For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the dishwasher and keep
them for future reference.
• Retain the manual. If you pass the dishwasher onto a third party, make
sure to include this manual.
• Keep ventilation openings in the dishwasher enclosure clear of
obstructions. The ventilation openings at the base of the dishwasher
must not be obstructed by carpet.
• Choose a location for your dishwasher away from heat sources such as
radiators or fires.
• Children should be supervised to ensure that they do not play with the
dishwasher.
• Keep mains cable out of reach from children.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Keep children away from detergents and rinse aids. These may cause
chemical burns in the mouth, throat and eyes or asphyxiation.
• Keep children away from the dishwasher when the door is open.
• Switch off and disconnect from the mains supply before fitting or
removing tools/attachments, after use and before cleaning.
• Keep your fingers away from moving parts and fitted attachments.
• Never use a damaged machine.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualified technician in order to avoid a hazard.
• Keep the mains cable and plug away from water.
• Never exceed the maximum capacities.
• 2 people are required to lift this dishwasher.
• Only use the dishwasher for its intended domestic use.
• This appliance is intended for indoor household use and similar
applications such as:
– farm houses and by clients in hotels, motels and other residential
SAFETY WARNING
DISHWASHER
1
Advertisement
Table of Contents
Related Manuals for Logik LID45W20
Summary of Contents for Logik LID45W20
- Page 1 SAFETY WARNING DISHWASHER For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the dishwasher and keep them for future reference. •...
- Page 2 type environments; – bed and breakfast type environments; – catering and similar non-retail applications. WARNING IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH INVOLVE THE REMOVAL OF COVERS. TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT REPAIRS YOURSELF.
- Page 3 dangerously bent or flattened. • Do not tamper with controls. • The appliance is to be connected to the water mains using new hose sets. • Never place heavy or wet items directly on top of the appliance. • Do not dismantle, repair or modify the machine. This may invalidate your guarantee and could lead to malfunction and cause fire or injury.
- Page 4 Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories. With over 1 million spares and accessories available we can deliver direct to your door the very next day. Visit www.partmaster.co.uk or call 0344 800 3456 (UK customers only) Calls charged at National Rate. The symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste.
- Page 5 45cm Integrated Dishwasher Installation / Instruction Manual LID45W20...
-
Page 6: Table Of Contents
Contents Unpacking ............................4 Installation ............................5 Location ....................................5 Product Overview ..........................12 Front View ..................................12 Rear View ..................................12 Internal View..................................12 Control Panel ................................... 13 Before Operating ..........................14 To Open the Door ................................14 To Close the Door ................................14 Items Not Suitable for Use in the Dishwasher ..................... - Page 7 Cleaning After Use ..........................30 External Care ................................... 30 - The Door and the Door Seal ............................ 30 - The Control Panel ................................ 30 Internal Care ..................................30 - Filtering System ................................30 - Spray Arms ..................................31 Frost Precaution ..........................31 Moving the Dishwasher ........................31 Maintenance After a Prolonged Period of Non-Operation ............32 Hints and Tips ............................32...
-
Page 8: Unpacking
Thank you for purchasing your new product. We recommend that you spend some time reading this instruction manual in order that you fully understand all the operational features it offers. You will also find some hints and tips to help you resolve any issues. Read all the safety instructions carefully before use and keep this instruction manual for future reference. -
Page 9: Installation
INSTALLATION Location When selecting a position for your dishwasher you should make sure the installation surface is flat and firm, and the room is well ventilated. Avoid locating your dishwasher near a heat source, e.g. cooker, boiler or radiator. Extreme cold ambient temperatures may also cause the appliance not to perform properly. - Page 10 INSTALLATION 3. Do not connect the unit to the mains socket before installation. Ensure you are not installing the unit right in front of the mains socket. This is to avoid potential damage to the back of the unit. 4. The condensation strip must be fitted to the underside of the worktop above your dishwasher to protect it against any moisture.
- Page 11 INSTALLATION 6. Position the dishwasher next to a water tap and a drain. Ensure the water inlet and drain hoses are not kinked or squashed. The unit must not stand on the mains cable. 7. Good levelling is essential for correct closure and sealing of the door.
- Page 12 INSTALLATION 9. Install the Aesthetic Panel onto the Hop hook dishwasher door. After the aesthetic panel is installed, the tension of the dishwasher door spring can be adjusted by rotating the adjusting bolt. If the tension is right, the door will remain horizontal in the fully open ST4*14 position.
