Volvo 31285564 Installation Instructions Manual

Volvo 31285564 Installation Instructions Manual

Mobility connection package
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
Instruction No
Instruction No
Version
Version
31285543
31285543
1.1
1.1
© Volvo Car Corporation
Part. No.
Part. No.
31285564
31285564
Mobility Connection Package
Mobility Connection Package
Mobility Connection Package- 31285543 - V1.1
Page 1 / 84

Advertisement

loading
Need help?

Need help?

Do you have a question about the 31285564 and is the answer not in the manual?

Questions and answers

Related Manuals for Volvo 31285564

Summary of Contents for Volvo 31285564

  • Page 1 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Instruction No Instruction No Version Version Part. No. Part. No. 31285543 31285543 31285564 31285564 Mobility Connection Package Mobility Connection Package © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 1 / 84...
  • Page 2 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Equipment IMG-242205 A0000162 IMG-282403 IMG-240673 IMG-240675 IMG-239660 IMG-317443 IMG-317444 IMG-264163 IMG-239446 M0000232 IMG-317463 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 2 / 84...
  • Page 3 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-317464 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 3 / 84...
  • Page 4 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-317465 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 4 / 84...
  • Page 5 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-319004 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 5 / 84...
  • Page 6 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-213320 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 6 / 84...
  • Page 7 Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Note! These installation instructions show installation on a left hand drive car. For installation on a right hand drive car, perform the steps on the opposite side and/or mirrored.
  • Page 8 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! Take care when handling the components, they are fragile and are easily damaged. Take the three screws M5x25 part no. 986957 and nuts from the kit. To prevent excessive resistance when the nut for the holder is tightened, hold the screw and screw the nut on and off the threaded part of the screw.
  • Page 9 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the kit with the four spacers from the installation kit. Applies to left and right hand drive cars without centre loudspeaker grille Carefully pry off the spacer using P/N 31212788. The part number (1) is on the bottom of the spacer.
  • Page 10 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Apply pieces of butyl tape to the screws so that the screw heads do not protrude outside the spacer when installing it. IMG-282408 Install the spacer in the bottom of the holder.
  • Page 11 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Ensure that the holder's two screw turrets align between the small pins in the oblong holes in the spacer. A click should be heard when the spacer is securely in position. IMG-282409 Place the connector in the bottom of the hole.
  • Page 12 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the small torx screws and carefully tighten the connector to the holder. Ensure that the connector's circuit board is properly against the screw turret and that there is no play. Remove the butyl tape from the screws.
  • Page 13 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Sections 11-15 apply to cars without centre loudspeaker grilles Take the template from the kit and cut along the outer lines LHD/RHD IMG-279845 Note! It is important to carefully measure for the location of the template.
  • Page 14 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Mark out the middle of the piece of tape in two places as illustrated, and draw a line between these marks. IMG-279848 Measure a distance of 82 mm (3¼") from the joint between the dashboard and grille and rearwards on the dashboard.
  • Page 15 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the template and position the arrow point by the marking for 82 mm (3¼"). Position the template so that the central line follows the line on the piece of tape. Tape the template to the dashboard.
  • Page 16 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-237462 Prize away the holder for the switch at the lower edge. Then prize at the upper edge while coaxing and pulling it out. IMG-237463 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 17 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Unplug the connector. IMG-237478 Remove the screw. IMG-237479 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 17 / 84...
  • Page 18 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Illustrations A and B Locate the holes. Pull the panel with air vents straight out. Use special tool 9512943. IMG-237481 IMG-296551 Remove the bolts of the panel underneath the glovebox and remove it.
  • Page 19 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the two screws. IMG-225205 Remove the six screws. Pull out the glove box in one piece. IMG-225201 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 19 / 84...
  • Page 20 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Disconnect the connector at the rear edge. IMG-279924 Remove the connectors on top and disconnect them. Remove the glovebox. IMG-279925 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 20 / 84...
  • Page 21 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Cover the ventilation openings with a paper towel to prevent drill swarf from entering. Place a paper towel in the dashboard underneath where the holes are to be drilled. IMG-279963 Sections 29-36 apply to cars without centre loudspeaker grille Mark the holes in the centre using a scriber.
