- Page 1 Roadster Mobile battery-powered speaker User manual The information in this user manual is subject to change at any time without notice. Version: 1.0 Date of creation and author's initials:: 6-01-2017 RV Revision date and author's initials: -...
- Page 2 Please be sure to check that all of the parts and accessories listed below under 'box contents' are included in the package. In the event that the Roadster does not function properly, or if you have any issues while operating it, please remove the plug from the power socket and contact your dealer for assistance.
-
Page 3: Safety Instructions
Safety instructions WARNING! Keep this device away from moisture, water and rain to avoid the chance of electric shocks. Everyone involved with the installation, operation and maintenance of this device must: - Be qualified - Be skilled - Have read the instructions in this user manual - Be sure that neither the device nor the included accessories are damaged. - Page 4 - Should the device not be used in the manner described in this user manual, damages or even injuries could occur. Devine cannot be held responsible for any injuries or damages that occur as a result of improper use of this product.
- Page 5 An experienced technician is qualified to replace the battery. Devine strongly recommends that users do not attempt to replace the battery themselves. Replacing the battery is done at your own risk.
- Page 6 Guidelines and operation of this device 1. USB charging socket 2. TRS jack line output 3. TS jack instrument input 4. TS jack microphone input 5. stereo RCA line (aux) input 6. IEC C13 power input for mains cable with fuse holder 7.
-
Page 7: Operating The Device
General use The Devine Roadster is equipped with a tablet holder slot, located on the top of the device. A wide range of tablets, smartphones, and other media players, with or without a protective cover, can be placed in this slot during use. -
Page 8: Audio Technology
RCA connector or a mini jack plug. When linking devices, it’s also possible to connect the jack output of the first Roadster to the aux input of a second Roadster. This will ensure that both speakers reproduce the same audio. - Page 9 The Devine Roadster comes complete with a microphone cable and microphone with an on/off switch. If the microphone is not actively being used but it is connected to the Roadster, switch it ‘off’ so it won’t pick up any unwanted sounds.
- Page 10 The Devine Roadster has a built-in battery, but can also function when plugged into the power mains. The advantage of this is that as you use the Roadster, the battery is charging at the same time so you can use it wirelessly another time.
- Page 11 Battery-powered speaker troubleshooting If you have a problem with your Roadster battery-powered speaker, please consult the troubleshooting section for possible solutions. If, after consulting this section, the problem remains unresolved, please contact your dealer for more information and/or help. This troubleshooting section contains information on how to solve the most common battery-powered speaker problems, but it does not and cannot cover every eventuality.
- Page 12 Cable not connected properly Make sure the cable is connected microphone properly to both the microphone and the mic input on the Roadster. Switch is 'off' Turn the microphone switch ‘on’. No sound on one of the inputs Volume control is not turned up...
-
Page 13: Specifications
Specifications - mobile battery-powered speaker - built-in 12V DC, 5 Ah battery - speaker components: 8-inch woofer, soft dome tweeter - component impedance: 4 ohms - amp capacity: 30W RMS, 60W peak - charging time: 5 h - battery life at high volume: +/- 5 h - battery life at 50% volume: +/- 9 h - battery life at 25% volume: +/- 13 h - built-in 5V DC, 1A USB port for charging multi-media devices (will impact battery performance)