- Page 13 INSTALLATION 13. To secure the dishwasher under the table Synthetic / Ceramic Worktop top, tighten the screws as shown. ST3.5x16 Hole Cover 14. Cut out a 448 mm wide plinth for toe panel. Tape the supplied toe panel mounting brackets to the toe panel as shown. Drill the required holes.
- Page 14 INSTALLATION 16. Attach the toe panel mounting brackets to the toe panel. Align the screw holes, then use the 4 screws ST4x14 to secure the toe panel. 17. Insert the toe panel to the dishwasher. 18. Make sure your plumbing is suitable for use Water mains with the dishwasher.
- Page 15 INSTALLATION 20. Connect the drain hose. The drain hose can be placed into your sink, or connected to the waste pipe. Before connecting to the waste pipe, make sure to check the waste pipe and remove any stopper or blockage inside, otherwise the unit may not be able to expel the waste water properly.
-
Page 16: Product Overview
Product Overview Front View Rear View Control panel Door handle Water inlet (connect to supply hose) Drain hose Mains cable Internal View 1. Cutlery Rack 5. Rinse Aid Reservoir 2. Spray Arm 6. Detergent Dispenser (one under the upper 7. Filtering System and one under the 8. -
Page 17: Control Panel
Control Panel EC O 1. ON/OFF button To turn on/off the power supply. 2. Programme button To select a wash programme. 3. Delay button To delay the wash starting time: 3 hours, 6 hours or 9 hours. 4. Half load button To choose half load washing of 6 place setting or less. -
Page 18: Before Operating
Before Operating To Open the Door • Pull the door handle. • If the door is opened during operation, first open the door slightly to avoid water spillage. If the door is opened during operation, all functions are automatically interrupted. To Close the Door •... -
Page 19: Adding Detergent Powder Or Tablet
Adding Detergent Powder or Tablet Only use detergents specifically designed for use in dishwashers. To be more environmentally friendly, please use no more than the correct amount of detergent. Fill the detergent dispenser with detergent powder or tablet. See the detergent manufacturers instructions for the correct amount to use. -
Page 20: Adding Rinse Aid
Adding Rinse Aid Rinse aid helps to ensure water does not cling and leave marks on crockery during the drying phase and helps crockery dry faster after it has been washed. Only pour rinse aid that is for domestic dishwashers into the reservoir. This model is designed to use liquid rinse aids only. Please follow the steps below to pour the rinse aid into the storage reservoir, and the amount will dispense automatically. -
Page 21: Adjusting The Rinse Aid Reservoir
Adjusting the Rinse Aid Reservoir To achieve a better drying performance, adjust the rinse aid level. 1. Open the door and press the ON/OFF button to switch on the dishwasher. 2. Within 60 seconds, press and hold the Programme button for more than 5 seconds, and then press the Delay button to enter setting mode. -
Page 22: Adding Salt
Adding Salt If the water in your area is hard, deposits will form on your dishes and utensils. This appliance contains a salt reservoir for you to reduce the hardness of the water. Please follow the steps below to pour the salt into the salt reservoir and it must be set to correspond to the water hardness level in your area. -
Page 23: Adjusting Salt Consumption
Adjusting Salt Consumption Salt consumption must be adjusted to correspond to the water hardness level in your area. If you don’t know how hard the water in your home is, please ask the company that supplies water in your area. It is recommended that adjustments should be made in accordance with the following chart. - Page 24 EC O EC O EC O EC O 4. After adjusting the water hardness level, press the ON/OFF button to save the setting.
