Instructions-Parts
Air Controls
Air controls for light and heavy duty Xtreme
24E025, 24Y396
Air Controls for Light Duty Xtreme Package Carts
24E013, 24Y101
Air Controls for Heavy Duty Xtreme Package Carts
17N621, 25D529, 25D649
Air controls for King Sprayer (XL6500/XL3400)
125 psi (0.86 MPa, 8.6 bar)
Maximum Air Working Pressure
depending on relief valve selected.
Important Safety Instructions
Read all warnings and instructions in this manual
and the Xtreme Packages manual. Save these
instructions.
®
Sprayer carts. For professional use only.
24W593, 24W040
Air Controls for Xtreme XL Cart or Wall Mount Packages
244841
Accessory lubricator kit for Xtreme or Xtreme XL Packages
17U994, 25D532, 25D650
Air controls for King Sprayer (XL10,000)
24Y101
3A0293H
EN
r_24e013_3A0293_1a
Advertisement
Table of Contents
Related Manuals for Graco 24E025
Summary of Contents for Graco 24E025
- Page 1 3A0293H ® Air controls for light and heavy duty Xtreme Sprayer carts. For professional use only. 24E025, 24Y396 24W593, 24W040 Air Controls for Light Duty Xtreme Package Carts Air Controls for Xtreme XL Cart or Wall Mount Packages 24E013, 24Y101...
-
Page 2: Table Of Contents
Locate the regulator as close as possible to the equip- Graco Standard Warranty ....14 ment it serves, but upstream from the bleed-type mas- ter air valve (3). -
Page 3: Adding A Lubricator (Accessory)
Use an oil rated at 50 to 200 SUS (ISO grade 7 to 6. Install the threaded end insert (13) onto the outlet of 46) at 100°F (38°C), such as Graco motor oil, Part No. the lubricator (L) with o-ring and grease. -
Page 4: Operation
Operation Operation Pressure Relief Procedure Adjusting the Air Regulator Use the bleed-type master air valve (3) to relieve air trapped between it and the pump when the valve is 1. Lock the gun trigger safety. closed. This helps reduce the risk of serious injury, 2. -
Page 5: Repair
Repair Repair Air Regulator Lubricator Service (Accessory) Repair Kits are available. Refer to page 6. An accessory Lubricator Kit is available. Order Part No. 244841. Repair Kits are available (refer to page 7) for an Every day, drain contaminants from the bowl before accessory lubricator. -
Page 6: Repair Kits
Repair Kits Repair Kits 116521, 17C498 C11034 Lubricator Air Filter/Regulator Sight Dome Repair Kit 116670 Lubricate with no. 2 Bowl lithium-base grease. Repair Kit 116672 Regulator Repair Kit 116634 TI1252A Bowl Replacement Kit 116672 . 2: C11034 Repair Kits 40 Micron Filter Element Kit 116635 TI1251A . -
Page 7: Parts
Parts Parts 24Y101 Xtreme Heavy Duty Cart Air Controls, Series C Ref. Part Description Qty. 116521 REGULATOR, filter, air 17B747 BRACKET 103833 SCREW, mach, pan hd 113429 COUPLING 113430 COUPLING 113218 VALVE, ball, vented, 3/4 105281 FITTING, union, swivel, 45 108638 FITTING, pipe, tee 100840 FITTING, elbow, street 100960 GAUGE, press air... - Page 8 Parts 24E025 Xtreme Lightweight Cart Air Controls, Series A and B Ref. Part Description Qty. 116521 REGULATOR, filter, air 160032 FITTING, nipple 113218 VALVE, ball, vented, 3/4 122327 ELBOW, street, pipe, 90° 157785 FITTING, swivel 108638 FITTING, pipe, tee 100840 FITTING, elbow, street...
- Page 9 Parts 24W593 and 24W040, For Xtreme XL Heavy Duty Cart or Wall Mount Packages Ref. Part Description Qty. 17C498 REGULATOR, filter, air, 1 in. npt 100467 ELBOW, street, pipe; wall mount only 17B747 BRACKET 103833 SCREW, mach, pan hd 127784 COUPLING, universal, 1 in. npt(m) 127785 COUPLING, universal, 1 in.
- Page 10 Parts 17N621 Air Control Module, 3/4 in. NPT For King Sprayer (XL6500/XL3400) Ref. Part Description Qty. 17U995 BRACKET, air controls, painted 116521 REGULATOR, filter, air 103833 SCREW, mach, crbh 113429 COUPLING, universal 113430 COUPLING, universal 16W586 CABLE, lanyard, whipcheck 113218 VALVE, ball, vented, .750 101689 GAUGE, press, air SAFETY VALVE 113498 110 psi, K30-K70 models...
- Page 11 Parts 25D649 Wall Mount Air Module For King Sprayer (XL6500/XL3400) Ref. Part Description Qty. 17U995 BRACKET, air controls, painted 116521 REGULATOR, filter, air 103833 SCREW, mach, crbh 113429 COUPLING, universal 113430 COUPLING, universal 16W586 CABLE, lanyard, whipcheck 113218 VALVE, ball, vented, .750 101689 GAUGE, press, air 115813 FITTING, street elbow, 3/4 npt SAFETY VALVE...
- Page 12 Parts 25D532 Air Lubricator, 1 in. For King Sprayer (XL10,000) Ref. Part Description Qty. 17U995 BRACKET, air controls, painted 17C498 REGULATOR, filter, air, 1 in. npt 103833 SCREW, mach, crbh 127784 COUPLING, universal, 1 in. nptm 127785 COUPLING, universal, 1 in. nptf 16W586 CABLE, lanyard, whipcheck 116522 KIT, conversion, air control C11034 LUBRICATOR, air...
-
Page 13: Technical Data
Technical Data Technical Data Air Controls Metric Maximum air input pressure 250 psi 1.7 MPa, 17.2 bar Gauge Port Size (Air Regulator) 1/4 npt(f) Air Filter Element 40 micron polypropylene screen Maximum operating temperature 50°C 122°F Air Inlet Size Xtreme, King (XL6500/XL3400) 3/4 npsm(f) Xtreme XL, King (XL10,000) 1 in. -
Page 14: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