  • Page 22 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Illustration A Select a Ø14 mm (9/16") hole saw. Swap the central drill bit in the hole saw for a Ø5 mm (13/64") drill bit. The hole in the holder is larger than the diameter of the drill bit.
  • Page 23 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Use a small screwdriver and clear the three small holes from any chips so that the underlying plastic layer appears. Remove the paper from the air ducts and the paper from under the dashboard.
  • Page 24 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take out the three nuts and tighten the cradle on the dashboard. Access for installing and tightening nuts is via the space for the glove box. IMG-279056 Take out the short connection cable from the kit and secure the connector to the bottom of the cradle.
  • Page 25 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Sections 36-52 apply to cars with centre loudspeaker grille Remove the loudspeaker grille as follows: Insert special tool, 9995919 in the joint between the loudspeaker grille and the dashboard approximately as illustrated, until it engages.
  • Page 26 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the template from the kit and cut along the outer lines LHD/RHD IMG-279845 Tape the template to the loudspeaker grille. IMG-280035 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 27 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Drill at right angles to the loudspeaker grille where the holes are to be. Note! Select the correct version LHD or RHD and with loudspeaker grille. Predrill the holes according to the template using a Ø3 mm (1/8") drill bit.
  • Page 28 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Illustrations A and B Drill perpendicularly through the holes in the speaker grille and through the loudspeaker bracket. Remove the loudspeaker grille as before. IMG-296558 IMG-280037 Drill the three holes for the cradle's feet using a step drill Ø14 mm (9/16").
  • Page 29 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the step drill and drill out the hole for the connection in the holder using a Ø28 mm (1 7/64") drill bit. IMG-280041 Tape a cloth over the loudspeaker. IMG-280042 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 30 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Drill out corresponding hole in the loudspeaker's bracket using a Ø25 mm (1") hole saw. IMG-280043 Drill the holes for the holder's stud screws using a Ø7 (9/32") mm drill bit. IMG-280045 ©...
  • Page 31 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Bend in and file off the hole edges on the loudspeaker grille using a round file. Clean away any swarf. Remove the cloth. IMG-280046 Illustrations A and B Take three nuts, washer and the cradle out of the kit and secure to the loudspeaker grille.
  • Page 32 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the screws in the loudspeaker. IMG-280050 Lift up the loudspeaker. Disconnect the connector. Remove any swarf from the area for the loudspeaker. IMG-280051 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 33 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Place the loudspeaker upside down on a surface that will not cause any damage. Position the loudspeaker with the holes above the grille's clips. Check that the stud screws align in the three holes. If not, enlarge the holes so that the stud screws fit.
  • Page 34 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the middle panel by prying it downwards, pull it off at the lower edge and then unhook it at the top. IMG-279969 Remove the holder by depressing the catches and folding it backwards.
  • Page 35 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the four screws which hold the cover and rear end to the tunnel console. Lift up and unhook the upper panel. IMG-279971 Remove the two screws which hold the cover and rear end to the tunnel console.
  • Page 36 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the storage compartment mat. IMG-279973 Remove the four screws at the bottom of the storage compartment. IMG-279974 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 36 / 84...
  • Page 37 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the tunnel console's left side panel by carefully pulling it loose starting at the trailing edge. It is secured with six clips on the inside. Applies to left-hand drive cars Remove both panels.
  • Page 38 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take a piece of foam tape from the kit and cut it in the centre. IMG-318544 Wrap the foam tape around the fuse holder to prevent rattling. IMG-279976 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 39 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the connector (1) that was removed from the 12V outlet to the female connector (2) on the routed cable. Wind the foam tape around the connectors. Connect the remaining connector to the 12V outlet.
  • Page 40 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars without centre loudspeaker grille Insert a piece of wire on the left-hand side by the air vent and pull it out down by the tunnel console's left-hand side. Tape the cable harness connector and a piece of the cable at the wire.
  • Page 41 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Sections 68-75 apply to cars with centre loudspeaker grille Push a wire up along the left-hand side of the centre console and out on the left-hand side by the air vent. IMG-280054 Insert the wire through the hole (1) in the recess, where the loudspeaker was, and out.
  • Page 42 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take out the short connection cable from the kit and connect to the newly routed cable harness. IMG-280056 Secure the connected connectors at the bottom of the space where the loudspeaker was, using a piece of butyl tape.
