- Page 1 Manual Version February 2024 NOMADA 12V105Ah NOMADA 12V105Ah-LT...
- Page 2 12V105Ah Li-ion battery. We kindly ask you to read this manual carefully before using the product. In this manual, the Nomada 12V105Ah Li-ion battery will be referred to as: the Li-ion battery. This manual is meant for the installer and the user of the Li-ion battery. Only qualified, certified personnel may install and perform maintenance on the Li-ion battery.
-
Page 3: Table Of Contents
Using the BCI (Battery Communication Interface) with a normal relay 4.5. Disconnecting the Li-ion battery 5. Connecting Li-ion batteries in series and parallel 5.1. Connecting Li-ion batteries in series. 5.2. Connecting Li-ion batteries in parallel Be in charge. Super B. - Page 4 5.3. Connecting Li-ion batteries in series and parallel 5.4. CANopen interface 5.4.1. CAN Bus network topology 5.4.2. Termination Resistors 5.4.3. CAN bus power 5.5. Independent temperature sensor (optional) 6. Battery use 6.1. General information 6.2. Charging 6.2.1. Battery balancing 6.2.2. Reading the battery’s State of Charge (SoC) 6.3.
-
Page 5: Safety Guidelines And Measures
Disconnect the Li-ion battery from the equipment when not in use. • Do not charge the Li-ion battery below 0°C, except for the Nomada 12V105Ah-LT model, which features internal heating. Warning! Keep the Li-ion battery away from dust and contamination. Place the Li-ion battery in well ventilated areas. -
Page 6: Introduction
Nomada 12V105Ah Li-ion battery 2.2. Intended use The Nomada 12V105Ah Li-ion battery serves as an energy source of 12V in power systems for recreational vehicles, commercial vehicles, leisure boats, commercial vessels and stationary applications. Potential applications for this Li-ion battery include: off grid power supply, marine power supply, medium for (renewable) energy storage and (traction) battery for vehicles. -
Page 7: Glossary Of Terminology
Easy CAN bus interconnection • Battery monitoring and history storage • Adaptive cell balancing • Configurable in serial or parallel connection • Independent temperature sensor for DNV type approved battery • The optional LT model includes internal heating Be in charge. Super B. -
Page 8: Technical Specifications
3.2. Technical specifications 3.2.1. Electrical specifications Nomada 12V105Ah Nomada 12V105Ah-LT Nominal capacity 105Ah 105Ah Energy 1344Wh 1344Wh Nominal voltage 12.8V 12.8V Open circuit voltage 13.2V 13.2V Self discharge <3% per month <3% per month Table 2. Electrical specifications 3.2.2. Mechanical specifications... -
Page 9: Temperature Specifications
3.2.4. Temperature specifications Nomada 12V105Ah Nomada 12V105Ah-LT Charge temperature 0°C to 55°C / 32°F to 131°F -30°C to 55°C / -22°F to 131°F Discharge temperature -20°C to 55°C / -4°F to 131°F -30°C to 55°C / -22°F to 131°F Storage temperature short -20°C to 45°C / -4°F to 113°F... -
Page 10: Scope Of Delivery
Use the Li-ion battery in a dry, clean, dust free, well ventilated area. Do not expose the Li-ion battery to fire, solvents or excessive heat. 3.4. Scope of delivery Figure 1. Scope of delivery. 1. (1x) Nomada 12V105Ah lithium battery 4. (4x) M8 Plain washer 2. (4x) M8 Bolt 5. (2x) Terminal protection cap 3. -
Page 11: Con 1 & 2 (Canopen; 5-Pin "Micro" Style Connector)
Note: Con 3 is only available for the DNV type approved model, as standard the battery is delivered without this optional connector, for further details and detailed information on how to use this connector please contact Super B 3.5.1. Con 1 & 2 (CANopen; 5-pin “micro” style connector) -
Page 12: Led Indicators
Figure 3. Protective M12 cap 3.5.3. LED Indicators Figure 4. LED Indicators D1 (Green) D2 (Yellow) D3 (Red) Mode Empty / Deep discharge 2 Off Alarm mode 3 On Operational mode 4 Flashing Operational mode (Idle) 5 Off Warning mode Table 10. -
Page 13: Peripheral Equipment
When a BIB or BCI with an external disconnect device is not installed the warranty of the Li-ion battery will be void. 3.6.2. Optional Components The Li-ion battery can be used in combination with a number of (Super B) products: Article name EAN code 8718531360716 CAN Cable 0.6m Male to Female... -
Page 14: Installation
