Pedestal
Are you placing the dryer on a pedestal? You have the option of
purchasing pedestals of different heights separately for this dryer.
You may select a 10" (25.4 cm) or 15.5" (39.4 cm) pedestal.
These pedestals will add to the total height of the dryer for a total
height of approximately 48" (121.9 cm) or 53.5" (135.9 cm),
respectively.
For a garage installation, you will need to place the 10" (25.4 cm)
pedestal at least 9" (22.9 cm) above the floor and the
15.5" (39.4 cm) pedestal at least 3.5" (8.9 cm) above the floor.
A
A. 10" (25.4 cm) pedestal
B. 15.5" (39.4 cm) pedestal
The pedestals are available in several colors.
To order, call the dealer from whom you purchased your dryer or
refer to the "Assistance or Service" section.
Pedestal
Color
Height
10" (25.4 cm)
White
10" (25.4 cm)
Biscuit
10" (25.4 cm)
Diamond Dust
(Silver)
10" (25.4 cm)
Black Diamond
15.5" (39.4 cm)
White
15.5" (39.4 cm)
Biscuit
15.5" (39.4 cm)
Diamond Dust
(Silver)
15.5" (39.4 cm)
Black Diamond
Stack Kit
Are you planning to stack your DUET
so, you will need to purchase a Stack Kit.
To order, call the dealer from whom you purchased your dryer or
refer to the "Assistance or Service" section. Ask for Part Number
8541503.
Door Reversal Kit
Are you planning to reverse the door swing direction on your
®
DUET
dryer? To do so, you will need to purchase a Door
Reversal Kit.
4

Options

B
Part Number
WHP1000SQ
WHP1000ST
WHP1000SU
WHP1000SB
WHP1500SQ
WHP1500ST
WHP1500SU
WHP1500SB
®
washer and dryer? To do
To order, call the dealer from whom you purchased your dryer or
refer to the "Assistance or Service" section. Ask for Part Number
8579666.
Door Reversal and Stack Combination Kit
Are you planning to reverse the door swing direction on your
®
DUET
dryer and stack your DUET
you can purchase a Door Reversal and Stack Combination Kit.
To order, call the dealer from whom you purchased your dryer or
refer to the "Assistance or Service" section. Ask for Part Number
W10110889.
Backguard
If you are installing your DUET
avoid having loose items fall behind your machines, you may
purchase a pair of washer/dryer backguards. These will reduce
the chance of items falling behind the machines during operation.
To order, call the dealer from whom you purchased your dryer or
refer to the "Assistance or Service" section. Ask for Part Number
8558694 (White).

Location Requirements

WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Place dryer at least 18 inches (46 cm) above the floor
for a garage installation.
Failure to do so can result in death, explosion, or fire.
You will need
A location that allows for proper exhaust installation. See
"Venting Requirements."
A separate 30-amp circuit.
If you are using a power supply cord, a grounded electrical
outlet located within 2 ft (61 cm) of either side of the dryer.
See "Electrical Requirements."
A sturdy floor to support the total dryer weight of 200 lbs
(90.7 kg). The combined weight of a companion appliance
should also be considered.
A level floor with a maximum slope of 1" (2.5 cm) under entire
dryer. If slope is greater than 1" (2.5 cm), install Extended
Dryer Feet Kit, Part Number 279810. Clothes may not tumble
properly and automatic sensor cycles may not operate
correctly if dryer is not level.
For a garage installation, you will need to place the dryer at
least 18" (46 cm) above the floor. If using a pedestal, you will
need 18" (46 cm) to the bottom of the dryer.
®
washer and dryer? To do so,
®
washer and dryer and wish to
