Extang Classic Platinum Installation Sheet

INS TAL LATI O N S H E E T
"DOUBLE HOOK"
Side Rail Clamps
(2 sizes)
Clamp Bolts
PARTS INCLUDED IN YOUR KIT. You may want to lay them out in this manner for accessibility.
1
Wash truck bed.
3
For Classic Platinum Only
ClickLock
TM
Depress the ClickLock
TM
release and remove one corner
from cab rail.
Extang Corporation
1901 E. Ellsworth Rd.
Ann Arbor, MI 48108
734 677-0444, Fax: 734 677-8409
Flareside Clamps
(This step does not apply to BlackMax)
Feed tarp dowel into cab rail.
(NOTE: For easiest feeding action, place tarp on a flat
smooth surface, and keep dowel straight while feeding
into cab rail. Caution, pavement may scuff tarp.)
Ford Flareside '04 –
MISSING PARTS???
call Extang at
Any and all needed parts will be shipped to you
Corner Pieces
directly. (DO NOT return whole kit to store)
Allen Wrench
B
LACK
2
Remove paper tape from all rails. Discard properly.
Reinsert corner piece into cab
rail until it "clicks" and locks
into place.
www.extang.com
Extra Cab Seal
Spring Bows
Tarp
1-800-877-2588
M has snaps on all rails.
AX
Foam has NO adhesive to
touch truck finish.
P L E A S E
D O N O T
L I T T E R
4
Off the truck bed, connect
the end rails to the two
side rails utilizing the
ClickLock™ clips.
Register your warranty at:
I t e m N o . 0 1 4 3 - 0 7 0 8 R H P r i n t e d i n U . S . A .
NOTE:
