SIG PIPER J-3 CUB Building And Flying Instructions page 6

.
Hardware Bag
3 1-72x1/2" Brass Bolts (Slotted
Rd. Hd.)
4 2-56x3/8" Bolts (Slotted Rd.
Hd.)
6 #2 Flat Metal Washers
10 4-40 Blind Nuts
2 8-32x1/2" Bolts (Socket-Head)
2 5/32" id Wheel Collars
2 Small Nylon Control Horns
6 2-56 Metal R/C Links: Rudder
(2), Tail Brace Wires(4)
4 1/4" od Nylon Retainers:
pushrod connectors(2), door
latch(2)
Easy Hinge Bag
17 3/4"x1" SIG Easy Hinges
Nylon Hinge Bag
2 Molded Nylon Hinges
Rudder Pull-Pull Bag
1 .021" dia.x6 ft. Steel Cable
1 1/8" dia.x2" Heat-Shrink Tubing
Tail Wheel Assembly Bag
1 3/32" id Wheel Collar
2 6-32x1/2" Mounting Bolts
(Slotted Rd. Hd.)
1 Nylon Tiller Bar
Miscellaneous
2 Glass-Filled Engine Mounts
1 Aluminum Fueler Mount
1 .880 id x17-1/2" Phenolic Wing
Joiner Tube
1 SIGDKM282B J-3 Cub Fuselage
Decal
1 Printed Instrument Panel
1 Plan Sheet 4
Wood Parts Identification
Dimensioned balsa and hardwood parts are easily identifiable by comparing their shape and dimensions to the plans and to the
COMPLETE KIT PARTS LIST. On the other hand, proper identification of the different wing ribs, wing sheeting, fuselage
formers, etc., can be confusing because some of them are very similar looking, when in fact they are quite different.
Use the following KEY TO LASER-CUT PARTS diagrams to correctly identify each part. Use a pencil to label each part with its
name or number, before removing the parts from the laser-cut sheets.
IMPORTANT:
The laser cut parts contained in this kit are extremely accurate in outline and fit. They are meant to be used directly out of their
sheets, without any trimming or sanding unless specifically called for in the instructions. The laser cutting process produces a
brownish edge to the parts and, in some cases, a blackout edge may result when cutting harder plywood parts.
CA adhesives work perfectly on these parts and they do not need to be sanded to remove the discolored edges. In fact, sanding
the edges of laser cut parts can change their shape and/or dimensions, resulting in a poor fit. DO NOT edge sand the laser cut
parts in this kit.
3 1-72 Brass Hex Nuts
4 2-56x3/8" Bolts (Flat Head)
8 4-40x3/8" Bolts (Slotted Rd.
Hd.)
4 6-32x3/4" Bolts (Slotted Rd.
Hd.)
1 9/64" Allen "L" Wrench: for 8-32
bolts
2 6-32x1/8" Headless Set Screws:
for wheel collars
1 Medium Nylon Control Horn
7 2-56 Solder Links: Elevator(1),
Ailerons(2), Tail Brace Wires(4)
4 Straight Pins
4 3/32" odx1/2" Aluminum Tubes 2 2-56 Rigging Couplers
1 4-40x3/16" Mounting Bolt
(Slotted Rd. Hd.)
2 6-32 Square Anchor Nuts
1 Formed Leaf-Spring
2 .130" od x36" Nylon Tubes:
Elevator Pusrod, Throttle
Pushrod
2 .060" thick Aluminum: Lower
Strut Fittings
3 5/32" od x12" Brass Tube for
Jury Struts
1 SIGDKM282C J-3 Cub Bear
Decal
1 Plan Sheet 1
1 Assembly Manual
26 #2x3/8" Sheet Metal Screws
11 2-56 Hex Nuts
2 4-40x3/8" Bolts (Socket-Head)
4 6-32 Blind Nuts
2 8-32 Blind Nuts
1 1/16" Allen "L" Wrench: for wheel
collars
4 Nylon Landing Gear Straps
2 brass Pushrod Connector Bodies
2 4-40x3/8" Mounting Bolts
(Slotted Rd. Hd.)
1 Nylon Tailwheel Bearing
1 Formed Tailwheel Wire
1 .190" od x36" Nylon Tube:
Elevator Pushrod Sleeve
6 .060" thick Aluminum: Upper
Strut Fittings, Fuselage Strut
Fittings
1 2"x20" Glass Cloth Tape
1 SIGDKM283A Clipped Wing Cub
Fuselage Decal
1 Plan Sheet 2
2 #2x1/2" Sheet Metal Screws
4 2-56 Blind Nuts
2 4-40 Hex Nuts
2 #6 Flat Metal Washers
2 #8 Flat Metal Washers
2 4-40x3/8" Nylon Bolts (Socket-
Head)
3 2-56 Nylon R/C Links: Ailerons
(2), Elevator(1)
2 4-40x1/8" Socket-Head Bolt:
set screw for pushrod connector
2 2-56 Hex Nuts
2 4-40 Lock Nuts
1 Nylon Rudder Horn
2 Steering Springs
1 1/16" od x24" Steel Cable:
Throttle Pushrod
1 7/8" od x17-1/2" Aluminum
Wing Joiner Tube
1 SIGDKM282A J-3 Cub Wing
Decal
1 SIGDKM283B Clipped Wing Cub
Bear Decal
1 Plan Sheet 3