4.2. Unpacking Check the Li-ion battery for damage after unpacking. If the Li-ion battery is damaged, contact your reseller or Super B. Do not install or use the Li-ion battery if it is damaged! 4.3. Preparing the battery for use Caution! Do not operate the Li-ion battery beyond published maximum specifications. -
Page 15: Connection Wires
4.4. Connection wires Use appropriate wire for the connection wires to prevent overheating and unnecessary losses. Use appropriate fuses matching the wires and load. Super B suggests to use 95mm connection wires. Connection wires with smaller diameters can cause overheating or unnecessary losses. -
Page 16: Using The Bib (Battery Interface Box)
BIB. Figure 6. Connecting a Li-ion battery to the BIB Consult with Super B for the BIB installation instructions. 4.4.2. Using the BCI (Battery Communication Interface) with a normal relay Figure 7. Connecting a Li-ion battery to the BCI... -
Page 17: Disconnecting The Li-Ion Battery
Caution! Before connecting 2 or more Li-ion batteries in parallel, the Li-ion batteries must be charged to 100% SoC. Caution! For more than 4 Li-ion batteries in parallel connection consult Super B or your dealer. Caution! Depending on the installation a precharge circuit might be needed. For further information consult Super B or your dealer. -
Page 18: Connecting Li-Ion Batteries In Series And Parallel
5.3. Connecting Li-ion batteries in series and parallel Caution! Before connecting 4 or more Li-ion batteries in series and parallel, the Li-ion batteries must be charged to 100% SoC. Caution! For more than 4 Li-ion batteries in series and parallel connection consult Super B or your dealer. -
Page 19: Canopen Interface
Caution! Depending on the installation a precharge circuit might be needed. For further information consult Super B or your dealer. Figure 10. Four Li-ion batteries in a series - parallel connection with a BCI and external disconnect device. 5.4. CANopen interface The CANopen interface of the Li-ion battery must be used for communication with the BCI/ BIB and can be used for monitoring purposes. -
Page 20: Termination Resistors
±120 ohms. Please note that the terminator can be connected directly to the second connector on the Li-ion battery by using the available Super B terminators. 5.4.3. CAN bus power Due to the galvanic isolation between the BMS and the Li-ion battery’s CAN interface an external power supply is needed on the CAN bus. -
Page 21: Independent Temperature Sensor (Optional)
The internal circuit can be powered from the CAN bus power, or by using the input connections within the Con 3 connector. The temperature sensor output is a fused open-drain output, pulling the signal line low when the temperature sensor has been activated. The sensor trip level is ~75°C. Be in charge. Super B. -
Page 22: Battery Use
Caution! When charging via an externally driven alternator, it must be ensured that an optimal charging curve charges the Li-ion battery (see for instructions the charging manual which can be found on the Super B website). For this, the use of a charge converter (DC/DC booster) is indispensable. -
Page 23: Reading The Battery's State Of Charge (Soc)
Additionally, a secondary internal failsafe mechanism is in place. 6.4. Battery Monitoring Software Super B battery monitoring software offers the possibility to monitor the parameters of the Li- ion battery, such as cell voltage or temperature. It also enables one to download a complete recording of the Li-ion battery’s properties over time. -
Page 24: Cleaning
Li-ion battery will vary depending on the products’ configuration and its application. 3. Routinely check the Li-ion battery’s SOC. Lithium Iron Phosphate batteries have some level of self- discharge (<3% per month) when not in use or stored. 4. Consider replacing the Li-ion battery if you note either one of the following conditions: - The Li-ion battery run time drops below about 80% of the original run time. -
Page 25: Disposal And Recycling
If the product is defective, please contact the dealer, reseller or retailer that you purchased the product from. Super B’s liability for any of its products is limited to the corresponding provisions under mandatory applicable law. - Page 26 For more information please contact: Super B Lithium Power B.V. Europalaan 202 7559 SC Hengelo (Ov) The Netherlands Tel: +31 (0)88 0076 000 E-mail: info@super-b.com www: www.super-b.com Manual February 2024...
