plen5stack_manual_en.md
Procedure
1. Ensure the switch board switch is in the off position. Connect servo motors #1 and #5 to the control
board pins as shown. When connecting the motors into the pins, ensure that the black (ground) cable is
towards the outside of the control board. Turn on the switch on the M5Stack.
-If you have not written the firmware yet, please refer to
2. The screen of M5Stack will be displayed and the servo motor will rotate and be initialized.
7. How to write the
19 / 60
firmware.
8/31/2020
