Extang Solid Fold 2.0 Installation Sheet page 2

Install the cover mounting hardware on both sides.
Place onto the cover threaded bolt
the large washer,
the lock washer,
the threaded knob.
Loosely tighten the knob.
With the bed cover aligned with the vehicle
bed, carefully open the cover without
disturbing the alignment.
Rotate the middle clamps down from their stowed positions.
Slide the clamps out toward the vehicle bed.
Pull down on the clamps and swing them under the lip of the
hinge bracket flanges.
Close the cover and the
tailgate.
Align the bed cover
so that it is square
with the vehicle
bed and that it
is centered front
to back and
side to side.
Firmly tighten both mounting knobs..
IMPORTANT
Re-tighten the front / cab knobs after every use.
Fully close the cover. Rotate the tail clamps down from their stowed
positions. Slide the clamps out toward the vehicle bed.
Pull down on the clamps and swing them under the lip of the
tail bracket flanges.