  • Page 43 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the connector to the loudspeaker. Pull up the connected short cable through the hole in the loudspeaker bracket. IMG-280058 Reinstall the loudspeaker with its screws. IMG-280060 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 44 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take the loudspeaker grille with holder and connect the routed connector. IMG-280061 Note! Ensure the stud bolts fit in their holes before securing the grille. Insert the cable through the hole in the loudspeaker bracket.
  • Page 45 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to both right and left-hand drive vehicles Fold aside the floor mat on the left side of the center console. IMG-254304 Disconnect the two connectors on the left-hand side of the gear selector assembly.
  • Page 46 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take cable harness (A) from the kit. Connect the fiber-optic cable's connectors between those disconnected from the car's cable harness. Note! Fibre-optic cables may not be bent with a radius less than 25 mm (1").
  • Page 47 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to left-hand drive cars Insert the long fiber-optic cable (1) in front of the air duct and across the center console. Position the large loose connectors (2) and the excess of the fiber-optic cables (3) as illustrated.
  • Page 48 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to left-hand drive cars Take the cable harness from the kit. Insert the end with the two connectors from the front edge of the tunnel console's right- hand side inside the carpet and back along the inside of the tunnel console.
  • Page 49 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to all models Lift up the tunnel console at the trailing edge and pull up the connector from the hole in the trailing edge of the storage compartment. IMG-262111 Route the cable out from the storage compartment. Measure the length of the cable that is to protrude from the bottom of the storage compartment.
  • Page 50 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Clamp the cable by the left bracket on the tunnel console with a cable tie when the cable length has been measured. Reinstall the centre console in its position. IMG-262103 Take the control module and two pieces of foam tape from the kit.
  • Page 51 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Illustrations A and B Remove the protective film on the foam tape and attach as illustrated. IMG-262108 IMG-262109 Applies to left-hand drive cars Connect the two connectors to the control module. Clamp the USB/iPod cable at the eyelet on the control module using a cable tie.
  • Page 52 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fold the carpet to one side. Place the control module high up on the cowl panel and against the right-hand side of the centre console. Fold back the carpet. Note! Do not damage the fibre optic cable.
  • Page 53 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fold the carpet to one side. IMG-278646 Place the control module against the firewall under the cable harness. Secure the control module using a cable tie in the cable harness for the fuse box.
  • Page 54 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the fiber-optic cable in a loop in front of the climate control unit. IMG-278648 Applies to all models Tighten down the tunnel console with the four screws. Make sure that the cable from the USB/iPod adapter does not get caught in the rear bracket when the screws are tightened.
  • Page 55 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Illustrations A and B Image A shows car without telephone Illustration B shows car with telephone Mark out and drill holes at the rear edge of the storage compartment mat, use a Ø6 mm (1/4") drill bit.
  • Page 56 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the gear lever panel by carefully prizing it away starting at the rear edge and then continuing forward. It is fitted with six catches underneath. IMG-222806 Applies to cars with manual gearbox Remove the gear lever panel from the gaiter by first pressing in the four catches at the sides, and then pull the panel up.
  • Page 57 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the covers and screws in the rear edge of the upper panel section of the centre console, remove the screws on the rear of the panel and then remove the remaining screws on the top, ten in total.
  • Page 58 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Carefully angle up the upper section of the centre console at the front edge so that the edge clip for the large cable harness on the left-hand side of the centre console is accessible.
  • Page 59 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the panel by moving it backward at the front edge and then lifting it out from the rear edge of the tunnel console. IMG-222812 Remove the two screws from the media player.
  • Page 60 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Pull out the media player completely and remove the connectors. IMG-222814 Clean the area on the dashboard as illustrated, which corresponds to the size of the double-sided adhesive tape. Use a solution of 25% isopropanol and 75% water, as well as a lint free cloth.
  • Page 61 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove a long piece of foam tape from the kit and cut it in the centre. Tape the piece of foam tape around the cable to the control panel. IMG-260526 Applies to left-hand drive cars Position the keypad cable in the groove as illustrated.
  • Page 62 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the protective film on the control panel and press securely.. IMG-260527 Carefully push the cable harness in between the panels using a weatherstrip tool. Angle/pull out the upper section of the centre...
