- Page 1 Installation Manual Simrad ES38DD Split-beam transducer TECHNOLOGY FOR SUSTAINABLE FISHERIES www.simrad.com...
- Page 3 The installation shipyard must provide all necessary installation drawings. If required, all documents provided by the shipyard for the physical installation of the ES38DD must be approved by the vessel’s national registry and corresponding maritime authority and/or classification society. The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval.
- Page 4 If you require maintenance or repair, contact your local dealer. You can also contact us using the following address: simrad.support@simrad.com. If you need information about our other products, visit https: //www.simrad.com. On this website you will also find a list of our dealers and distributors. Kongsberg Maritime AS www.kongsberg.com...
-
Page 5: Table Of Contents
Installation Manual Table of contents ABOUT THIS MANUAL .............. 5 SIMRAD ES38DD ..............7 Order information ......................8 Physical and environmental specifications ................9 Support information ......................10 TRANSDUCER HANDLING AND MAINTENANCE....... 12 Rules for transducer handling ..................13 Approved anti-fouling paints ...................14 Inspecting and cleaning the transducer face ..............16 Painting the transducer face .....................17... - Page 6 Simrad ES38DD 341701/B...
-
Page 7: About This Manual
The outline dimensions of the ES38DD transducer and the relevant installation items can be found in the Drawing file chapter in this manual. - Page 8 Simrad ES38DD Installation Manual Registered trademarks Observe the registered trademarks that apply. Windows ® is a registered trademark of Microsoft Corporation in the United States and other countries. Simrad ® , SIMRAD ® and the Simrad ® logo are either registered trademarks, or trademarks of Kongsberg Maritime AS in Norway and other countries.
-
Page 9: Simrad Es38Dd
Simrad ES38DD Simrad ES38DD The Simrad ES38DD is a split-beam transducer. It uses 88 "tonpilz" elements distributed over four quadrants. It is filled with a liquid, and this enables use down to 1500 metres depth. This makes the transducer well suited for landers and towed bodies. -
Page 10: Order Information
Simrad ES38DD Installation Manual Order information To order the ES38DD, or any of the optional items provided with it, contact your local dealer. If you do not have a regular dealer, a list of all our distributors and dealers can be found on our website. -
Page 11: Physical And Environmental Specifications
: +70° C Maximum – : -20° C Minimum • Operating temperature – : +30° C Maximum – : -5° C Minimum Related topics Simrad ES38DD, page 7 200031 Dimensions ES38DD, page 31 074076 Mounting ring ES38DD, page 33 341701/B... -
Page 12: Support Information
Simrad ES38DD Installation Manual Support information If you need technical support for your Simrad ES38DD you must contact your local dealer, or one of our support departments. A list of all our offices and dealers is provided on our website. You can also contact our main support office in Norway. - Page 13 : Kongsberg Maritime China Ltd Company name • : 555 Chuanqiao Road, China (Shanghai) Pilot Free Trade Zone, 201206, Address China • : +86-21-3127-9888 Telephone • : +86-21-3127-9555 Telefax • https://www.simrad.com Website • simrad.china@simrad.com E-mail address Related topics Simrad ES38DD, page 7 341701/B...
-
Page 14: Transducer Handling And Maintenance
Simrad ES38DD Installation Manual Transducer handling and maintenance Topics Rules for transducer handling, page 13 Approved anti-fouling paints, page 14 Inspecting and cleaning the transducer face, page 16 Painting the transducer face, page 17 341701/B... -
Page 15: Rules For Transducer Handling
Cleaning and painting the transducer face During normal use, the transducer is subjected to biological fouling. If this marine growth is excessive, it will reduce the performance of the ES38DD. The transducer has not been designed with any protection against biological fouling. -
Page 16: Approved Anti-Fouling Paints
Because some paint types may be aggressive to the polyurethane in the transducer, consult our list of approved paints. The list can also be found on http://www.simrad.com. Observe the relevant instructions and safety information provided by the paint manufacturer. - Page 17 Apply 40 µm dry film thickness. – : Intersmooth 7465Si SPC Paint Apply 100 µm dry film thickness. The list can also be found on http://www.simrad.com. Related topics Transducer handling and maintenance, page 12 Painting the transducer face, page 17 341701/B...
-
Page 18: Inspecting And Cleaning The Transducer Face
Context During normal use, the transducer is subjected to biological fouling. If this marine growth is excessive, it will reduce the performance of the ES38DD. Whenever opportunity arise, typically when the vessel is dry-docked, the transducer face must be cleaned for shells and other marine growth. -
Page 19: Painting The Transducer Face
Painting the transducer face, page 17 Painting the transducer face Marine growth (biological fouling) on the transducer face reduces the ES38DD performance. We recommend that you paint the transducer face immediately after installation, and then again as often as required to maintain the protection. - Page 20 Simrad ES38DD Installation Manual • Wet film gauge • Airless spray Because some paint types may be aggressive to the polyurethane in the transducer, consult our list of approved paints. Context The transducer has not been designed with any protection against biological fouling.
