and promote ease of use. It incorporates

the industry's widely accepted high-speed USB 2.0 standards bus communication, allowing as many as

twelve Silicon Sculptor 4 systems to be connected to a single PC through a series of nested high-speed

USB 2.0 hubs. It is a highly reliable programmer for Microsemi's portfolio of FPGAs.

Table of Contents

Do you have a question about the Microsemi Silicon Sculptor 4 and is the answer not in the manual?

Page 1 Before you get started, take the time to carefully read the following instructions that guide you towards a successful programming operation. This Quickstart Card applies to the Microsemi Silicon Sculptor 4. Silicon Sculptor 4 is an FPGA programming tool equipped to deliver high data throughput and promote ease of use. It incorporates the industry’s widely accepted high-speed USB 2.0 standards bus communication, allowing as many as...
Page 2 Silicon Sculptor 4 Quickstart Card Procedure Verification of Calibration Prior to operating the device, please ensure the device is in a working condition. Visit the following website to verify your Silicon Sculptor 4 is calibrated and ready to use: https:// goo.gl/8HGpLM.
Page 3 Silicon Sculptor 4 Quickstart Card Verify that all USB drivers are loaded correctly, recognized by Windows and attached. The programmer sites will be listed in Windows Device Manager. You can open the Device Manager in Windows by accessing Windows Control Panel or with the Windows+Break keyboard combination.
