Axis JS7001K Instruction Manual

JS7001K
7 INCH LED MONITOR & HEAVY DUTY CAMERA KIT
SPECIFICATIONS
JS7001 MONITOR
- TFT Panel: New Grade A LCD, LED Backlight
- LCD Size: 178mm (7-Inch) Diagonal
- Display Format: 16:9
- Resolution: 800 x 480
- Brightness: < 400 CD/M2
- Viewing Angles: 90 Deg. Left/Right/Up/Down
- Video System: Auto PAL/NTSC Select
- Video Connect: 2 x 4-Pin (Female)
- Reverse Trigger: Assignable to Cam 1 or 2 (via Menu)
- Camera View: Input Selectable (CAM Button)
Input Overide in Reverse Mode
- Monitor View: Normal/Mirror Image Select
- Guidelines: Selectable
- Audio: On Board Speaker
- Main Menu: Brightness/Contrast/Colour/Volume/Reset/
Slideshow/Language/Reverse Priority & Delay
- Casing Material: 100°C Heat/Flame Proof (UL94V-0) ABS
- Power Input: 10-32V DC (Negative Ground)
- Dimensions: 182W x 122H x 29D mm (excluding brackets)
- Included: Stand Mount, U-Shape Mount, Remote Control,
Power Cable Assembly, Sunshade
Optional: Glass Mount Bracket (BKT101)
INSTRUCTION MANUAL
CAMERA
- Image Device:
- Image Sensor:
- Diagonal Viewing Angle:
- Horizontal Viewing Angle:
- Signal System:
- Effective Pixels:
- Resolution:
- Sync System:
- Orientation:
- Night Vision:
- Illumination:
- Ingress Protection:
- Integrated Microphone:
- Operating Temperature:
- Power Consumption:
- Dimensions:
- Connection:
- Power Supply:
- Included:
1/3" Nextchip NVP2040 CCD
Sony ICX639XK
130°
90°
PAL
752H x 582V
600 TV Lines
Internal
Mirror Image
Yes, 18 LED
0.1 Lux with IR on
IP67
Yes
-20 to 70°
90-300mA
77W x 52H x 69D mm
(Excl Bracket)
Terminated 4-Pin Male
8-50V DC
15m 4 Pin (Male) to 4 Pin
(Female)
Extension Cable,
Mounting Bracket
1
