Service Mode
A Step through below
B Cash Box
C Sales
D Display Temperature
E Set Refrig. Temp.
F Clear Totals
1 Number Sold
2 Enable Item (Disable)
3 Sales by Column
4 Escrow
5 Force Vend
6 Set Temp. (F or C)
7 Set Prices (Regular &
Secondary
8 ***Set Shelf Location (G, M1,
M2, D, E, E1, D2)
9 Relay Toggle Test
0 Clear Errors
*Factory Diagnostics – sub-menus
A Build #### = software revision build number
B Model # = Set Model Number DN5800-4, DN3800-4, DN5800-E4, DN3800-E4
E Extended Cup = All BevMax 3 5800-4 – Enabled
F Delivery (Picker) Cup Sensor Option = BevMax 3 5800-4 with cup sensor set ON, BevMax 3 5800-4 with out cup sensor set OFF.
1 Position Test = F – goes home; 0 – cycles plunger; * - stops all motors; Shelf letter – moves cup to shelf selected; Column # - moves cup to column selected.
2 Port Test = A – opens port; B – closes port; C – sensor test ON'; D – sensor test OFF; E – cup LED's on; F – port LED's on; * - All Stop.
3 Delivery (Picker) Cup Check = "On (status of cup sensor):#"; "In (detects product in cup):#"; "Out (picker out switch status):#"; "Hm (picker home switch status):#".
4 Repeat Vend
5 Vend Error Codes = Factory Use Only / Do Not Use.
6 Product Sensors = All BevMax 3 5800-4 set ON
7 Factory Use Only / Do Not Use
8 Shelf Offset = BevMax 3 5800-4 Shelf Location "D2" = 700
9 (Not Used)
0 Hook Swipe X = sets far right travel distance to Delivery door (BevMax 3 5800-4 factory default = 93871).
**Test Vend = Test Mode press "9" and "*" (enter) to get to "Enter Selection". Close the service door and choose desired selection to test vend.
To set Timers for schools = Set Date/Time / Set Not Available blocks / Set Not Available Times / Set Daylight Savings Time
Cash and Sales Numbers = Sales / Number Sold / Sales by Column / Total Sales / Cash Box
***Set Shelf Location = Service Mode press "8" - BevMax 3 5800-4 = D2 (default is 700)
Set Hook Swipe X = Test Mode press "F" and "*" (enter) to get to "Factory Diagnostics". Press "8" and "*" (enter) to get to Hook Swipe ##### (default is 91871).
BevMax 3 5800-4 Z Board Programming
Test Mode
A Step through below A
B List Errors B
C Light Timer C
D Enable Snack Menus D
E Keypad Test E
F *Factory Diagnostics F
1 Tube Fill/Dispense 1
2 Daylight Savings 2
3 Set Not Available 3
4 Set Credit Timer 4
5 Door Open 5
6 Power out 6
7 Test Health Guard 7
8 Display Health Guard 8
9 **Test Vend 9
0 Show Checksum 0
Setup Mode 1
Step through below A
Enter Message B
Clear Message C
Enable/Disable $ D
Set Happy Hour Time E
Master Reset F
Machine Number 1
Set Happy Hour 2
Set Not Available Time 3
Consumer Overpay 4
Date/Time 5
Total Sales 6
Health Control 7
Update Software 8
Set Lights Off Time 9
Enter New Password 0
Setup Mode 2 Satellite Mode (Multimate)
Step through below A Step through below
STS Enabled/Disabled B (not used)
Custom STS C Set SAT Price (Satellite only)
Default STS D Enable Combo Discount
Display STS E Number Combo Discount
Set No Vend Limit F (not used)
Multivend 1 Set Golden Eye Policy
Select Language 2 Set Golden Eye Selections
Sold Out Enable 3 Check Motor Scan (press #1)
Price Display 4 Set Credit Return Timeout
Storage Temp Enable
Interval Sales Reset Use other Setup Modes for:
Set Lights Off Multivend: Setup Mode 2 key 1.
Double Talk Set Not Available: Test Mode key
3.
Set Storage Time Set Not Available Time: Setup
Mode 1 key 3.
Set Storage Temp Test Vend: Test Mode key 9.
