Accessories Of The Standard F200 Analyzer - SD Biosensor F200 User Manual

A. Color TFT LCD
Use for displaying test screen and interacting with the graphic user interface
B. Test Slot
Part for inserting a test device to analyzer
C. Test Device
Use for proceeding the test by inserting the specified test device
D. Printer Cover
Use for covering and protecting the printer sheet
E. Printer Cover Button
Use for opening the printer cover
F. DC Jack Port
Use for connecting power supply adaptor 12V/5A to its compartment
G. Power Switch
Use for turning on/off the analyzer
H. USB x 4
Use for connecting with keyboard, barcode scanner and USB memory
When using USB memory or USB storage device, the USB file
system should be formatted to the FA32 so that the STANDARD
F200 Analyzer recognizes the USB.
Note
I. LAN
Use for communicating through the local area network
J. Mini USB
Use for upgrading the F/W upgrade by PC connection
K. Additional Device Port
Use for connecting with specific device manufactured by SD BIOSENSOR,Inc.

Accessories of the STANDARD F200 Analyzer

Accessory STANDARD F Calibration Set F CAL-1, F CAL-2, F CAL-3
STANDARD F Test Device
Barcode scanner
Optional
Printer Paper
AC/DC Power Adaptor
Specific test device manufactured
by SD Biosensor, Inc.
USB Barcode scanner
-
Input: AC 100~240 V, 50/60 Hz
(Voltage tolerance ± 10 %)
Output: DC 12V/5A
