Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
Instruction No
Instruction No
Version
Version
31260816
31260816
1.1
1.1
© Volvo Car Corporation
Part. No.
Part. No.
31260792
31260792
Tracker system based on Volvo on Call
Tracker system based on Volvo on Call
Tracker system based on Volvo on Call- 31260816 - V1.1
Page 1 / 20
Advertisement
Related Manuals for Volvo 31260792
Summary of Contents for Volvo 31260792
- Page 1 Part. No. Part. No. 31260816 31260816 31260792 31260792 Tracker system based on Volvo on Call Tracker system based on Volvo on Call © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 1 / 20...
- Page 2 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Equipment IMG-242205 A0000162 IMG-239664 IMG-334911 IMG-315383 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 2 / 20...
- Page 3 Turn the ignition switch to position 0. Disconnect the battery negative lead. Note! Wait at least three minutes before unplugging the connectors or removing other electrical equipment. IMG-246024 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 3 / 20...
- Page 4 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-239420 Remove the bolts of the panel underneath the glovebox and remove it. IMG-222268 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 4 / 20...
- Page 5 Volvo Car Corporation Gothenburg, Sweden Disconnect the lighting connector and place the panel to one side. IMG-222270 Remove the two screws. IMG-225205 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 5 / 20...
- Page 6 Pull out the glove box slightly. Disconnect the connector at the rear edge. Remove the connectors on top and disconnect them. Remove the glovebox. IMG-225201 IMG-279924 IMG-279925 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 6 / 20...
- Page 7 Remove the three screws in the control module and withdraw it from the holder. The screws will be reused. IMG-315405 Disconnect the connectors from the control module and remove IMG-315406 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 7 / 20...
- Page 8 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the spring nuts. They will not be used again. IMG-315408 IMG-315409 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 8 / 20...
- Page 9 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-315643 IMG-315644 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 9 / 20...
- Page 10 Remove the GPS cable from the kit and insert it down through the hole in the dashboard at the right hand A-post. Pull it out as illustrated in image B. IMG-315646 IMG-315407 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 10 / 20...
- Page 11 Place the GPS antenna on the insulation mat at the A-post as illustrated. Pierce holes in the insulation mat on both sides of the antenna. Move the GPS antenna. IMG-315648 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 11 / 20...
- Page 12 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Thread a tie strap through the holes. IMG-315649 Tighten the antenna against the insulation mat. IMG-315651 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 12 / 20...
- Page 13 A post so that the insulation mat tab is held in place. IMG-315650 Clamp the GPS cable to the existing cable harness. IMG-315652 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 13 / 20...
- Page 14 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-315653 IMG-315663 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 14 / 20...
- Page 15 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-315664 Install the control module in the bracket. IMG-315665 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 15 / 20...
- Page 16 Position the control module where the glove box was located. Connect the cable (1) from the GPS. Connect other cables that were disconnected from the control module. IMG-315683 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 16 / 20...
- Page 17 Take the glove box and connect the connectors on the reverse. Reinstall the glove box and tighten the M6 bolts to 10 Nm (7.5 lbf.ft). IMG-225269 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 17 / 20...
- Page 18 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Install the screws in the lower edge. IMG-280026 IMG-286608 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 18 / 20...
- Page 19 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-225272 IMG-280033 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 19 / 20...
- Page 20 Turn the ignition key to position II. Reconnect the battery negative lead IMG-242267 Download the software for the accessory's function following the service information in VIDA. IMG-242268 © Volvo Car Corporation Tracker system based on Volvo on Call- 31260816 - V1.1 Page 20 / 20...