  • Page 63 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! Make sure the cable harness runs free of the panel's guides. IMG-260530 Secure the control panel's cable using a cable tie in the existing cable harness. IMG-260531 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 64 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the cable through to the other side. IMG-260532 Remove the right end panel of the dashboard. IMG-222265 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 64 / 84...
  • Page 65 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Detach the moulding on the front edge of the door opening. IMG-222267 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1 Page 65 / 84...
  • Page 66 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden 116A Illustrations A, B and C Pull the sill panel backwards with a weatherstrip tool so that the two clips release. Note! The front and upper sill panel must be removed and installed as one unit.
  • Page 67 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Detach the moulding at the upper A-pillar panel and the corner of the roof panel. IMG-225200 Remove the cover and bolt of the A-pillar panel. IMG-222271 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 68 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Carefully remove the A-pillar panel by starting at the upper edge and pulling it inwards into the car until the three clips on the inside release. IMG-222272 Remove the bracket for the sun visor.
  • Page 69 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the interior lighting by grasping the front edge and pulling downwards. It is held in place with six catches. IMG-253982 Remove the three screws. IMG-253984 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 70 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Take two 700 mm pieces of foam tape from the kit. Cut one piece of foam tape in the middle. Tape one long and one short piece of foam tape on the microphone cable starting 70 mm from the microphone.
  • Page 71 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Make a mark on the foam tape affixed to the cable 230 mm from the microphone. Use a cable tie to fasten the cable at the mark at the existing connector. Install the three trim screws.
  • Page 72 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Clean the microphone and roof panel in the area illustrated, which corresponds to the size of the double-sided adhesive tape. Use a solution of 25% isopropanol and 75% water, as well as a lint free cloth. Wipe dry carefully, do not rub.
  • Page 73 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the cable as illustrated. Take three small tie straps from the kit and secure the cable at the A-pillar. Refit the sun visor mountings. Reinstall the A pillar panel and weatherstrip.
  • Page 74 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Get a thick foam tape from the kit and fasten it on the front of the control module. Fold up the foam tape around the corners and edges of the control module.
  • Page 75 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Place the control module on the upper edge between the car's cable harness and sill. Note! The control module's connection must point forwards and with the foam tape towards the sill. IMG-269485 Take cable harness (B) from the kit.
  • Page 76 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the two 4-pin connections (2) from the cable harness (A), under the mat up to the A-pillar. IMG-269487 Connect the cable harness to the corresponding connector in the car. Take a thick piece of foam tape and wrap it around the connector.
  • Page 77 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Insert the taped connector into the compartment under the media player. IMG-269504 Connect the corresponding connectors on the cable harness to the media player. Reconnect the other connectors to the media player.
  • Page 78 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden 139A Illustrations A and B Open the cover on the holder for the connectors. Use a screwdriver to release the catches. IMG-269505 139B IMG-282896 Open the grey 4-pin connector and connect the cable harness between these.
  • Page 79 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the microphone cable (1) toward the centre console as illustrated. Route the cable harness (2) from the control module to the centre console as illustrated. Route the cable from the keypad (3) as illustrated.
  • Page 80 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Apply thin foam tape around the connectors and the excess cables and position them as illustrated. IMG-269507 Take the yellow cable with cable lug from cable harness (B) and push it up by the gearshift.
  • Page 81 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Route the cable as illustrated. Note! Make sure that the cable does not lie by any of the gearshift's moving parts. IMG-260631 Take the 10-pin green connector disconnected from the centre console. Open the catch.
  • Page 82 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the yellow cable to terminal 9. Press the catch back. IMG-260632 Take a tie strap from the kit and secure the cable to the existing cable harness. IMG-260633 © Volvo Car Corporation Mobility Connection Package- 31285543 - V1.1...
  • Page 83 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Reinstall the panel with its connectors and screws. Reinstall the detached components in reverse order. IMG-222816 First download software for USB and iPod®Music interface and then software for Handsfree System with Bluetooth, according to the service information in VIDA.
  • Page 84 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Check the function of the Bluetooth system as follows: Turn the ignition key to position I. Turn the radio on. Wait 20 seconds. Check that the control panel for Bluetooth illuminates. Press the round button (1) in the middle of the control panel.