-
Page 25: Loading The Dishwasher
Loading the Dishwasher Before Loading the Dishwasher Please observe the following notes before loading your cutlery and crockery into the basket. • Remove lipstick stains and any food residues from crockery and dishes. Rinse if necessary. • Dishes and cutlery must not lay inside one another, or cover each other. •... -
Page 26: Upper Basket
For safety reasons, do not operate the dishwasher without the upper and lower baskets in place. Upper Basket We recommend using the upper basket for small and lightweight items such as cups saucers, glasses, dessert bowls, etc. Shallow pans or casserole dishes can also be placed in the dishwasher basket. -
Page 27: Loading The Upper Basket For 10 Place Settings (According To En 60436)
Loading the Upper Basket for 10 Place Settings (according to EN 60436) For loading the upper basket, please refer to the table below. Number Item Cups Saucers Glasses Mugs Dessert bowls Glass bowl To prevent water dripping from the upper basket onto the dishes in the lower basket, we recommend that you empty the lower basket first and then the upper basket. -
Page 28: Loading The Lower Basket For 10 Place Settings (According To En 50242)
Loading the Lower Basket for 10 Place Settings (according to EN 50242) For optimum loading of crockery in the lower basket, please refer to the below table and image. Number Item Dessert dishes Dinner plates Soup plates Oval platter Cutlery Basket Loading the Lower Basket for 10 Place Settings (according to EN 60436) For optimum loading of crockery in the lower basket, please refer to the below table and image. -
Page 29: Cutlery Rack And Basket (According To En 50242 And En 60436)
Cutlery Rack and Basket (according to EN 50242 and EN 60436) To make unloading much easier, cutlery should be grouped in zones and placed in the cutlery rack and basket. Please refer to the table below for the optimum placement of cutlery. Cutlery rack Number Item... -
Page 30: Operation
Operation Starting a Wash Cycle Please follow the steps below to start a wash cycle. 1. Ensure the unit is connected to the mains power and the water supply is on (water pressure between 0.04MPa and 1.00MPa). 2. Open the door. Pull out the lower and upper baskets, load the dishes and push the baskets back. -
Page 31: Switching Off The Unit
Switching Off the Unit To save energy, remember to switch the dishwasher off using the ON/OFF button. The dishwasher will continue to use electricity until it is switched off. If the dishwasher is not going to be used for a long period of time, e.g. whilst on holiday, disconnect the unit from the mains supply. -
Page 32: Wash Cycle Table (According To En 50242)
Wash Cycle Table (according to EN 50242) Detergent Cycle Running Energy Water Rinse Amount Time Consumption Consumption Programme Process Selection (Pre-wash/ Information (min.) (kWh) Main wash) Intensive • For heaviest soiled • Pre-wash • Pre-wash 1.378 15.3 crockery, and (50°C) (5g) normally soiled pots, •... -
Page 33: Wash Cycle Table (According To En 60436)
Wash Cycle Table (according to EN 60436) Detergent Cycle Running Energy Water Rinse Amount Time Consumption Consumption Programme Process Selection (Pre-wash/ Information (min.) (kWh) Main wash) Intensive • For heaviest soiled • Pre-wash • Pre-wash 1.378 15.3 crockery, and (50°C) (4g) normally soiled pots, •... -
Page 34: Cleaning After Use
Cleaning After Use External Care The door and the door seal • Clean the door seals regularly with a soft damp cloth to remove food deposits. • When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door. -
Page 35: Spray Arms
Spray arms Particles of food can get stuck in the spray arm jets and bearings. The spray arms should therefore be checked and cleaned regularly. • Ensure the dishwasher is switched off. Use a pointed object, e.g. a cocktail stick, to loosen food particles in the spray arms’... -
Page 36: Maintenance After A Prolonged Period Of Non-Operation
Maintenance After a Prolonged Period of Non-operation If you are not going to use the unit for a prolonged period of time, you are advised to: 1. Disconnect the dishwasher from the mains socket. 2. Disconnect the unit from the water inlet and drain. Use a suitable receptacle to catch the water. - Page 37 Problem Possible Causes Remedy A spray arm is knocking against an Interrupt the programme, item in a basket. and re-arrange the items Knocking noise in the which are obstructing the wash cabinet. spray arm. See the section “Loading the Dishwasher”. Smearing appears The rinse aid dosage is too high.
-
Page 38: Fault Code
Fault Code Codes Description & possible causes Remedy Rapid programme Longer inlet time. indicator blinking • Faucets are not open. • Check and make sure the faucets rapidly (blink 5 • Water intake is restricted. are open and functioning properly. times faster than •... -
Page 39: Specifications
Specifications Rated Voltage and Frequency 220-240 V~50Hz Rated Power Input 1760-2100 W Inlet Water Pressure 1.0 MPa (maximum) – 0.04 MPa (minimum) Degree of protection against ingress of IPX1 water 815mm(H) x 448mm(W) x 550mm(D) Dimension (door closed) Features and specifications are subject to change without prior notice. Note: The above values have been measured in accordance with standards under specified operating conditions. - Page 40 IB-LID45W20-200727V1...
- Page 41 16176000A45261 ST3.5X45 ST3.5X25 11.5 ST3 .5X 16 3.5~5 kg 395.4 Front Counter Drain pipe ±1...
