Dryer Use; Starting Your Dryer - Whirlpool Duet W10151592A Use And Care Manual

Duet electronic electric dryer
Hide thumbs


Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Do not dry anything that has ever had anything
flammable on it (even after washing).
Failure to follow these instructions can result in death,
explosion, or fire.
WARNING: To reduce the risk of fire, electric shock, or injury to
persons, read the IMPORTANT SAFETY INSTRUCTIONS before
operating this appliance.
This manual covers several different models. Your dryer may not
have all of the cycles and features described.
The following is a guide to starting your dryer. Please refer to
specific sections of this manual for more detailed information.
1. Clean lint screen before each load. See "Cleaning the Lint
2. Place laundry in dryer and shut door.
3. Press the POWER button then rotate the dial to select either
an Automatic or Manual Cycle. The preset settings and drying
time for the cycle chosen will be displayed.
NOTE: A default time is displayed when an Automatic Cycle
is selected. During the first few minutes of the drying process,
the cycle time may automatically vary from the default time
based on the size and fabric type of the load. Toward the end
of the drying process, the estimated time display will adjust
again, showing the final drying time.
To use an Automatic Cycle
NOTE: A light next to each feature will glow green when the
feature is selected or will glow amber when the feature is
selectable. The light will not glow when the selection is
unavailable with the cycle or option combinations selected.
Press the POWER button.
Rotate the dial to select an Automatic Cycle.


Starting Your Dryer

No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on
it (including cooking oils).
Items containing foam, rubber, or plastic must be dried
on a clothesline or by using an Air Cycle.
Failure to follow these instructions can result in death
or fire.
Select DRYNESS LEVEL to adjust how dry you want the
load to be. As the cycle runs, the control senses the
dryness of the load and adjusts the time automatically for
the selected Dryness Level.
NOTE: Most loads may be dried using Normal, which is
shown in boldface type on your control panel. Normal is the
energy preferred dryness level and will use the least energy.
The default dryness setting is Normal when an Auto Dry
Cycle is selected. You can select a different dryness level,
depending on your load, by pressing DRYNESS LEVEL
and choosing More, Normal or Less. Selecting More,
Normal or Less automatically adjusts the dryness level at
which the dryer will shut off. Once a dryness level is set, it
cannot be changed without stopping the cycle.
The Dryness Level can be changed only with Automatic
Press the WRINKLE SHIELD™ feature button if this
option is desired.
Press the CYCLE SIGNAL button to set end of cycle
signal volume to desired level.
Press the DAMP DRY CYCLE SIGNAL button to set damp
dry signal volume to desired level.
Fire Hazard
