  • Page 1 Manual Version April 2020 NOMADA 12V105Ah...
  • Page 2 12V105Ah Li-ion battery. We kindly ask you to read this manual carefully before using the product. In this manual, the Nomada 12V105Ah Li-ion battery will be referred to as: the Li-ion battery. This manual is meant for the installer and the user of the Li-ion battery. Only qualified, certified personnel may install and perform maintenance on the Li-ion battery.

  • Page 3: Table Of Contents

    Disconnecting the Li-ion battery 5. Connecting Li-ion batteries in series and parallel 5.1. Connecting Li-ion batteries in series. 5.2. Connecting Li-ion batteries in parallel 5.3. Connecting Li-ion batteries in series and parallel 5.4. CANopen interface Be in charge. Super B.
  • Page 4 5.4.1. CAN Bus network topology 5.4.2. Termination Resistors 5.4.3. CAN bus power 6. Battery use 6.1. General information 6.2. Charging 6.2.1. Battery balancing 6.2.2. Reading the battery’s State of Charge (SoC) 6.3. Battery Monitoring Software 6.3.1. Battery History Recording 7. Inspection and cleaning 7.1.

  • Page 5: Safety Guidelines And Measures

    Batteries may be returned to the manufacturer. Li-ion WARNING: Must be disposed of properly. May explode if damaged or disposed Do not mix with other (industrial) waste. of in fire. Do not short circuit. Be in charge. Super B.

  • Page 6: Introduction

    Nomada 12V105Ah Li-ion battery 2.2. Intended use The Nomada 12V105Ah Li-ion battery serves as an energy source of 12V in power systems for recreational vehicles, commercial vehicles, leisure boats, commercial vessels and stationary applications. Potential applications for this Li-ion battery include: off grid power supply, marine power supply, medium for (renewable) energy storage and (traction) battery for vehicles.

  • Page 7: Used Symbols

    Adaptive cell balancing • Configurable in serial or parallel connection 3.2. Technical specifications 3.2.1. Electrical specifications Nominal capacity 105Ah Energy 1344Wh Nominal voltage 12.8V Open circuit voltage 13.2V Self discharge <3% per month Table 2. Electrical specifications Be in charge. Super B.

  • Page 8: Mechanical Specifications

    3.2.2. Mechanical specifications Dimensions (LxWxH) 437 x 90 x 175 mm / 17.2” x 3.5” x 6.9” Weight 10 kg / 22 lbs Case material PC+ABS (UL94 V-0) flame-retardant battery casing Ingress protection IP66 Cell type / chemistry Prismatic - LiFePO4 Table 3.

  • Page 9: General Product Specifications

    Use the Li-ion battery in a dry, clean, dust free, well ventilated area. Do not expose the Li-ion battery to fire, solvents or excessive heat. 3.4. Scope of delivery Figure 1. Scope of delivery. 1. (1x) Nomada 12V105Ah lithium battery 2. (4x) M8 Bolt 3. (4x) M8 Spring washer 4. (4x) M8 Plain washer 5.

  • Page 10: Connections

    3.5. Connections Figure 2. Connections 1. Con 1 (CANopen; 5-pin “micro” style connector female) 2. Con 2 (CANopen; 5-pin “micro” style connector male) 3. Terminal + (2x M8) 4. Terminal - (2x M8) 3.5.1. Con 1 & 2 (CANopen; 5-pin “micro” style connector) PIN # Signal Description...

  • Page 11: Led Indicators

    Li-ion battery and can pose high safety risks for users and the environment. When a BIB or BCI with an external disconnect device is not installed the warranty of the Li-ion battery will be void. Be in charge. Super B.

  • Page 12: Optional Components

    3.6.2. Optional Components The Li-ion battery can be used in combination with a number of (Super B) products: Description Article name EAN code CAN Male-female Cable 0.6m 8718531360716 SB CAN Male-female Cable 0.6m CAN Male-female Cable 1m 8718531360723 SB CAN Male-female Cable 1m...

