PART FOUR – ELECTROMECHANICAL CHARACTERISTICS
Use a circuit breaker rated at 2 A for one and two devices. For each additional device added to the system depending
on the same power source a 1 A stronger circuit breaker should be used.
Characteristic
Dimensions
Mass
Input Voltage
Range
Average Current
Wi-Fi / Bluetooth
range
80 [mm] (3.125˝) size
82 x 82 x 52 [mm]
3.23˝ x 3.23˝x 2.05˝
279 grams
9.84 oz.
9.0 – 30.0V DC
150 milliamps @ 12V DC
100 metres / 20 metres
Version: All
Page 7 of 9
57 [mm] (2.25˝) size
62 x 62 x 63 [mm]
2.44˝ x 2.44˝x 2.48˝
215 grams
9.84 oz.
9.0 – 30.0V DC
150 milliamps @ 12V DC
100 metres / 20 metres
