PART ONE – INTRODUCTION
The aim of this manual
is to make sure that the devices you purchase and install by yourself are installed properly.
Since this manual is shared for multiple devices, at the name of each step in square brackets [/] initials of the
device, for which the step is valid for, will be written. The initials used are as follow:
LX 10k
-
LX Era
-
LX Traffic Monitor
-
LX Horizon
-
LX iris series
-
The reason for sharing steps and manual is that these devices share the same hardware platform, with the
distinction of the LX Era being of a different orientation (rotated left by 90°) to the other devices.
It is also important to note, that all of the devices, apart from the 10k main device, all units come in either
an 80 or 57 [mm] standard aviation size instrument panel hole.
– [K]
– [E]
– [T]
– [H]
– [I]
Version: All