- Page 21 Transducer handling and maintenance Further requirements The contractor or shipyard must keep a daily paint log recording all relevant information from the surface treatment. Related topics Transducer handling and maintenance, page 12 Approved anti-fouling paints, page 14 Inspecting and cleaning the transducer face, page 16 341701/B...
-
Page 22: Installing The Transducer
Simrad ES38DD Installation Manual Installing the transducer Topics Installation on a towed body, page 21 Installing the transducer, page 22 Dual transducer arrangement, page 23 Avoid protruding objects near the transducer, page 24 Using a suitable inclination angle, page 24... -
Page 23: Installation On A Towed Body
Installing the transducer Installation on a towed body Transducers designed to withstand large water pressure are suited for use in towed bodies. A towed body used to hold the transducer is not provided by Kongsberg Maritime. Your organization is responsible for design and manufacture of such body. The recommended installation method is through the hull plating hull using mounting ring. -
Page 24: Installing The Transducer
Simrad ES38DD Installation Manual Installing the transducer The transducer can be flush mounted on large vessels, where the size of the hull prevents air bubbles from reaching down to the transducer face. Flush mounting can also be used on vessels operating in shallow harbours or waters, where a protruding blister can not be accepted. -
Page 25: Dual Transducer Arrangement
Installing the transducer Dual transducer arrangement The illustration below shows a typical through the hull installation of small and large circular transducers on a towed body. Small transducer Medium or large transducer Electronic equipment in watertight compartment Related topics Installing the transducer, page 20 Installation on a towed body, page 21 Avoid protruding objects near the transducer, page 24 Using a suitable inclination angle, page 24... -
Page 26: Avoid Protruding Objects Near The Transducer
1 ° inclination angle. The smaller beam angle your transducer has, the smaller the inclination angle can be. Note Ensure that you do not mount the transducer with a negative inclination angle. This may cause turbulence on the transducer face, and reduced ES38DD performance. 341701/B... -
Page 27: Smooth Surface Is Important
Installing the transducer Related topics Installing the transducer, page 20 Installation on a towed body, page 21 Installing the transducer, page 22 Dual transducer arrangement, page 23 Smooth surface is important Make sure that the surface of the transducer face, as well as the plating and putty around the transducer is as even and smooth as possible. -
Page 28: Cable Layout And Interconnections
Simrad ES38DD Installation Manual Cable layout and interconnections Topics Burton underwater connector, page 27 341701/B... -
Page 29: Burton Underwater Connector
Cable layout and interconnections Burton underwater connector ES38DD transducer is fitted with only a short cable, and this is terminated in a female underwater connector. When the transducer is installed, the design of the subsea device must include a watertight junction box with the matched male panel socket. The transducer cable must then be fed from the junction box to the vessel or land station, or to a transceiver built into the subsea unit. - Page 30 Simrad ES38DD Installation Manual Pin configuration Pin on Sectors Pin on connector GPT connector 1 (+) 1 (-) 2 (+) 2 (-) 3 (+) 3 (-) 4 (+) 4 (-) It is very important that the transducer is correctly installed with the sectors positioned as shown in the illustration (seen from above).
-
Page 31: Drawing File
Drawing file Drawing file Topics About the drawings in the drawing file, page 30 200031 Dimensions ES38DD, page 31 074076 Mounting ring ES38DD, page 33 341701/B... -
Page 32: About The Drawings In The Drawing File
Simrad ES38DD Installation Manual About the drawings in the drawing file Relevant drawings related to the installation and/or maintenance of the ES38DD are provided for information purposes only. Note These drawings are provided only for information and planning purposes. Information may be omitted. -
Page 33: 200031 Dimensions Es38Dd
Drawing file 200031 Dimensions ES38DD Download the source drawing from the transducer pages on https://www.simrad.com/td. 341701/B... - Page 34 Simrad ES38DD Installation Manual Related topics Physical and environmental specifications, page 9 341701/B...
-
Page 35: 074076 Mounting Ring Es38Dd
Drawing file 074076 Mounting ring ES38DD Download the source drawing from the transducer pages on https://www.simrad.com/td. 341701/B... - Page 36 Simrad ES38DD Installation Manual Related topics Physical and environmental specifications, page 9 341701/B...
- Page 37 Index Index physical and environmental specifications .... 9 drawing about ES38DD mounting ring ......... 33 Burton subsea connectors....... 27 ES38DD outline dimensions ......31 dual transducer arrangement ......23 drawings ES38DD............ 7 about ............30 inclination angle ......... 24 approval ..........5, 30 installation drawings .........
- Page 38 ............ 10 maritime authority size approval of installation drawings ....5, 30 ES38DD........... 31 mechanical drawings ES38DD mounting ring ......... 33 about ............30 physical and environmental specifications .... 9 mounting smooth surface mounting the transducer ........ 22 transducer ..........22, 25...
- Page 39 Index weight physical and environmental specifications .... 9 341701/B...