  • Page 13: Installation

    4.2. Unpacking Check the Li-ion battery for damage after unpacking. If the Li-ion battery is damaged, contact your reseller or Super B. Do not install or use the Li-ion battery if it is damaged! 4.3. Preparing the battery for use Caution! Do not operate the Li-ion battery beyond published maximum specifications.

  • Page 14: Using The Sb Bib (Battery Interface Box)

    BIB. Figure 4. Connecting a Li-ion battery to the SB BIB Consult with Super B for the SB BIB installation instructions. 4.4.2. Using the SB BCI-C1 (Battery Communication Interface) with a normal relay Figure 5.

  • Page 15: Disconnecting The Li-Ion Battery

    Caution! Before connecting 2 or more Li-ion batteries in parallel, the Li-ion batteries must be charged to 100% SoC. Caution! For more than 4 Li-ion batteries in parallel connection consult Super B or your dealer. Caution! Depending on the installation a precharge circuit might be needed. For further information consult Super B or your dealer.

  • Page 16: Connecting Li-Ion Batteries In Series And Parallel

    5.3. Connecting Li-ion batteries in series and parallel Caution! Before connecting 4 or more Li-ion batteries in series and parallel, the Li-ion batteries must be charged to 100% SoC. Caution! For more than 4 Li-ion batteries in series and parallel connection consult Super B or your dealer.

  • Page 17: Canopen Interface

    Caution! Depending on the installation a precharge circuit might be needed. For further information consult Super B or your dealer. Figure 8. Four Li-ion batteries in a series - parallel connection with a BCI and external disconnect device. 5.4. CANopen interface The CANopen interface of the Li-ion battery must be used for communication with the BCI/BIB and can be used for monitoring purposes.

  • Page 18: Termination Resistors

    ±120 ohms. Please note that the terminator can be connected directly to the second connector on the Li-ion battery by using the available Super B terminators. 5.4.3. CAN bus power Due to the galvanic isolation between the BMS and the Li-ion battery’s CAN interface an external power supply is needed on the CAN bus.

  • Page 19: Battery Use

    6.1. General information Warning! It is required to use a Super B Battery Communication Interface (BCI) in combination with an external disconnect device or a Super B Battery Interface Box (BIB), for safe operation of the Li-ion battery. Warning! In case of an undervoltage shutdown the charging current must be very low until a safe voltage is achieved.

  • Page 20: Battery Balancing

    The Li-ion battery’s State of Charge can only be read by CAN communication. 6.3. Battery Monitoring Software Super B battery monitoring software offers the possibility to monitor the parameters of the Li- ion battery, such as cell voltage or temperature. It also enables one to download a complete recording of the Li-ion battery’s properties over time.

  • Page 21: Inspection

    Transporting an end-of-life, damaged, or recalled Li-ion battery may, in certain cases, be specifically limited or prohibited. The transport of the Li-ion battery falls under hazard class UN3480, class 9. For transport over water, air and land, the Li-ion battery falls within packaging group PI965 Section II. Be in charge. Super B.

  • Page 22: Disposal And Recycling

    10. Disposal and recycling Always discharge the Li-ion battery before disposal. Use electrical tape or other approved covering over the terminals to prevent short circuits. Battery recycling is encouraged. Dispose of the Li-ion battery in accordance with local, state and federal laws and regulations. Batteries may be returned to the manufacturer. 11.

  • Page 23: Warranty And Liability

    In the event that any such damage has arisen, the customer must notify Super B thereof as soon as possible, in any event no later than three (3) days of delivery, by means of accurate, written statement, stating the damage and where possible a photograph.
  • Page 24 These policies contain a usual limitation of insurance payment to be paid out to Super B if, and to the extent that, the event is a covered event.
  • Page 25 Be in charge. Super B.
  • Page 26 For more information please contact: Super B Lithium Power B.V. Demmersweg 3 7556 BN Hengelo (Ov) The Netherlands Tel: +31 (0)88 0076 000 E-mail: info@super-b.com www: www.super-b.com Manual January 2020...
